2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |

GLOBE FOOD EQUIPMENT COMPANY

Project Name: AIA#:

Model #: Location:

Item #: Quantity:

12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.

Approved by: Date:

Globe® 80 Quart Planetary Floor Mixer SP80PL

Model

o SP80PL

Standard Features

• Powerful 3 HP custom built motor

• Gear-driven, high-torque transmission

• Heat-treated hardened steel alloy gears & shafts

• Four ﬁxed speeds

• Oil bath transmission

• Thermal overload protection

• Front-mounted touch pad controls with 60-minute

digital timer and last-batch recall

• Stainless steel, interlocking bowl guard with built-in

fully welded ingredient chute

• Heavy duty bowl truck (pictured)

• Power bowl lift

• Rigid cast iron body

• Industry standard #12 attachment hub

• NSF approved enamel gray paint

• 6-foot cord and ground plug

• Automatic safety shut off, provides superior motor and

transmission protection

Standard Accessories/Attachments

• 80 qt. stainless steel bowl (#304 series)

• Aluminum ﬂat beater

• Stainless steel wire whip

• Aluminum spiral dough hook

• Non-slip rubber feet

• Bowl truck

Warranty

• Two year parts and labor

Optional Attachments/Accessories

• Seismic ﬂange kit

• Vegetable slicer for #12 hub

• Shredder/grater for #12 hub

• Meat grinder for #12 hub

• Meat tenderizer for #12 hub

• Strip cutter for #12 hub

• Aileron (wing) whip

• 40 qt. adapter kit

• 60 qt. adapter kit

• Bowl scraper

• Correctional package

• Extended warranty

To select options, see complete list on back

The Perfect Mix of Value,

Performance & Durability

Features front mounted touch pad control

panel with 60-minute digital timer!

80 Quart Planetary Floor

Mixer

2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |

12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.

80 Quart Planetary Floor Mixer SP80PL

DIMENSIONS | SHIPPING INFORMATION

Cartons are reinforced for shipping. The weight and dimensions of this reinforced carton are included below and may vary from shipment to shipment.

This product ships on a pallet. Freight class 85.

Model Base Foot Print Overall Dimensions Net Weight Shipping Dimensions Shipping Weight

SP80PL

30.25'' W 36.5 D x

(77 cm x 93 cm)

30.25'' W 38.6" D 62'' Hx x

(77 cm x 98 cm x 156 cm)

1,003 lbs

(455 kg)

48'' W x 48'' D x 76'' H

(122 cm x 122 cm x 193 cm)

1,270 lbs

(575 kg)

SPECIFICATIONS

Model Motor Volts Amps

Transmission

Type

Capacity Controls

Power

Bowl

Lift First Second

First Second

SP80PL

(3 Phase)

3 HP 208/60/3 12 Gear

80 qt

75.7 liter

Digital, front

mounted

timer &

controls

1/8 HP

Motor

60 105 67 118

Third Fourth Third Fourth

176 310 198 349

Agitator Speeds (RPMs) Attachment Speeds (RPMs)

Mixer is constructed of a rigid cast iron body with front-mounted controls and 60-minute digital timer with last-batch recall. Mixer has 3 HP

custom built motor with overload protection and gear-driven, high torque permanently lubricated transmission consisting of heat-treated

hardened steel alloy gears and shafts. Mixer comes with 80 qt. stainless steel bowl, aluminum ﬂat beater, stainless steel wire whip, bowl truck,

aluminum spiral dough hook and non-slip rubber feet. Interlocked with stainless steel bowl guard with fully welded ingredient chute. Mixer has

#12 attachment hub and interlocked bowl lift. Mixer is NSF and ETL listed. Two-year parts and labor warranty.

OPTIONAL MIXER ACCESSORIES AND HUB ATTACHMENTS

MIXER:

XXSEISMIC KIT-LG Seismic kit

80 qt stainless XXBOWL-80

steel (S/S) bowl

XXBEAT-80 Alum. ﬂat beater

XXBEAT-80SS S/S ﬂat beater

XXHOOK-80 Alum. dough hook

S/S wire whipXXWHIP-80

Heavy-duty 4 mm XXHDWHIP80-4

S/S wire whip

XXAWHIP-80 80 qt aileron whip

scraper with mounting kitXXSCRP-80

Adapter kit - 40 qt XXACC40-80

bowl, hook, beater and whip

Adapter kit - 60 qt XXACC60-80

bowl, hook, beater and whip

HUB:

9" Slicer/Shredder/Grater XVSGH

housing only (no plates included-must

select from plates listed on this sheet)

Adjustable slicing plate XASP

(for vegetables only)

Plate holder -*only 1 requiredXPH

Shredding Plates:

3/32" (2.3 mm) XSP332*

XSP316* 3/16" (4.7 mm)

1/4" (6.3 mm)XSP14*

XSP516* 5/16" (7.9 mm)

1/2" (12.7 mm)XSP12*

Grating plateXGP*

Meat Tenderizer attachmentL00670

L00783 Strip Cutter attachment

XMCA-SS Meat grinder assembly

(Polished stainless steel cylinder, worm

gear, ring, and s/s pan. Includes knife,

3/16" plate, and pusher)

XXCK Chopper knife for XMCA-SS

Chopper Plate Sizes Available:

CP02-12 1/16" (2 mm)

5/32" (4 mm)CP04-12

CP05-12 3/16" (5 mm)

1/4" (6 mm)CP06-12

5/16" (8 mm)CP08-12

CP10-12 3/8" (10 mm)

CP12-12 1/2" (12 mm)

CP14-12 9/16" (14 mm)

CP16-12 5/8" (16 mm)

CP18-12 11/16" (18 mm)

CP00-12 Stufﬁng plate\

1/2" Stufﬁng tube (mutton)XST12

3/4" Stufﬁng tube (pork)XST34

FACTORY INSTALLED OPTION:

XXCORR-80 Correctional package,

includes tamper resistant external

fasteners.

EXTENDED WARRANTY

SP-XDSPL Extended warranty for

SP80PL mixer, extends factory warranty

to 3 years. Available only at time

of purchase.

Drawings available through KCL at www.kclcad.com.
