309315E

WARNING: HIGH PRESSURE.

Keep Clear of Nozzle.

Read these instructions carefully.

TI0666

INSTRUCTIONS--PARTS LIST

INSTRUCTIONS

This manual contains important

warnings and information.

READ AND KEEP FOR REFERENCE.

Contractort In-line Valve

- For applying architectural paints and coatings -

Model 244161, Series A (North America)

3600 psi (25 MPa, 248 bar) Maximum Working Pressure

Model 244364, Series A (Europe)

3600 psi (25 MPa, 248 bar) Maximum Working Pressure

Model 244365, Series A (Asia)

3600 psi (25 MPa, 248 bar) Maximum Working Pressure

Table of Contents

Symbols 2......................................

Installation 4.....................................

Operation 6.....................................

Parts 6.........................................

Parts List 12.....................................

Operation 13....................................

Technical Data 14................................

W arranty 16.....................................

Graco Phone Number 16..........................

GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440--1441

Graco Inc. is registered to I.S. EN ISO 9001

2 309315

Symbols

Warning Symbol

WARNING

This symbol alerts you to the possibility of serious

injury or death if you do not follow the instructions.

Caution Symbol

CAUTION

This symbol alerts you to the possibility of damage to

or destruction of equipment if you do not follow the

instructions.

The wallet-sized warning card provided with the Contractor In--line Valve should be kept with the operator at all

times. The card contains important treatment information should a fluid injection injury occur . Additional cards are

available at no charge from Graco Inc.

WARNING

INJECTION HAZARD

Spray from the spray tip, hose leaks or ruptured components can inject fluid into your body and cause

extremely serious injury, including the need for amputation. Splashing fluid in the eyes or on the skin

can also cause can also cause serious injury.

D Fluid injected into the skin might look like just a cut, but it is a serious injury. Get immediate surgi-

cal treatment.

D Do not point the spray tip at anyone or any part of the body.

D Do not put hand or fingers over the spray tip, and do not stop or deflect fluid leaks with your hand,

body, glove or rag.

D Do not “blow back” fluid; this is not an air spray system.

D Always have the tip guard and the trigger guard on the in-line valve when spraying.

D Be sure the trigger safety lever operates before operating the in-line valve.

D Lock the trigger safety lever when you stop spraying.

D Follow the Pressure Relief Procedure on page 4 when you are instructed to relieve pressure;

stop spraying; check, clean, or service any system equipment; or install or change spray tips.

D T ighten all fluid connections before each use.

D Check the hoses, tubes and couplings daily. Replace worn or damaged parts immediately. Perma-

nently coupled hoses cannot be repaired.

D Handle and route hoses and tubes carefully. Keep hoses and tubes away from moving parts and

hot surfaces. Do not use the hoses to pull equipment. Do not expose Graco hoses to temperatures

above 150_F(65_C) or below --40_F(--40_C).

TOXIC FLUID HAZARD

Hazardous fluids or toxic fumes can cause a serious injury or death if the fluid is swallowed or

splashed in the eyes or on the skin or if the fumes are inhaled.

D Know the specific hazards of the fluid you are using.

D Store hazardous fluid in an approved container. Dispose hazardous fluid according to all local,

state and national guidelines.

D Dress appropriately for your application. Wear protective eyewear, noise protection for the ears, a

personal respirator, gloves, and clothing.

RECOIL HAZARD

Due to the high pressure fluid emitted, a strong recoil action may occur when you trigger the in--line

valve. If you are unprepared, your hand could be forced back toward your body or you could lose your

balance and fall, resulting in serious injury.
