Output Capacity

DC IR GB

GPT-12002

GPT-12003

GPT-12004

GPT-12001

Function

200VA

Rear Output

Continuity

200VA AC Test Capacity

7” LCD Color Display

Capacitive Load Testing Capability Up to 47 F

Controllable Ramp Up & Ramp Down Time

Statistic Function

Testing Time Starting From 0.3s

Provide USB Flash Drive Storage Function

Universal Power Input

GPT-12000 Series

AC/DC/IR/GB Electrical Safety Analyzer

AC/DC/IR/GB

Electrical Safety Analyzer

MODEL

7” LCD

GPT 12000CD1DH-

Specifications subject to change without notice.

T F+1-909-399-3535 +1-909-399-0819

T F+604-6111122 +604-6115225

U.S.A. Subsidiary

INSTEK AMERICA CORP.

Japan Subsidiary

TEXIO TECHNOLOGY CORPORATION.

Korea Subsidiary

T F+82-2-3439-2205 +82-2-3439-2207

GOOD WILL INSTRUMENT KOREA CO., LTD.

T F+81-45-620-2305 +81-45-534-7181

GOOD WILL INSTRUMENT CO., LTD.

Global Headquarters

T F+886-2-2268-0389 +886-2-2268-0639

China Subsidiary

Malaysia Subsidiary

GOOD WILL INSTRUMENT (SEA) SDN. BHD.

GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.

T F+86-512-6661-7177 +86-512-6661-7277

GOOD WILL INSTRUMENT EURO B.V.

T F+31(0)40-2557790 +31(0)40-2541194

Europe Subsidiary

Simply Reliable

www.gwinstek.com

www.facebook.com/GWInstek

AC WITHSTANDING

Output-Voltage Range

Output-Voltage Resolution

Output-Voltage Accuracy

Maximum Rated Load

Maximum Rated Current

Output-Voltage Waveform

Output-Voltage Frequency

Voltage Regulation

Voltmeter Accuracy

Current Measurement Range

Current Best Resolution

Current Measurement Accuracy

Window Comparator Method

ARC Detect

RAMP UP (Rise Time)

RAMP DOWN (Fall Time)

TIMER (Test Time)

WAIT TIME

GND

DC WITHSTANDING

Output-Voltage Range

Output-Voltage Resolution

Output-Voltage Accuracy

Maximum Rated Load

Maximum Rated Current

Voltage Regulation

Voltmeter Accuracy

Current Measurement Range

Current Best Resolution

Current Measurement Accuracy

Window Comparator Method

ARC Detect

RAMP UP (Rise Time)

RAMP DOWN (Fall Time)

TIMER (Test Time)

WAIT TIME

GND

INSULATION RESISTANCE

Output Voltage

Output-Voltage Resolution

Output-Voltage Accuracy

Resistance Measurement

Voltage Regulation

Voltmeter Accuracy

Short-Circuit Current

Output Impedance

Window Comparator Method

RAMP UP (Rise Time)

RAMP DOWN (Fall Time)

TIMER (Test Time)

WAIT TIME

GND

GROUND BOND

Output-Current

Output-Current Resolution

Output-Current Accuracy

Test-Voltage

Test-Voltage Frequency

Ohmmeter Measurement Range

Ohmmeter Measurement Resolution

Ohmmeter Measurement Accuracy

Window Comparator Method

TIMER (Test Time)

Test Method

GND

CONTINUITY TEST

Output-Current

Ohmmeter Measurement Range

Ohmmeter Measurement Resolution

Ohmmeter Measurement Accuracy

MEMORY

Single Step Memory

Automatic Testing Memory

INTERFACE

REMOTE, USB host

Rear Output, RS-232C, USB device, SCAN terminal, Signal I/O,

GPIB

DISPLAY

POWER SOURCE

DIMENSION & WEIGHT

0.050kV~5.000kV

±(1% of setting + 5V) [no load]

200 VA (5kV/40mA)

40mA (0.5kV< V 5kV); 10mA (0.05kV V 0.5kV)≦ ≦ ≦

Sine wave

50 Hz / 60 Hz selectable

±(1% + 5V) [maximum rated load -- no load]

±(1% of reading + 5V)

1 A~40.00mAμ

1 A / 10 Aμ μ

±(1.5% of reading + 30 A)μ

Yes

0.1s~999.9s

0.0s~999.9s

OFF, 0.3s~999.9s

0.0s~999.9s

ON/OFF

0.050kV~6.000kV

±(1% of setting + 5V) [no load]

50W (5kV/10mA)

10mA (0.5kV< V 6kV);≦2mA (0.05kV V 0.5kV)≦ ≦

±(1% + 5V) [maximum rated load -- no load]

±(1% of reading + 5V)

1 A~10.00mAμ

0.1 A /1 A /10 Aμ μ μ

±(1.5% of reading + 3 A) when I Reading < 1mA ;μ±(1.5% of reading + 30 A) when I Reading 1mAμ

Yes

0.1s~999.9s

0.0s~999.9s

OFF, 0.3s~999.9s

0.0s~999.9s

ON/OFF

50V~1200V dc

50V

±(1% of setting + 5V) [no load]

Test Voltage Display Range

50V V 100V≦ ≦ 0.1M 10.00GΩ~ Ω

150V V 450V≦ ≦ 0.1M 20.00GΩ~ Ω

500V V 1200V≦ ≦ 0.1M 50.00GΩ~ Ω

Measurement Range / Accuracy

0.1M 1M 5% of reading + 3 count);Ω~ Ω：±( 1 M 50M 5% of reading + 1 count);Ω~ Ω：±(

51M 2G 10% of reading + 1 count)Ω~ Ω：±(

0.1M 1M 5% of reading + 3 count);Ω~ Ω：±( 1 M 500M 5% of reading + 1 count);Ω~ Ω：±(

501M 9.999G 10% of reading + 1 count);Ω~ Ω：±( 10G 50G 20% of reading + 1 count)Ω~ Ω：±(

±(1% + 5V) [maximum rated load -- no load]

±(1% of reading + 5V)

10mA max.

2kΩ

Yes

0.1s~999.9s

0.0s~999.9s

0.3s~999.9s

0.0s~999.9s

ON/OFF

03.00A~32.00A ac

0.01A

3A I 8A : ±(1% of reading + 0.2A);≦ ≦ 8A<I 32A : ±(1% of reading + 0.05A)≦

8Vac max (open circuit)

50Hz/60Hz selectable

1m ~ 650mΩ Ω

0.1mΩ

±(1% of reading + 2 m )Ω

Yes

0.3s~999.9s

Four Terminal

ON/OFF

100mA dc (fixed)

0.10 ~ 90.00Ω Ω

0.01Ω

±(10% of reading + 2 m )Ω

MANU : 100 blocks

AUTO : 100 blocks, Manu per auto : 10

Standard (Front)

Standard (Rear)

Option

7” color LCD

AC 100V~240V ± 10%, 50Hz/60Hz

380(W) x 148(H) x 454(D) mm; Approx. 15kg

≦

SPECIFICATIONS

Produkt Specifikationer

Mærke:	GW Instek
Kategori:	Måling
Model:	GPT-12003
