When the voltage is applied, the
quartz workings only start after a
The full power reserve is only
achieved after 5 days (EHN111,
Setting the current time: Turn the min-
ute hand (6) right or left (Figure05).
Setting the current weekday (only-
EHN171): Turn the switching disk (2) in
the clockwise direction until the correct
number displays the x-th day of the
Define the switching times by press-
ing the switching segments (3) to the
left(ON) or to the right (OFF)
Display of the switching state
The knob (1) turns automatically,
displaying the state of the con-
nected circuit (1: ON/ 0: OFF).
Selecting the operating mode (Fig-
= Auto/ 1 = Continuous ON/
Operating voltage 230 V~, +10 %/-15 % ..............
− EHN111, EHN171 50 - 60 Hz .............................
− EHN110 50 Hz ...................................................
Cycle / shortest switching time:
− EHN110, EHN111 24 hours / 15 minutes ...........
− EHN171 7 days / 2 hours ...................................
− EHN111, EHN171 max.0.5 W ...........................
− EHN110 max.0.9 W ..........................................
Switching capacity 16 A, 250 V~, AC1 ..................
Switching capacity min. 24 V~, 100 mA ................
− ≤ 2 W 20 W ........................................................
− > 2 W 180 W ......................................................
Incandescent/halogen lamps 1100 W ...................
− Compensated 400 VA (max. 42 μF) ...................
− Uncompensated 1100 VA .................................
Compact fluorescent lamps 90 W .........................
− EHN111, EHN171 120 h (230 V) .........................
− EHN111, EHN171 ±1 s/day at +20 °C ...............
− EHN110 Network-synchronous .........................
Conductor cross-section 0,5 - 6 mm² ....................
Miniature circuit breaker 16 A ................................
Contact Change-over contact ................................
Opening width < 3 mm (μ) .....................................
Protection class II ...................................................
Degree of protection IP 20 .....................................
Electrical equipment may only be installed
and assembled by a qualified electrician in
accordance with the relevant installation
standards, regulations, directives and
safety and accident prevention directives
Failure to comply with these installation
instructions may result in damage to the
device, fire or other hazards.
− Daily programme (EHN11x)
− Weekly programme (EHN171)
− For lighting, ventilators, fountains, adver-
tising, etc. in closed, dry rooms
− Mounting on DIN rail TH 35 - 7,5 (accord-
− Switching of any exterior conductor
is permitted, switching of SELV is not
Switching disk to display the switching
Switching segments, each 15’, 2 hrs (only
Clock face for the current time
Switch for operating mode:
= Auto/ 1 = Continuous ON/
Installation and electrical
Electrical shock when live parts
An electric shock can lead to
Isolate all power before work-
ing on the device and cover
any live parts in the area!
Snap the device onto the DIN rail (Fig-
Connect according to wiring diagram
Switch the miniature circuit breaker on
− EHN111, EHN171 –10 °C - +55 °C ....................
− EHN110 -20 °C - +55 °C ....................................
Storage temperature -20 °C - +70 °C .....................
Rated surge voltage .......................................4 kV
Operating altitude < 2000 m ..................................
Contamination level 2 .............................................
− EHN111, EHN171 1 BSTU .................................
− EHN110 1 BRTU ................................................
Correct disposal of this product
(Waste Electrical & Electronic
(Applicable in the European Union and other
European countries with separate collection
The identification shown on the product or its
documentation indicates that it should not be dis-
posed of with other household waste at the end
of its working life. To prevent possible harm to the
environment or human health, please separate this
device from other types of waste. This helps you to
promote sustainable reuse of material resources.
Private consumers are asked to contact the dealer
from whom they purchased the product, or their
municipal administration, to obtain information on
how to dispose the product in an environmental-
ly-friendly manner. Commercial consumers are
asked to contact their suppliers and to check the
general terms and conditions of business of the
purchasing agreement. This product should not be
mixed with other commercial waste for disposal.
La instalación y el montaje de dispositivos
eléctricos deben ser efectuados exclu-
sivamente por personal electricista de
acuerdo con las normas de instalación,
directivas, instrucciones, disposiciones y
normas de prevención de accidentes per-
Si no se tienen en cuenta las indicaciones
de instalación, podría dañarse el equipo,
producirse un incendio o surgir otros peli-
− Interruptor temporizador analógico
− Programa diario (EHN11x)
− Programa semanal (EHN171)
Uso conforme a lo previsto
− Para iluminación, ventilación, fuentes, pu-
blicidad, etc. en espacios secos cerrados
− Montaje en carril DIN TH 35 - 7,5 (segun
− Está permitida la conmutación de cual-
quier conductor exterior, no está permiti-
da la conmutación de SELV
Estructura del dispositivo
Visualización del estado de conmutación
0 = DESCONECTADO / 1 = CONECTADO
