USER MANUAL
Item no. 3043500
CF Lens Adapter
CF Lens Adapter
The CF Lens Adapter (3043500) allows the use of all C-type lenses
from the V System on H cameras. Integral processors for data con-
version bridge the two systems to access a number of the H-display
and lens-control functions. The adapter allows:
• light metering at full aperture.
• electronic focus confirmation on viewfinder display.
• exploitation of databus connection with CFE lenses.
• access to shutter speeds (manually set on lens) from
1s–1/500s including B and T mode.
Functions such as autofocus and continuous drive are an integral
part of the H System only so they are therefore not available when
C lenses are used. Likewise, as the light measuring and aperture/
shutter controls are also different between the two systems, then
camera operation differs too. Some other restrictions also apply
regarding specific lenses or combinations of lenses/converters.
Operation of the adapter is not difficult but requires an awareness
of certain points that contrast with regular H operation. You can
use the adapter immediately by going through the procedures
described under the Quick Start heading but a thorough reading
of this manual is advised to ensure optimum performance.
ENG
The figures beside the headings refer to the relevant illustrations
for that section. Rotation directions are described as seen when
facing the camera.
Please note that the adapter requires firmware version 9.0.0 or later installed
in the camera! (see camera manual for details).
Parts and Components 1
1. Lens locating index
2. Connecting cable
3. Databus connector for CFE lenses
4. Lens cocking lever
5. Adapter locating index
6. Drive shaft
7. Adapter release catch
8. Camera databus connector
Quick start 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12
C-type lenses from the V System have changed over the years in
functionality and appearance. The illustrations therefore show some
variations that might not match the lenses you are using. The later
CFE/i models, for example, have a locking device on the PC flash con-
nector whereas earlier models did not. Please see the relevant user
manual for details.
a. Align the red adapter locating index on the rear of the adapter with the red
index on the camera body (illus 2) and rotate the adapter clockwise until it
clicks into place.
b. Align the index on the lens with the red lens locating index on the adapter
(illus 3) and rotate the lens clockwise until it clicks into place.
c. Attach the connecting cable to the PC socket on the lens (illus 4).
d. The grip LCD on the camera will automatically display the lens and converter
choice screen (such as in illus 5).
e. Rotate the front control wheel to choose the lens and the rear control wheel
to choose the converter (or No converter). For example, 150 mm lens with
‘No converter’, as in illus 6. Finally, press Save (DRIVE button) to store the
setting and automatically access the standard screen.
f. The focal length of the lens chosen (illus 7) as well as a ’X’ symbol for a con-
verter if chosen (illus 8) now appears on the LCD beneath the AF button.
g. Ensure the depth-of-field button on the lens is in the off position, illus 9.
h. When measuring the light, the camera will display setting information
which has to be transferred to the lens, for example 1/60s at f/11 as in illus
10. See relevant lens user manual if you are not familiar with the settings
on C lenses. This procedure varies according to the type of lens:
C/CF/CFi lenses — Rotate the front control wheel on the grip to scroll
through the list of aperture/shutter combinations visible on the grip LCD
and the viewfinder LCD. Transfer the chosen shutter speed / aperture combi-
nation settings (or EV visible on grip LCD) to the lens.
The information in this document is furnished for informational use only, is subject to change without notice, and should not be construed as a commitment by Victor Hasselblad AB. The text and images in this document cannot be reprinted or reused without the express permission of Victor Hasselblad AB. Victor Hasselblad AB assumes no
responsibility or liability for any errors or inaccuracies that may appear in this document. Victor Hasselblad AB assumes no responsibility or liability for loss or damage incurred during or as a result of using Hasselblad products. Copyright © 2013 - Victor Hasselblad AB. All rights reserved.
1/2 Document ID: CF Lens Adapter / 3043500 / User Manual D / V5 / 2013
