Side 1/6

The Dash Monitor Mount bracket system requires two or three main parts that

are Sold Separately. See web site Monitor Conﬁgurator for more detailed

bracket information. http://www.havis.com/monitor_mounts.htm

• 1 - Vehicle Speciﬁc dash mount bracket. (C-DMM-114)

• 1 - Computer Speciﬁc Monitor adaptor bracket. (C-MM-200 series)

• 1 - Oﬀset adaptor bracket. (C-MM-301)

The C-MM-301 oﬀset adaptor goes between the C-DMM-114 and C-MM-2XX.

It may not be required in some applications.

TOOLS REQUIRED:

• Ratchet Wrench

• Socket Set

• Open End Wrenches - 7/16”, 1/2”

• Phillips Screwdriver (short)

HARDWARE:

QTY: DESCRIPTION: PART #:

2 1/4” x 3/4 Hex Bolt GSM33001

2 1/4” Flat Washer GSM31005

2 1/4” Nylon retaining washer GSM31322

6 1/4-20 Hex Flange Serrated Nut GSM30023

4 10/32 x 1/2 Flat Head Machine Screw GSM33072

4 Rubber Bumpers (stick on) GSM19802

1 Monitor Adapter Hardware Varies (monitor speciﬁc)

ALWAYS!

• Read all instructions before installing any Havis, Inc products.

• Use hardware provided with install kit

Note:

The swing door utilizes a gas spring to assist in opening the door and to eliminate the

possibility of it slamming shut. If additional damping is desired because of heavier equipment, an

optional stronger gas spring is available under Part Number CM86662-30 (sold separately)

Installer must change out gas spring as needed.

INSTALL INSTRUCTIONS

C-DMM-114

2007-2014 TAHOE SWING-OUT DASH MONITOR MOUNT

C-DMM-114_INST_4-10 rev 9-13

C-DMM-114

Assembly for Tahoe

C-MM-201

Monitor Mount Adaptor

(VESA bracket shown)

C-MM-301

Oﬀset Adaptor
