Side 1/6

C-DMM-122_INST_REV-9-13

INSTALLATION INSTRUCTIONS

C-DMM-122

2013-2017 Ford Interceptor Sedan

SWING-OUT DASH MONITOR MOUNT

** Does NOT work in Interceptor Sedan with Interior Upgrade Package (Code 12P) **

Always!

 Read all instructions before installing any Havis, Inc. products.

 Check for obstructions (Wires, brake lines, fuel tank, etc.) before drilling any holes!

 Use hardware provided with install kit

The Dash Monitor Mount bracket system requires two or three main parts that are sold

separately. See web site Monitor Configurator for more detailed bracket information.

http://www.havis.com/monitor_mounts.htm

 1 - Vehicle Specific dash mount bracket. (C-DMM-122)

 1 - Computer Specific Monitor adaptor bracket. (C-MM-200 series)

 1 - Offset adaptor bracket. (C-MM-301)

The C-MM-301 offset adaptor goes between the C-DMM-122 and C-MM-2XX.

It may not be required in some applications.

Docking stations for tablet applications can be bolted directly to C-DMM without adaptor. Offset

adaptor C-MM-303 is available if additional positioning options are desired for docking station.

TOOLS REQUIRED:

• Ratchet Wrench Jig Saw or Plastic cutting tool

• Socket Set Dash panel removal tools

• Open End Wrench - 7/16” Open End Wrench – 10mm

• Phillips Screwdriver

HARDWARE and PARTS:

QTY: DESCRIPTION: PART #:

1 Upper Support Bracket CM005091

1 Lower Support Bracket CM005131

2 1/4" x 1/2” Carriage Bolt GSM31999

2 1/4"x 1/2" Pan Head Phillips Bolt GSM33124

2 1/4" Serrated Flange Hex Nut GSM30023

4 1/4” Flat Washer GSM31005

4 1/4” Lock Washer GSM31026

2 6mm x 30mm Hex Bolt GSM33713

1 Monitor Adapter Hardware Included with C-MM-2XX kit

Note: The swing door utilizes a gas spring to assist in opening the door and to eliminate the possibility of

it slamming shut. If additional damping is desired because of heavier equipment, an optional stronger gas

spring is available under Part Number CM86662-30 (sold separately)

Installer must change out gas spring as needed
