INSTALL INSTRUCTIONS

C-DMM-2002 Dash Monitor Mount

2013-2017 Police Interceptor Sedan Standard Interior and

Interceptor with Interior Upgrade Package (Ford option code ) 12P

Notes:

1. The C-DMM-2000 series Dash Monitor Mount brackets are speciically designed to work with

Havis, Inc, model # TSD-101 Touch Screen Display.

2. The display mount bracket includes a VESA 75 hole pattern that can also be used for some light

weight tablet docking station applications under 5 lbs. . Acceptable positioning must be

determined by end user.

3. 2002 The C-DMM- will work with all Havis, Inc. consoles made for the Interceptor Sedan.

4. 2002 The C-DMM- Does NOT work in the Retail Taurus sedan.

TOOLS REQUIRED: ( ) some tools are not needed for all vehicle installations

• • 1.5” hole saw • Tape measure Socket set - metric & standard • Drill & drill bits

• • • Pencil / Marker

Phillips screwdriver Trim removal tools

MOUNT BRACKET PARTS and HARDWARE:

Installation parts with * come loose in hardware kit bag. Other parts are preassembled

QTY: DESCRIPTION: PART #:

1 Main dash mount bracket -0280- MT SM

1 Pivot / display mount bracket -0269 * MT -SA

1 Tilt swivel hinge GSM22005

2 M6 x 30mm Hex head bolt GSM33773 *

1 hex nut GSM30113 M8 SS

1 M8 lock washer SS GSM31217

2 GSM34432 #10 x ¾” Hex head self tapping screw

4 GSM20016 ¾” Dome Plug

1 Vinyl cap - .375 id) GSM41127 (.50” high x .312

1 Stop bracket -0291- MT SM

2 M5 x 10mm Thread forming screw GSM33774

2 GSM20091 Grommet (1.75” wide)

2 Pull through bumper (3mm head) GSM21109

2 Push in bumper (10mm head) GSM21108

3 8-32 x ss head machine screw GSM34077 * .312” Phillips tru

C-DMM-2001_INST_1-16

C-DMM- assembly 2002

ALWAYS!

• Read all instructions before installing any Havis, Inc products.

• Use hardware provided with install kit

GSM30113

GSM41127

GSM22005

MT-0269-S * A

GSM31217

GSM20091

GSM * 20016

GSM34432 *

GSM33773 *

MT-0291- with SM

GSM21108

MT-0280- SM
