Side 1/12

Owner’s Manual

Havis Rugged Mobile Docking Station

For Panasonic CF-54 Toughbook

DS-PAN-420-SERIES_OMN_4-15

www.havis.com

1-800-524-9900

DS-PAN-421

DS-PAN-421-2

DS-PAN-422

DS-PAN-422-2

DS-PAN-423 PKG-DS-PAN-422

PKG-DS-PAN-422-2

DS-PAN-420 Series

Havis, Inc.

75 Jacksonville Road, PO Box 2099

Warminster, PA 18974

www.havis.com 1-800-524-9900

DS-DA-417

Screen Support

Secure your laptop screen to prevent excess wear

and reduce vibration while in use.

Related Products

Havis oﬀers a wide variety of accessory products specically for use

with the DS-PAN-420 Series Docking Station. For more information or

to order, please visit www.havis.com.

LPS-112

120W Power Supply

External power supply and cable for Panasonic

CF-54 Toughbooks with cigarette lighter adaptor.

LPS-204

Power Supply Mounting Bracket

Mount the LPS-112 Power Supply directly to your

Docking Station.

DS-DA-226

Card Reader Mounting Bracket

Mount an E-Seek Model 250 card reader to the side

of the Docking Station.

(Bracket can be customized for other Card Reader Models)

DS-DA-501

Replacement Keys

Set of two (2) replacement keys for

the DS-PAN-420 Series Docking Stations.

DS-DA-602

Rugged Communication Hub

Rugged USB/Ethernet hub makes adding peripherals

to your mobile workspace easy and safe.

www.havis.com • 1-800-524-9900

DS-PAN-421

DS-PAN-421-2

DS-PAN-422

DS-PAN-422-2

DS-PAN-423 PKG-DS-PAN-422

PKG-DS-PAN-422-2

Before Beginning

(Original Instructions)

2 11

• NEVER STOW OR MOUNT THE DOCKING STATION DIRECTLY IN A VEHICLE

AIRBAG DEPLOYMENT ZONE.

• DO NOT USE COMPUTER WHILE DRIVING.

• READ ALL INSTRUCTIONS THOROUGHLY BEFORE BEGINNING INSTALLATION.

• DO NOT CONNECT PERIPHERALS

(USB, ETHERNET, POWER IN) SIMULTANEOUSLY

TO COMPUTER AND DOCKING STATION WHEN COMPUTER IS DOCKED OR

DAMAGE MAY OCCUR.

Havis is pleased to provide this Owner’s Manual to aid in the proper

installation and use of the DS-PAN-420 Series Docking Station for

the Panasonic CF-54 laptop computer.

For questions regarding the set-up of your DS-PAN-420 Series Docking Station,

please contact Havis at 1-800-524-9900 or visit www.havis.com for additional

product support and information.

This Owner’s Manual applies to the following Part Numbers:

• THE DS-PAN-420 SERIES DOCKING STATIONS ARE DESIGNED EXCLUSIVELY FOR USE

WITH PANASONIC CF-54 TOUGHBOOK COMPUTERS ONLY AND ARE NOT BACKWARD

COMPATIBLE WITH THE PANASONIC CF-52 OR CF-53 COMPUTER.

• DS-PAN-420 SERIES DOCKING STATIONS ARE COMPATIBLE WITH ALL MODELS

OF THE CF-54 COMPUTER (LITE, PRIME, PERFORMANCE, OR GLOVED MULTI TOUCH).

• FOR DOCKING STATION MODELS EQUIPPED WITH A BUNDLED POWER SUPPLY

(DS-PAN-422, DS-PAN-422-2, PKG-DS-PAN-422, PKG-DS-PAN-422-2), REFER TO THE SUPPLIED

LIND POWER SUPPLY REFERENCE GUIDE.

• WHEN LAPTOP IS DOCKED, THE BATTERY WILL ONLY CHARGE BETWEEN

-2°C to 60°C (28°F to 140°F).

PLEASE REFER TO PANASONIC CF-54 OWNER’S MANUAL FOR MORE INFORMATION.

Optional Accessories (continued)

DS-DA-417 - Screen Support

(For further Installation Instructions, refer to the Instructions included with DS-DA-417)

1) Position the Screen Support bracket so the mounting holes line up with

threaded holes at bottom (rear left corner) of Docking Station.

2) Install two (2) #8-32 x 3/8” screws through the bracket and into

Docking Station. Torque screws to 20 in-lbs ± 10%.

3) Dock your computer in the Docking Station and open display latch on

Screen Support.

4) Open computer screen to meet the stop bumper on Screen Support.

5) Press slightly on top left corner of computer screen while closing the

display latch of Screen Support over the computer screen.

6) While pulling on knob of adjustment pin, adjust arm of Screen Support

with screen to desired position.

Open Closed

OpenOpen

ClosedClosed

LPS-204 - Power Supply Mounting Bracket

(For further Installation Instructions, refer to the Instructions included with LPS-204)

1) Orient Lind Power Supply so the cords are rear facing.

2) Select the desired side of mounting. Insert four (4) 6-32 x 1 1/4” screws through

the washers and Lind Power Supply, through Mounting Bracket. Torque screws

to 25 in-lbs ± 10%.

3) Remove the two (2) 1/4”-20x3/8” screws from the Docking Station and insert

them through the holes in the Mounting Bracket.

4) Attach the Mounting Bracket and Lind Power Supply to the Docking Station

with the two (2) 1/4”-20x3/8” screws. Torque screws to 80 in-lbs (9.0 Nm) ± 10%.

Produkt Specifikationer

Mærke:	Havis
Kategori:	Computertilbehør
Model:	DS-PAN-421
Bredde:	348 mm
Dybde:	76 mm
Højde:	384 mm
Vægt:	2449.4 g
Produktfarve:	Sort
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte:	2
Ethernet LAN:	Ja
Driftstemperatur (T-T):	-20 - 60 °C
Forbindelsesteknologi:	Docking
DC-in-stik:	Ja
Strømkilde type:	DC
Indbygget kortlæser:	Ingen
Mikrofonindgang:	Ingen
Antal VGA-porte (D-sub):	2
