10/17 Page Model 8300.158 1 of 5

No. 2080167(15)

1455 Kleppe Lane  Sparks, NV 89431-6467 (775) 359 Fax (775) 359-4712 -7424

E-mail: haws@hawsco.com  website: www.hawsco.com

Model 8300.158 Combination

Shower Eye/Face Wash

INSTALLATION, OPERATION

MAINTENANCE INSTRUCTIONS

LIMITED WARRANTY

HAWS warrants that this specific product is guaranteed against defective material or poor

workmanship for a period of one year from date of shipment. HAWS liability under this

warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any goods,

or part thereof, which shall appear to the Company upon inspection to be of defective

material or not of first class workmanship, provided that claim is made in writing to Haws

within a reasonable period after receipt of the product. Where claims for defects are made,

the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS

ill not be liable for the cost of repairs, alterations or replacements, or for any expense

connected therewith made by the owner or his agents, except upon written authority from

HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by defective

materials or poor workmanship, except for replacements, as provided above. Buyer agrees

that Haws has made no other warranties either expressed or implied in addition to those

above stated, except that of title with respect to any of the products or equipment sold

hereunder and that HAWS shall not be liable for general, special, or consequential

damages claimed to arise under the contract of sale.

The emergency equipment manufactured by HAWS is warranted to function if installation

and maintenance instructions provided are adhered to. The units also must be used for the

purpose for which they were intended. This product is intended to supplement first-aid

treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this

emergency

equipment will prevent serious injury or the aggravation of existing or prior

injuries.

NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED

OR GIVEN BY HAWS.

NOTE TO INSTALLER: Please leave this information with the Maintenance Department.

SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS

MODEL PLEASE CALL:

TECHNICAL SUPPORT: 1- - - 800 766 5612

FOR CUSTOMER SERVICE: 1- - - 888 640 4297

10/17 Model 8300.158 Page 2 of 5

LOCATION OF UNIT: The Model 8300.158 Emergency Shower should be installed in

close proximity to potential accident areas. It should be clearly identified, free from

obstructions and easy to access.

SUPPLY LINE: The minimum recommended line size is 1 1/4” IPS with 30- -90 psi (2 6

ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter

is recommended.

PLUMBING CONNECTIONS: Inlet supply is female 1 1/4” IPS. Waste outlet is female

1 1/4” NPT.

MAINTENANCE: In freezing conditions, wipe eye/face wash head and dust cover dry

after each use to prevent unwanted ice build up.

NOTE: To minimize excessive spillage from air gap when testing, unit must be opened

and closed completely with one continuous motion. swift

INSTALLATION PROCEDURE

Refer to Installation Drawing for clarification. Check parts list to insure all required parts are

included. Use pipe joint sealant PST #565 (Loctite) on all connections.

STEP 1: Prepare the emergency shower foundation by using the floor flange assembly as

a template. Loc 16 UNC x 6” anchor bolts (not ate the three holes for the 3/8

supplied). They should extend 1” above the floor level.

STEP 2: Once the concrete foundation is ready (dry), assemble the floor flange assembly

to the anchor bolts 16 UNC Hex nuts and 3/8” ; then securely fasten with 3/8

washers (not supplied). Seal and tighten floor flange and tee making certain the

waste tee is facing the proper location (as shown in installation drawing) and the

foot control holes are facing side to side.

STEP 3: Assemble nipple (1 1/4” x 21 1/2”) to the floor flange assembly and tighten with a

pipe wrench.

STEP 4: Assemble the eye/face wash loop assembly to the 21 1/2” nipple from step three.

Connect the pipe wrench to the galvanized nipple between the two tees to avoid

damage.

STEP 5: Assemble in the following order:

Attach nipple (1 ” 1/4 x 24”) to loop assembly.

Attach coupling 1/4(1 ”) to nipple.

Attach nipple (1 1/4” x 24) to coupling.

Attach tee (1 1/4” ” x 1 1/4 x 1”) to nipple.

Attach nipple (1” x Close) to tee.

Attach ball valve/handle assembly to nipple. Note: Refer to installation

Drawing (Sheet 5 of O&M) for correct orientation of ball valve.

Attach nipple (1” x 19 ”) to ball valve/handle assembly.1/2

Attach elbow (1”) to nipple and attach showerhead to elbow.

STEP 6: Assemble the (1”) elbow onto the horizontal nipple (1” x 19 ½”), and attach the

showerhead onto the elbow.
