Side 1/1
Mic Input Any Lo-Z balanced microphone, female XLR
Mic Output Line or Mic level, Lo-Z, balanced, male XLR
Mic Pre gain 30-50 dB, adjustable via rear panel Gain trim
Local, Return Inputs -10 dBu to +4 dBu, 20K bal or 10K unbal, ¼” TRS jack
Link I/O Links multiple units with cat5 cable, distributes Power,
Local, Return audio to all units.
MODE switch Selects split-mono or stereo headphone audio
LOC switch Selects Local input or Mic preamp as Local source
Headphone Output >24 ohms, ¼” and 3.5mm jacks provided
MultiPhones Master unit or SixMix USB audio console,
PowerPod, or MultiPhones Master
Specifications subject to
change without notice.
REV A 2021
and pan settings. Multiple Talent Pod IIs can be quickly linked with cat5
cables, distributing Power, Local and Return headphone audio to all units
and eliminating the need for multiple power sources, DAs and complicated
wiring. Talent Pod IIs can be used by themselves or integrated with Henry
Engineering’s MultiPhones system or with Sports Pods/Mini Pods/Guest
Pods.
The Talent Pod II also includes a mic preamplifier, which can be used to add an
additional mic input to a mixer or used with a codec that has no microphone
input and/or monitor jack. The LOCal button (on rear) allows the output of
the mic preamp to be used for local monitoring (via the Local volume control)
when doing a “single-mic” broadcast without a mixer. If the Local audio
source is stereo (as in a studio environment) the MODE button can select
Stereo operation, with both headphone channels controlled by the Local
Volume control.
Talent Pod IIs can be powered with a MultiPhones Master unit, Power Pod,
or an external wall transformer (not included). One power source will operate
several units linked with cat5 cables. An optional retractable Desk Mount
stand is available. Talent Pod II is 1/3 rack width, and can be rack mounted
using the optional Rack Shelf. It can also be wall or cabinet mounted using
optional wall/cabinet mounting brackets.
TALENT POD II
Product Description
MIC & HEADPHONE CONTROLLER
The Talent Pod II is an announcer’s mic and headphone controller for use by
talent at a remote broadcast. It is ideal for use at sporting events and on-
location broadcasts. Talent Pod II solves the problem of providing talent with
a mix Local and Return (IFB or “back- haul”) audio for their headphones. Its
simplicity allows for error-free use by non-technical users, and it provides a
simple way to link several units when a broadcast requires multiple announcers.
The Talent Pod II provides the announcer a convenient way to turn his mic on
and off and control his headphone audio. There is a large illuminated Mic On/
Off button and also a Cough button which momentarily mutes mic audio. Mic
audio is switched on and off electronically without any pops or clicks.
The Talent Pod II also provides control of the announcer’s headphone audio,
allowing remote-site Local audio to be mixed with the Return audio that’s sent
to the site from the main studio. There are separate inputs for Local and Return
audio with a Volume control for each source, so the talent can adjust the mix
in his headphones. To minimize confusion between the two, Talent Pod II’s two
Pan switches can independently position Local and Return audio in the Left,
Center, or Right channel of the announcer’s headphones.
For broadcasts with multiple announcers, several Talent Pod IIs can be used
so that each announcer can control his own mic, headphone volume, mix,
Front
Back
Technical Specifications Typical Application
PO Box 3796
Seal Beach, CA 90740
TEL: 562-493-3589
www. henryeng.com
TM
MIC MIXER
Announcer
1
Talent Pod
Announcer
2
Talent Pod
Announcer
3
Talent Pod
Mic Out
Mic Out
Mic OutMic
Inputs
PGM Out
RTN
TO STUDIO RETURN FROM
STUDIO
MON
Cat 5
LOC
Cat 5
Rack Mountable
