Elettromedia - 62018 Potenza Picena (MC) Italy - T +39 0733 870 870 - F +39 0733 870 880 - elettromedia.com
hertz-audio.com
All Specifications Subject to Change Without Notice_23.A
1. Up to 87% efficiency thanks to ADC (Advanced D-Class) output stage.
2. USS (Universal Speakers Simulators) allows SP 4.500 to work with head units
featuring the “speaker load detection” circuit.
3. 90 W RMS x 4 (4Ω) with ultra-compact size: 192.7 x 130 x 49 / 7.59 x 5.12 x 1.93
(mm/inch)
agents.
5. No cooling fan to prevent internal accumulation of dirt.
6. Sealed power cord, line inputs and speaker outputs to prevent oxidation.
7. Crossovers filters and controls on a single side to facilitate calibration when the
product is installed.
8. Balanced fully-differential high-noise rejection inputs.
9. ART (Automatic Remote Turn-On/Off) automatically turns on/off theamplifier
when the OEM head-unit turns on/off (can be enabled/disabled).
SP 4.500
D-CLASS MONO AMPLIFIER
600 W
A185.7 mm 7.31 in.
B192.7 mm 7.59 in.
C107 mm 4.21 in.
D130 mm 5.12 in.
E49 mm 1.93 in.
Sealed connectors
E
POWER SUPPLY
Nominal power supply voltage 11 15 VDC ÷
Pulse Operating voltage 6 16 VDC÷
Idling current 1.1 A
Idling current when off 0.03 mA
Consumption @ 14.4 VDC, MIN load
impedance (Max Musical Power)
27 A
Remote IN 6 15 VDC (9 mA)÷
DC-REM - Remote Turn on by SPK DC
from BTL speakers outputs
3.5 7 VDC÷
AMPLIFIER STAGE
Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power <0.02%
Damping factor @ 1 kHz, 4Ω, 2 VRMS >150
Bandwidth @ -3 dB 10 Hz 35 kHz÷
S/N ratio (A weighted @ 1 V Input) 100 dBA
Pre-In sensitivity 0.6 6 VRMS÷
Speaker-In sensitivity 2.2 22 VRMS÷
Minimum load impedance
@ 4Ch: 2Ω
@ 3Ch: 2Ω + 2Ω + 4Ω
@ 2Ch: 4Ω
Output power (RMS) @14.4 VDC, 1% THD:
4Ch 90 W x 4 (4Ω)
4Ch 150 W x 4 (2Ω)
3Ch 80 W x 2 (4Ω) + 330 W x 1 (4Ω)
3Ch 145 W x 2 (2Ω) + 300 W x 1 (4Ω)
2Ch 300 W x 2 (4Ω)
INPUTS / OUTPUTS / FILTERS
Inputs Pre IN / Speaker IN
Filters:
Full
Hi-pass: 50 5k Hz @ 12 dB/Oct.÷
Lo-pass: 50 5k Hz @ 12 dB/Oct.÷
Filters:
Full
Hi-pass: 50 5k Hz @ 12 dB/Oct.÷
Lo-pass: 50 5k Hz @ 12 dB/Oct.÷
Bass Boost 45Hz (adjustable) OUT 3 - 4 (0 8 dB) [LP = ON only]÷
CEA SPECIFICATION
Output power @ 4Ω
1% THD+N, 14.4 V
75 W x 4 Ch
SN ratio (ref. 1 W output) 81 dBA
SIZE / WEIGHT
Max size (mm/inch) 192.7 x 130 x 49 7.59 x 5.12 x 1.93/
Weight (kg/lbs) 1.9 4.18/
GENERAL
IP Rating IP55
Operating Temperature Range 0°C (32°F) to 55°C (131°F)
Maximum versatility
