Side 1/6

H-racer 2.0

ASSEMBLY GUIDE

To avoid the risk of property damage, serious injury or death:

Model No.: FCJJ-23

This kit should only be used by persons 12 years old and up, and only under the supervision of adults who

have familiarized themselves with the safety measures described in the kit. Keep small children and

animals away, as it contains small parts that could be swallowed. The fuel cell generates gases that are

very easily ignited. Read the instructions before use and have them ready for reference.

Warning

Battery operation instructions:

1. The removing and inserting of batteries is to be conducted by the adults only.

When inserting the batteries make sure that you are doing so with the correct polarity (the positive end of

the battery must match up with the “+” and the negative end of the battery must match up with the “-”

indicated on the battery pack) and then close the battery compartment.

2. Non-rechargeable batteries are not to be recharged.

3. Different types of batteries such as rechargable, alkline and standard batteries or new and used batteries

are not to be mixed and should be used separately.

4. The two spare red&black cables are not to be inserted into an AC socket.

5. Exhausted batteries are to be removed from the battery compartment.

Connect one end of the flexible tubes to the lower

nozzle on the storage cylinder and the other end of

the flexible tube to the nozzle on fuel cell located

nearest to the motor. Connect the other end of the

flexible tube on the refueling input valve to the other

nozzle located on the fuel cell. Connect the purging

valve tube to the upper nozzle located on the storage

cylinder. Make sure all tubes are properly positioned

as in diagram.

Warning: Make sure these connections are

correct. Any other connection will not allow

proper operation of the car and its fuel cell

power system. Also ensure the wires are not

touching the wheels and the

tubes are not kinked or

pinching.

ASSEMBLY GUIDE

H-racer 2.0

What do you need?

H-Racer 2.0

AA batteries=2 Units LR44 batteries=3 Units

Water=25ml

Connect one of the flexible tubes to the small purging valve. Make

sure the tube is inserted all the way into the base of the purging valve

nozzle.

Connect another flexible tube to the nozzle of the refueling input valve.

Make sure the tube is inserted all the way into the base of the nozzle

of the refueling input valve.

Position the fuel cell onto the square slot located in the middle

of the car chassis. The positive mark on the fuel cell should be

positioned on the side with the red cable, and the negative

mark on the side with the black cable. Push the fuel cell into

the chassis.

Position the black cable terminal between the fuel cell holder

and the fuel cell end plates, and position the red cable terminal

in the same manner on the opposite side. Make sure the holes

are aligned.

Align the fuel cell holder with the two holes on the car chassis.

Place the screws into the screw holes and make sure the

screws are entered through the cable terminal holes and

straight into the chassis.

*Please note there are two types of screws. The smaller

screws are used for the fuel cell and the larger screws are

used for the car body.

Use a screwdriver to attach the fuel cell end plate and the red

& black cable terminals to the screw holes on the chassis.

Make sure the metal terminals from the cables are closely

touching the fuel cell end plates. Do not tighten the screws

until the two screws are partially entered into the chassis.

Drive the screws into the chassis making sure all the parts are

connected tightly without moving.

Force is required to drive these

screws into place, to avoid

damage to the kit ask an adult

to drive in the screws.

TIP: To fit the flexible tubes onto the nozzle of the valve, connect the tube

by twisting it against the nozzle, then push the nozzle into the tube until the

tube is snuggly fitted to the base of the nozzle.

Place the refueling input valve above the opening

on the left side of the chassis. Make sure the red

cable is positioned above the refueling input valve

tubing. Slide the refueling input valve onto its

mount located at the opening on the side of the

chassis. With a downward motion, click the valve

into place ensuring it is smoothly aligned with the

outer surface of the chassis.

Place the purging valve above the opening on the

right side of the chassis. Slide the purging valve

onto its mount located at the opening on the side

of the chassis. Make sure the refueling valve tube

is not in the way of the purging valve tubing. With

a downward motion, click the valve into the slot on

the chassis. Make sure that the whole body of the

purging valve is positioned in the slot on the

chassis and the purging button is positioned

outside the edge of the chassis.
