HuddleCamHD HCM-2 Manual

HuddleCamHD Videokonferencesystem HCM-2

Læs gratis den danske manual til HuddleCamHD HCM-2 (2 sider) i kategorien Videokonferencesystem. Denne vejledning er vurderet som hjælpsom af 23 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 12 anmeldelser. Har du et spørgsmål om HuddleCamHD HCM-2, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

Step 2

For masonry or drywall wall:

Place included anchors (Fig 1, #1) in wall and

mount to anchors using included #10 sheet

metal screws. (Fig 1, #2)

For double gang electrical box:

Mount to box using #6 machine screws and

washers. (Fig 1, #3)

What s Included’

QTY —Large Wall Mount BK/WH1

QTY — x 1" Conical Plastic Anchor 1/4" Drill Size (Fig 1, #1)4 10-12

QTY — x 1 1/4" PPH Sheet Metal Screw with Flat Washer (Fig 1, #2)4 #10-16

QTY — x 1" PPH Machine Screw (Fig 1, #3)4 #6-32

QTY — PPH and QTY — Machine Screw Flat Washer (Fig 1, #4)4 1/4”-20x 3/8” 2 1/4”

Fig 1

Rev 2.2

8/212020

HCM 2-

Large Base Camera

Wall Mount

Setup Guide

Mounng Instrucons

Step 1

For masonry or drywall wall:

Posion Large wall mount (Fig 2) on wall and

mark wall for anchor placement (Fig 2, # 1). Pre-

drill 1/4" holes, minimum deep. 1”

For double gang electrical box:

Posion over box with slots overlaying device

mounng holes (Fig 2, #1) on box.

For more informaon on HuddleCamHD

mounts and other products please visit:

hps://huddlecamhd.com Rev 2.2

8/21/2020

HuddleCamHD

HC12X HUDDLEVIEW-

HC20X SIMPLETRACK2-

Generaon 1 USB 3.0 HuddleCamHD cameras

Step 4

Mount Camera to mount (Fig 2, #3) with

included 1/4 20 machine screw. (Fig 1, # -

Ulize (0,1,2) machine screw at 1/4”

washers as required. (Fig 1, #4) Note: 1/4”

machine screw at washers are to be

used depending upon depth of thread in-

sert in base of camera, in order to achieve

a snug t. Pass all cables through opening

in mount (Fig 2, #2) and connect.

Mounng Instrucons Connued...

Mount Compability

Step 3

Drill hole in wall through rear exit opening for

cable access, or use base exit opening. (Fig 2, #2)

Other Cameras…

This mount has been

designed for use with most

large based cameras ulizing

a 1/4 20” -mounng hole as

can be found on SONY,

Panasonic, Cisco, Polycom

and Vaddio cameras.
