Installing one-piece compression BNC and right angle connectors
just got easier. No more uncertainty when inserting the cable into the
connector. No more collapsed center pins. No more wasted connectors
and rework time on the job.
With the patented InSITE® Technology feature, now standard on our
BNC and right angle (90°) compression connectors, field termination of
these blind entry connectors is simpler, faster and now provides a higher
performance connection for all applications from CCTV to HD Video.
The InSITE® window is a 360° clear window which allows the installer
to verify that the prepped cable has been inserted far enough into the
connector to make contact with the fixed pin. The cable, which requires a
1/4“ x 1/4“ industry standard preparation, is inserted into the connector
until the folded braiding is visible within the InSITE ® window. No
measuring, no jacket marking, no guesswork.
In addition to the InSITE® feature, other improvements include:
• Increasedcompatiblerangesofcablejacketdiameters
• Lowercableinsertionforce
• Aredesignedfunneledpinentry-centersangledpins
• Accepts23-18AWGsolidcenterconductorpins
• Smootherandeasiermatingwithsocketsthroughincreased
BNC head travel range
• Betterreturnlossperformance:>35dBupto1GHz,>25dB
upto2GHz,>20dBupto3GHz
Improved contact accepts
23-18AWGsolidcenterconductors
External color band for
series identification
Patented 360° InSITE®
clear window for
confident insertion
Patented compression sleeve adapts
toawiderangeofcablesizes
Weatherproof
back seal
Funneled entry centers
angled pins
Nickel plated brass
body
Goldplatedxedpin
will not fall out
Extended head travel
range to ensure plug to
socket mating
Multiple
compression
surfaces
New dielectric design for
improved RF performance
