Side 1/65
250 Pro Instruction manual
International edition
Rev 1.0 - April 2016
‘Living Manual’
Table of Contents
Table of Contents
Living Manual
Thank You!
Getting Started, ARF Version
The Anatomy of a Vortex
Connectors and Switches
Connector Part Numbers and Sources
Arm Assembly
Camera Mounting Plate
Flight Camera
GoPro Camera Mount
Lost Model Alarm
The On Screen Display (OSD)
The Welcome Screen
The Main Menu
The LED Setup Menu
The Flight Controller Menus
The Video Tx Menu
Flight Controller
R/C Transmitter Control Modes
Flight Modes
Betaflight / Cleanflight / Baseflight / Multiwii / Open-Source
Cleanflight Configurator Connection
2
9) XT-60 Battery Connector
The pre-installed XT-60 connector is compatible with most batteries of the size and
capacity in the class required by the Vortex.
Note: Pay EXTREME attention to the polarity of batteries connected to this
connector, especially those soldered ‘DIY’. A reverse-polarity connection, even for
a fraction of a second will let out the ‘magic smoke’ and destroy most of the
electronics in the Vortex.
Also Note: When unplugging the battery, especially one with a new, and rather tight
connector, take care to hold the cables, and avoid unnecessary strain on the Vortex
PDB. Pulling these cables too hard may pull the traces off of the PCB.
Connector Part Numbers and Sources
If any of the connectors on the Vortex 250 Pro are damaged, or if 3rd party components are to
be integrated into the system, the following list of connectors and pre-crimped wires should
be useful.
Cable
Description
Manufacturer’s PN
Digikey PN
ESC Signal Connector
Picoblade 2 pin
0510210200
WM1720-ND
FUN/GPS Signal Connector
Picoblade 5 pin
0510210500
WM1723-ND
Camera Signal Connector
Picoblade 3 pin
0510210300
WM1721-ND
Picoblade Signal Wires
(all Picoblade connectors)
Picoblade
0006660013
WM2320-ND
14
18
