Side 1/48

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 4

Cutting off the water or electricity supply

Cleaning the washing machine

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 5

General safety

Disposal

Description of the washing machine

and starting a wash cycle, 6-7

Control panel

Indicator lights

Starting a wash cycle

Wash cycles, 8

Table of wash cycles

Personalisation, 9

Setting the temperature

Setting the spin speed

Functions

Detergents and laundry, 10

Detergent dispenser drawer

Preparing the laundry

Garments requiring special care

Load balancing system

Troubleshooting, 11

Service, 12

IWD 61451

Instructions for use

WASHING MACHINE

English, 1

GB FR NL

Français,13 Nederlands,25

Deutsch,37

Installation

! This instruction manual should be kept in a safe

place for future reference. If the washing machine

is sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they contain

vital information relating to the safe installation

and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washing machine from its packaging.

2. Make sure that the washing machine has

not been damaged during the transportation

process. If it has been damaged, contact the

retailer and do not proceed any further with the

installation process.

3. Remove the pro-4

tective screws (used

during transportation)

and the rubber washer

with the corresponding

spacer, located on the

rear part of the applian-

ce ( ).see figure

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will need

them again if the washing machine needs to be

moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washing machine on a flat sturdy

floor, without resting it up against walls, furnitu-

re cabinets or anything else.

2. If the floor is not

perfectly level, com-

pensate for any une-

venness by tightening

or loosening the

adjustable front feet

( ); the angle see figure

of inclination, measu-

red in relation to the

worktop, must not

exceed 2°.

Levelling the machine correctly will provide

it with stability, help to avoid vibrations and

excessive noise and prevent it from shifting

while it is operating. If it is placed on carpet or

a rug, adjust the feet in such a way as to allow

a sufficient ventilation space underneath the

washing machine.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it to

a cold water tap using

a ¾ gas threaded con-

nection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the inlet

hose to the washing

machine by screwing

it onto the correspon-

ding water inlet of the

appliance, which is si-

tuated on the top right-

hand side of the rear

part of the appliance

(see figure).

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details

table (see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	IWD 61451 C ECO EU
Bredde:	595 mm
Dybde:	535 mm
Højde:	850 mm
Vægt:	66500 g
Produktfarve:	Hvid
Indbygget skærm:	Ja
Pakkedybde:	590 mm
Pakkebredde:	645 mm
Pakkehøjde:	890 mm
Energieffektivitetsklasse (gammel):	A+
Strømforbrug (standby):	8 W
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Tromlekapacitet:	6 kg
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	16
Støjniveau (centrifugering):	79 dB
Støjniveau (vask):	60 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Hygiene/anti-allergy, Black, Hand/wool, Intensive/outdoor, Jeans/denim, Shoes, Sport, Delicate/silk
Årligt energiforbrug vask:	196 kWh
Tromle volumen:	52 L
Dør farve:	Hvid
Spin-tørre klasse:	B
Årligt vandforbrug vask:	8643 L
Overløbsbeskyttelse:	Ja
