Washer-dryer

Instructions for use

! This symbol reminds you to read this instruc-

tion manual.

Contents

Installation, 2-3-4-5

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Care and maintenance, 6

Cutting off the water and electricity supplies

Cleaning the washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Precautions and tips, 7

General safety

Disposal

Description of the washer-dryer, 8-9

Control panel

Display

How to run a wash cycle or a drying cycle, 10

Wash cycles and options, 11-12

Table of wash cycles

Wash options

Push&Wash+Dry

Detergents and laundry, 13-14

Detergent dispenser drawer

Preparing the laundry

Special wash cycles

Load balancing system

Troubleshooting, 15-16

Product Guarantee and Repair Information, 17

XWDE 961680

English,1

! This instruction manual should be kept in a safe

place for future reference. If the washer-dryer is

sold, transferred or moved, make sure that the

instruction manual remains with the machine so

that the new owner is able to familiarise himself/

herself with its operation and features.

! Read these instructions carefully: they contain

vital information relating to the safe installation

and operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packaging.

2. Make sure that the washer-dryer has not been

damaged during the transportation process. If

it has been damaged, contact the retailer and

do not proceed any further with the installation

process.

3. R e m o v e t h e 4

protective screws (used

during transportation)

and the rubber washer

with the corresponding

spacer, located on

the rear part of the

appliance ( ).see figure

4. Close off the holes using the plastic plugs

provided.

5. Keep all the parts in a safe place: you will

need them again if the washer-dryer needs to

be moved to another location.

! Packaging materials should not be used as

toys for children.

Levelling

1. Install the washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture

cabinets or anything else.

2. If the floor is not

p e r f e c t l y l e v e l ,

c o m p e n s a t e f o r

any unevenness by

tightening or loosening

the adjustable front

feet ( ); the see figure

angle of inclination,

measured in relation to

the worktop, must not

exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive

noise and prevent it from shifting while it is

operating. If it is placed on carpet or a rug, adjust

the feet in such a way as to allow a sufficient

ventilation space underneath the washer-dryer.

Connecting the electricity and

water supplies

Connecting the water inlet hose

1. Connect the supply

pipe by screwing it

to a cold water tap

using a ¾ gas threaded

connection (see figure).

Before performing the

connection, allow the

water to run freely until

it is perfectly clear.

2. Connect the inlet

hose to the washer-

dryer by screwing it

onto the corresponding

water inl et of t he

appliance, which is

situated on the top

right-hand side of

the rear part of the

appliance . (see figure)

3. Make sure that the hose is not folded over

or bent.

! The water pressure at the tap must fall within

the values indicated in the Technical details table

(see next page).

! If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

! Never use second-hand hoses.

! Use the ones supplied with the machine.

Installation

Produkt Specifikationer

Mærke:	Indesit
Kategori:	Vaskemaskine
Model:	XWDE 961680X W UK
Bredde:	595 mm
Dybde:	540 mm
Højde:	850 mm
Vægt:	66000 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Energieffektivitetsklasse (gammel):	A
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1600 rpm
Støjniveau (centrifugering):	81 dB
Støjniveau (vask):	55 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Cotton, Wool, Sport, Delicate/silk
Energiforbrug ved vask:	1.17 kWh
Årligt energiforbrug vask:	234 kWh
Restfugtighed:	44 %
Vaskeklasse:	A
Årligt vandforbrug vask:	12000 L
Energieffektivitetsskala:	A til G
Brugerdefineret panel klar:	Ja
Tørreevne:	6 kg
Vaske kapacitet:	9 kg
Støjniveau (tørring):	61 dB
Cyklustid vask og tørring:	645 min.
Årligt energiforbrug ved vask og tørring:	1224 kWh
Årligt vandforbrug ved vask og tørring:	20000 L
Vandforbrug pr. vask:	60 L
Energiforbrug pr. vask og tørring:	6.12 kWh
Vandforbrug pr. vask og tørring:	100 L
