Side 1/2
4-1/2"
115mm
3-1/4"
84mm
1-1/8"
30mm
3-7/8"
98mm
5-1/8"
129mm
3-3/16"
80mm
4-3/4"
120mm
2-1/4"
57mm
3/8"
8mm
2-1/16"
51mm
1-13/16"
45mm
2-3/8"
60mm
7/8"
22mm
17mm
R E F E R E N C E
5030cs
Declaration of Conformity
We,Harman Consumer Group,Inc.
2,route de Tours
72500 Château du Loir
France
declare in own responsibility that the product described in this owner’s
manual is in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group,Inc.
Château du Loir,France 1/09
5030cs
BL (T-m) 3.50
DCR (ohms) 2.30
Mms (g) 10.86
Sd (sq cm) 103.9
Cms (μm/N) 528
Vas (l) 8.00
Fs (Hz) 66.5
Qes 0.85
Qms 6.27
Qt 0.75
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty
.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030c
s
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030c
s
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030c
s
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
SPECIFICATIONS
5030cs
Type: 5-1/4" (130mm)
2-Way Component
Impedance: 2 Ohms
Power Handling,RMS: 75W
Power Handling,Peak: 225W
Frequency Response: 67Hz – 21kHz
Sensitivity (2.83V,1m): 92dB
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased.Your local Infinity car audio retailer can help you determine the length
of your warranty.To register your product,please visit us at www.infinitysystems.com.
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage.Un numéro de série valable est exigé pour la couverture de la garantie.
Features, specifications and appearance are subject to change without notice.
Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman Consumer Group, Inc., 250 Crossways Park Drive,Woodbury, NY 11797 USA
www.infinitysystems.com
© 2009 Harman International Industries, Incorporated.All rights reserved.Tous droits réservés. • Part No.REF5030CSOM1/09
Infinity is a trademark of Harman International Industries,Incorporated,registered in the United States and/or other countries.
I-Mount is a trademark of Harman International Industries, Incorporated.
Infinity est une marque commerciale de Harman International Industries,Incorporated, déposée aux États-Unis et/ou dans d’autres pays.
I-Mount est une marque commerciale de Harman International Industries, Incorporated.
