reference series

505cs,605cs

& 105t

Thank you for purchasing Infinity’s Reference Series

automotive loudspeaker components. We’ve organized this manual

to make your installation as simple and trouble-free as possible.

Please read it thoroughly before proceeding. Remember to keep

your sales receipt with this manual in a safe place so both are

available for future reference.

instructions

¤¤

Reference

- 2 -

IMPORTANT: Installation of automotive stereo

components can require extensive experience

with a variety of mechanical and electrical

procedures. Although these instructions explain

how to install Reference Series speakers in a

general sense, they do not show the exact

installation methods for your particular vehicle.

If you do not feel you have the experience, do not

attempt the installation yourself, but instead ask

your authorized Infinity car-audio dealer about

professional installation options.

WARNING: Playing loud music in an automobile

can permanently damage your hearing, as well as

hinder your ability to hear traffic. The maximum

volume levels achievable with Infinity speakers,

combined with high power amplification, may

exceed safe levels for extended listening. We

recommend using low volume levels when

driving. Infinity accepts no liability for hearing

loss, bodily injury, or property damage as a result

of use or misuse of this product.

INSTALLATION ARNINGS ANDW TIPS

•Always wear protective eyewear when using

any tools.

•Turn off all audio systems and other electrical

devices before you start. Disconnect the (

–)

negative lead from your vehicle’s battery.

•Keep speakers in their package until final

installation. When moving a speaker, always

rest it with the cone or dome facing up. Never

use force to install any speaker.

•Check clearances on both sides of a planned

mounting surface before drilling any holes or

installing any screws. Remember that the

screws can extend behind the surface.

•At the installation sites, locate and make a note

of all fuel lines, hydraulic brake lines, vacuum

lines, and electrical wiring. Use extreme caution

when cutting or drilling in and around these

areas.

CAUTION: In some cars, fuel tanks may be

located directly beneath the rear deck. Check

for adequate speaker basket clearance before

considering this location!

•Before drilling or cutting holes, use a utility

knife to remove unwanted fabric or vinyl, to

keep material from snagging in a drill bit or

saw.

•For door installations, check the clearance with

the windows throughout the range of the

window’s travel, and verify that a mounted

speaker will not interfere with the window

crank or power window mechanism.

•If mounting speakers elsewhere, check for

clearance around rear deck torsion bars, glove

box, or other structural elements.

•Do not mount speakers where they will get wet.

INSTALLATION

Figure 1.

Mounting the 505cs woofer.

INSTALLATION

Figure 2.

Mounting the 605cs woofer with the grille.
