Side 1/2

Hot & Cool Models Without Filtration

Hot Only Models Without Filtration

FILL TANK & THEN CONNECT POWER

INSTALLING THE FAUCET

Brass Nut

Run the water for at least 2 minutes to flush

lines (both the hot and cold handles

independently if applicable).

Ferrule

Brass Insert

DO NOT plug in unit until

water flows from faucet

PREPARATION

Indulge

™

Contemporary, Antique, Tuscan

Invite

™

Contour

™

, Classic

™

Turn screws

until snug.

FILTRATION STANDARD WITH HWT-F1000S

Available as an option. Separate purchase required.

Typical Complete Installation

(Hot & cool model shown)

Brass Nut

Ferrule

Brass Insert

To dispenser

From water

supply

See Installation, Care & Use Manual for important cautions and warnings

IF INSTALLING FILTRATION SYSTEM

Turn off

cold water

supply

Quick & Easy Steps to Instant Hot Water

FINAL WATER CONNECTION

CONNECTING FAUCET TO TANK

Press ALL tubes in once again to ensure secure fit.

Electric Shock Hazard: This appliance MUST be grounded. Using an ungrounded

appliance can result in serious injury or death from electric shock. Improper connection of

the equipment grounding conductor can result in the risk of shock by electricity.

Property Damage: Make sure bends in all water lines are smooth and unkinked, with

no pinching, twisting or blockage. Pinched or blocked water lines may cause damage to

the dispenser tank.

O-Ring

Brass Nut

Ferrule

Hex Tool

(included)

STEP STEP STEP

Models With Filtration

Involve

™

View

, Wave

(H/HC-View

, H/HC-Wave

)

Invite Hot100

™

, Hot150

™

blue 1/4" tube

Fiber

Washer

Star Nut

STEP

GN1100, GN2200,

GN2215, HC3300,

H3300

HC1100, HC2200,

HC2215

1-1/4" Small

Steel Washer

1-1/4" Rubber

Washer

white 7/16" tube

clear 5/16"

tube

Hole smaller than 1-1/2”1-1/2” hole

white 1/4" tube

copper 1/4" tube

copper 1/4"

tube

white 1/4"

tube from

connector

Hex Tool

(included)

Indulge

™

Modern

(H/HC3300)

(H-Contour

, H-Classic

)

(H-Hot100, H-Hot150)

(GN/HC1100, GN/HC2200, GN/HC2215)

Flat

Gasket

Trim

Ring

Wing Nut

Rubber Washer

Plastic Spacer

Mounting

Plate

Semi-Circular

Mounting Plate

Long Nut

MOUNTING THE TANK

leave 1/4"

exposed

Hang tank and

tighten screws

with only

1/2 turn

clockwise.

16" or less from

faucet base

and

30" or less

from standard

grounded outlet

DO NOT extend plumbing

or electrical lines

Tank

must be

mounted

level.

STEP

From filter or

water supply line

Plug

From filter or

water supply line

NOTICE

TROUBLESHOOTING

WHAT TO DO

Water and steam

spits forcefully

from spout without

turning on the

dispenser faucet.

Water is not hot.

• Unit is boiling.

May be normal during

initial setup.

• The unit is unplugged.

• The electric outlet is

inoperative.

• Activate faucet lever to release some water from the tank.

• Adjust water temperature using dial on tank front.

Remember that at higher altitudes, water boils at lower

temperatures. See Installation, Care & Use manual.

• Make sure the unit is connected to a properly grounded

electric outlet.

• Make sure the circuit breaker or fuses are functioning properly.

• Check that the outlet is not switched off.

Water is too hot

or not hot enough.

• Thermostat is not adjusted

to your needs.

• Adjust the thermostat slowly, then activate faucet lever for

20 secs. to bring in fresh water at the new setting. Allow 5-7

minutes for water to reach new temperature.

Water comes out the

vent instead of spout.

• Outlet tube is blocked. • Check that outlet tube is not kinked, twisted or pinched.

• Unscrew spout end piece and clean out any debris.

Water is dripping

from the spout/vent

intermittently.

• The expansion chamber

isn’t draining properly due

to low water pressure.

• The spout is blocked.

• Unplug the unit. If the dripping doesn’t stop after a few

minutes, check the supply valve to ensure that it is fully open

and there are no obstructions in the water line reducing the

pressure below 30 psi (i.e., a poorly mounted saddle valve, a

clogged water filter, or a partially opened shut-off valve).

• Unscrew spout end piece and clean out any debris.

Water is dripping

from the spout/vent

constantly.

• Debris in the water line may

be in the faucet valve seat

causing a slow water leak.

• Unscrew spout end piece and clean out any debris.

• Activate faucet lever 7-10 times to flush faucet & lines.

Divided stream.

• Debris in the end piece. • Unscrew spout end piece and clean out any debris.

Water continues to run

after releasing lever.

(Involve

™

View

Involve

™

Wave

)

• Mounting nut too tight.

• Mounting washer not

installed properly.

• Loosen mounting nut, 1/4 turn at a time, until shut-off occurs.

• See Installation, Care & Use manual to check proper mounting

washer installation options.

PROBLEM POSSIBLE CAUSE

FILTRATION ISSUES

(Filtration available as an option)

If you are still experiencing trouble, visit www.insinkerator.com or call the

AnswerLine

1-800-558-5700.

Water taste or odor.

• Filter needs to be

flushed out.

• Life of filter has expired.

• Activate faucet lever and run until the water is cold.

If no change, replace filter cartridge.

Plea se read Troubleshooting Guide and/or visit

w ww.insinkerator.com before calling AnswerLine

New filter leaks or

doesn’t fit.

• Head & bracket not

fully rotated.

• Filter O-ring breach.

• Remove, inspect, reinstall filter cartridge.

• Remove new filter, replace with old filter. Check operation.

If OK, reinstall new filter and recheck operation.

No water flow or

low water flow.

• Life of filter has expired.

• Replace filter cartridge.

Water discoloration/

rusty appearance.

• Corrosion of unit. • Unplug and drain unit as described in the Seasonal Storage/

Drainage section of the Owner’s Manual. If the water

discoloration remains after draining and refilling unit,

discontinue use and contact an authorized InSinkErator

service agent.

To see a tutorial of this installation:

http://goo.gl/AZOHu
