Net Toner and Probe KitUser Manual
In testing leads and modular cables for individual-wire tests or modular-jack tests, this
handy device helps you attain the quick, reliable results you need in order to get — and
keep — your wired systems up and running.
ADDITIONAL FEATURES: Tests datacom, telecom, security, video and audio networks
• Two-position switch for single or multi-tone signal • LEDs for line polarity, continuity
and voltage • Enhanced talk battery mode provides power for voice communications
over inactive pairs • Replaceable plastic tip to prevent accidental shorts • Trace or
identify wire or cables in a bundle or group • Alligator clips, RJ45 jack, RJ12 plug, optional
F-connector • Lifetime Warranty Electric Shock Risks & Precautions • Avoid using this
device in wet, damp or excessively humid environments. • Before using the test lead or
accessory, check that it is clean and dry, and that the insulation is in good condition. •
Do not open the battery compartment when test leads are connected to a live circuit, or
when the unit is switched on. • Never connect the Toner or Net Probe to a live wire from
a non-compatible telephone/network system. Doing so may damage the tracer and/or
the equipment. Live Circuit Warnings Acceptable voltage: the tester is designed to bear
voltage conditions commonly found on live telephone wires: It can safely be connected
to wires carrying 48 V DC or less at less than 80 mA, or 24 V AC.
UNACCEPTABLE VOLTAGE: Do not connect the tester to wires bearing over 48 V DC
TABLE OF CONTENTS
Operation . . . . . . . . . . . . . . . . . . . . . . . . 3
Sending/Tracing a Tone ........................ 3
Supplying Talk Power ...........................3
Testing Cable Continuity ........................3
Testing Terminated Coax Cables .................4
Testing Unterminated Coax Cables ...............4
Testing Polarity: Identifying the Tip and Ring ........ 4
Verifying the Line ..............................4
Net Probe — Tone Tracing .......................4
Line Testing...................................5
Other Functions/Components . . . . . . . . . . . . . 5
Replacing the Tip.............................. 5
Replacing the Battery ..........................6
Specifications . . . . . . . . . . . . . . . . . . . . . . 6
Net Toner .................................... 6
Net Probe ....................................6
Environmental ................................6
Package Contents............................. 6
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Information . . . . . . . . . . . . . . . . . 8
