6 合 1 P 5 主 机 散 热 架
产品说明书(PG-P5013)
产品外观图示
产品使用说明:
产品技术参数：
1.先将P5游戏主机倒立放置，再将底座
居中放置在P5主机上，使底座中心位置
的螺丝孔对齐P5主机底部的螺丝孔，再
拧入“主机固定螺丝”，拧紧螺丝后，
主机（建议连接至主机正面的USB端口
）,成功连接后,两个充电槽指示灯常亮。
2.将P5手柄上的Type-C充电接口对准底座上的Type-C插头放入手柄充电槽中，对应
的充电指示灯红灯常亮，开始充电，充满后充电指示灯白灯常亮。
3.当两个手柄同时充电时，面板上的两个充电指示灯同时红灯常亮。充满电后，对
应的充电指示灯白灯常亮。
4.如需给主机散热, 请按下底座上 。的散热开关按钮，散热风扇工作给主机散热
1. 外接其它5V电源可能导致本产品工作异常；
2. P5手柄快充满电时，本产品充电指示灯存在与P5主机或手柄提示不符合的现象，此
为正常现象.（如：P5手柄充电指示已经指示充满，但是进入P5主机查看依然在充电）
3. P5手柄电池低压被保护后，插入本产品充电，指示灯会不准确，此为正常现象；
（例如：P5手柄电池低压被保护后，插入产品进行充电，充电指示灯短时间内依然显
示白色或者白色与红色之间闪烁）
4.请不要在高温环境下充电使用！
5.避免暴晒、雨淋、受潮、受热!
6.不宜放置在通风不好地方充电！
注意事项：
底座 x1
产品清单：
ipega官方微信公众号
售后客服QQ群： 783735068
客服电话： 8(0755) 2791 899
在线时间：周一至周五9:30-17:30
耳机支架
游戏碟架
手柄充电槽1
手柄充电槽 2
主机散热槽
电源输入接口
USB接口
风扇开关
输入电压: 4.75V-5.25V 输入电流: ≤ 2A
单组充电电流: ≤600 mA 充电时间: 5小时
Type-C USB线 p1-x1 说明书 x1 主机固定螺丝 x1
充电槽 2
指示灯
充电槽 1
指示灯
专利号：ZL201930745335.X
产品特征
1.本产品适用于P5原装游戏主机散热，手柄充电，配件摆放与收纳 。
2.带充电指示灯，在充电过程中便于识别充电状态。
3.座充充电槽内有两个专用的TYPE-C公头，手柄充电时随取随放使用非常方便。
4.配备耳机支架,可放置耳机，方便拿取收纳。
5.双风扇能给主机降温与散热。
6.配备游戏碟架,可放置17个游戏碟。
7.配有USB2.0 5V输出端口，可以给耳机，手机等设备充电
主机固定螺丝孔
1
2
3
6 In 1 Vertical Stand for P5
User Manual(PG-P5013)
Features
Product Overview
Product instructions:
Parameters:
Notes:
1. This product is a multi-functional Stand for P5 console and accessories.
Which can be as a vertical stand for P5 console, charge station for P5
controllers, a headset holder, 17pcs game disc storage and cooling fan for the
console.
2. With charging indicator, it is easy to identify the charging status during
charging .
3. It is equipped with two special type C male plugs for original P5 game
controller charging,and it is easy to operation.
4. Equipped with earphone bracket, the earphone can be placed for easy
access and storage.
5. With Dual cooling fans for P5 console, can avoid overheating of the console.
6. Equipped with game disc rack, 17 game discs can be placed.
7. Equipped with USB 2.0 DC 5V output port for charging headsets/ mobiles
and other gaming devices.
2. Plug P5 gamepad into charging slot, the indicator will be on red while starts
charging; indicator turn white when fully charged.
3. When 2 gamepad are charged at the same time, the 2 Red indicators will be
always on. and turn white indicators when fully charged.
4. Put the console into the cooling fan slot, press the switch button, and the fan
1. First place the P5 game console upside down, and then place the stand on the
P5 game console in the middle, so that the screw hole in the center of the base
is aligned with the screw hole at the bottom of the P5 game console, and then
screw in the "console fixing screw". After tightening the screw, connect the
product to the P5 console through type-C USB cable (it is recommended to
connect to the USB port on the front of the Console). After successful connected,
the two charging slot indicators are always on.
1. Connect other 5V power source may cause the product working abnormal.
2. When P5 gamepad is nearly fully charged, the charging indicator of this
product does not conform to the indication of P5 gamepad or console, which is
normal;
(for example: P5 gamepad charging indicator has indicated full charged, but
enter P5 console to check that it is still charging)
3. After the P5 gamepad battery low voltage is protected, insert this product to
charge, the indicator light will be inaccurate, this is a normal phenomenon;
(for example: P5 gamepad battery low-voltage protection, plug in the product
to charge, the charging indicator still shows white or flashing between white
and red)
4. Please do not charge in high temperature environment!
5. Avoid exposure to the sun, rain, damp and heat!
6. It is not suitable to place it in a place with poor ventilation for charging!
Headset Bracket
Game Card Storage
Cooling Slot
Cooling Switch
Charging
Indicator 2
Charging
Indicator 1
Charging
Slot 2
Charging
Slot 1
Power input
USB Port
1. Working voltage: DC 4.75 - 5.25V.
2. Input current: ≤ 2A.
3. Allowable charging current: ≤ 600 mA (single Gamepad).
4. Charging time: 5H
Vertical Stand x1
Included：
Type-C Cable p1-x1 Console fixing screw x1
User Manual X1
Patent NO. : ZL201930745335.X
Slot for console
fixing screw
1
2
3
