IPEGA PG-XBX003 Manual

IPEGA Konsol PG-XBX003

Læs gratis den danske manual til IPEGA PG-XBX003 (1 sider) i kategorien Konsol. Denne vejledning er vurderet som hjælpsom af 19 personer og har en gennemsnitlig bedømmelse på 3.6 stjerner ud af 10 anmeldelser. Har du et spørgsmål om IPEGA PG-XBX003, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

X B X 手柄充电座

产品说明书 PG-XBX003

1. 本产品适用于XB Series X/S手柄进行充电使用；

2. 支持双手柄充电功能，更好的节约空间及电源

设备；

3. 具有充电及饱和指示功能，清晰直观的了解当

前充电状态；

4.具有短路保护功能；

适用说明:

1.输入电压：DC 4.8-5.5V

2.输入电流：1A

3.充电电压：DC 3.2V；

4.充电电流：≈250 mA(单个手柄)

5.充电时间：3-4H

6.电池容量：1000mAh(单个电池)

电性参数：

LED工作模式：

1.LOGO灯：通电长亮白灯；

2.模式灯1/2：通电亮绿灯，充电亮红灯，充满亮

绿灯；

充电功能：

1.将产品USB2.0插头插入XB Series X/S主机USB

母座或者其它5V电源（1A以上），产品LOGO灯

长亮白灯，产品模式灯长亮绿灯；

2.将手柄插入卡槽1/2进行充电，此时红色指示灯

1/2常亮；

3.手柄被充满电后，红灯转绿色指示灯常亮；

4.若手柄充电时出现异常造成短路，内部自动保护，

充电指示灯闪亮，短路解除后重新接入电源自动恢

复工作；

产品使用说明

1.请不要把本产品在潮湿或高温地方存储；

2.不要敲击、摔打、棒打、刺穿、或试图去分解本

产品，以免对产品造成不必要的损害；

3.不要在靠近火或其它热源的地方对手柄进行充电；

4.非专业人员误拆卸本产品,否则不在售后保修服

务内；

注意事项

产品清单

充电底座 x1 说明书 x1 电池盖 x2 电池 x2

专利号：ZL202030675301.0

CHARGER DOCK

WITH BATTERY PACK

User Manual for PG-XBX003

1. Compatible with XB Series X/S Controller;

2. Dual Controller charging at the same time,

easy to use

3. With charging indicators. easy to know the

charging status while charging.

4. With charge protective to avoid overcharge;

Instructions:

1. Input voltage: DC 4.8-5.5V

2. Input current: 1A

3. Charging voltage: DC 3.2V;

4. Charging current: ≈250 mA (Single)

5. Charging time: 3-4H

6. Battery capacity: 1000mAh(Single)

Specification:

LED working status:

1. LOGO indicator: Turn on while connecting to

power source;

2. Mode indicator 1/2: Green indicator turned on

when power on/ full charged, Red indicator

turned on when charging;

Charging function:

1. Connect to XB Console/ other 5V power

source (over 1 A) by using USB Cable, the

LOGO light will glow white and the mode

indicator will glow Green;

2. Connect controller to the dock slot 1/2 , mode

indicator 1/2 will glow red while charging

3. Once the controller is fully charged, the red

indicator turns to green and the light will be

turned on;

4. With charge protective, If the controller is

charged abnormally and causes a short-circuit,

the LOGO light and the mode indicator will flash,

and the work will automatically resume after the

short circuit is removed;

Usage Instruction:

1. Please do not store this product in wet or

high-temperature areas.

2. Don't knap, beat, drub, pierce, or try to

decompose this product, to avoid unnecessary

damage to the product.

3. Do not charge the Controller near fire or other

heat sources;

4. Non professional personnel should not

disassemble the product, otherwise it will not

be covered in the after-sales warranty service.

Notes：

Accessories List:

Charger

Dock x1

User

Manual x1

Battery

cover x2

Ni-MH

Battery x2

Patent No.：ZL202030675301.0
