Side 1/1
5、彩灯开关按键：按下灯效开关键可以在11种灯光效果中依次切换
1：七彩呼吸流水
2：七彩变色慢跑
3：七彩呼吸渐变
4：单色整体呼吸渐变
5：多色整体跳变
6：蓝色
7：水蓝色
8：绿色
9：黄色
10：红色
11：紫色
6、长按灯光模式切换键3秒，保存当前灯光模式并熄灯，再次按一下灯光模式切换键，进入已
模式；
7、共配备两个USB接口，1个带2.0数据功能；
另1个仅支持小电流充电功能。
(PG-XBX025S)
充电指
示灯A
充电指示灯B
1.本产品适用于XBX主机散热及原装手柄（手柄内装XBX原装充电电池）充电使用。
2.配备4个低噪散热风扇，散热效果好，噪声低。
3.配备1个风扇档位触摸按键与1个灯光模式触摸按键。
4.配备一个耳机支架，方便收纳耳机。
5.具备两个存储扩展卡槽位，方便收纳存储扩展卡。
6.配备游戏碟架，可放置6张游戏光盘
7.带RGB炫彩灯效，共有11种灯光效果。
8.兼容XBX原装保护皮套使用。
1、将多功能座充按上图操作方法与主机装配连接；
2、将XBX主机开机，多功能座充的手柄充电指示灯A与指示灯B及风扇档位灯亮绿灯，
此时座充处于待机状态，RGB炫彩灯工作在上次关机前的模式；
3、将XBX原装手柄对准充电槽中的TYPE-C插头插入手柄充电槽A或充电槽B，对应的充电指示灯
将亮红灯，表示手柄正在充电，当手柄充满电时，对应的充电指示灯将亮绿灯；
4、散热风扇开机默认为3档风速，按一下风扇开关，散热风扇停止工作，同时风扇指示灯熄灭。
再按一下风扇开关，切换为1档风速，同时风扇档位指示灯1亮绿灯，再按一下风扇开关，
切换为2档风速，同时风扇档位指示灯2亮绿灯，再按一下风扇开关，切换为3档风速，同时风扇
档位指示灯3亮绿灯。风扇开关可使散热风扇在“3档→关闭→1档→2档”四种状态之间依次切换；
手柄充电
槽A
存储扩展
卡槽A
XBX主机
放置位
存储扩展卡槽B
风扇档位
指示灯
手柄充电槽B
耳机支架
主机连接
USB插头
游戏碟架
USB充电端口
USB数据端口
XBX多功能机甲座充
散热风扇
开机默认为高速档，按一下关闭风扇
再按一下切换至低速档，
再按一下切换至中速档
再按一下切换至高速档，
再按一下关闭风扇，依此循环......
输入：DC 5V/2A
单个手柄充电电流：≤500mA
输出：DC 5V/2A
充电时间：约3.5小时
1.本产品手柄充电功能仅适用于XBS/XBX原装手柄与原装电池组，请勿为其他非原装手柄
和电池组充电。
USB连接线 x 1
灯光模式触摸切换键
USB2.0数据
传输接口
USB充电接口
充电: 亮红灯
待机/充满电：亮绿灯
灯光模式
触摸按键
风扇档位
触摸按键
风扇档位
触摸按键
中档
(PG-XBX025S)
XBX Console area
Controller Charging
port A
Controller
Charging
port B
Storage
Expansion
Cardslot A
Storage
Expansion
Cardslot B
Charging
indicator A
RGB Light
Switch Button
USB Port
USB Port
Game Disc
Storage
Headset
Stand
USB connecting
plug
*For console
Cooling fan
status indicator
Fans speed
control button
Charging
indicator B
Cooling fans
Press one time: Turn on and go to level 3
Press two times: Level 1
Press three times: Level 2
Press four times: Level 3
Press five times: Turn off, loop
Level 1
Level 2
Level 3 (Best dissipation effect, but it may noisy)
USB port 1
USB port 2
1.The charging function only support the XBS/XBX original battery pack, please do not charge
other controller and battery pack.
Charging : Red Light
Standby/Finished: Green Light
RGB Light
Switch Button
Product Description ：
Specifications:
1. This product is suitable for the XBX console which is able to reduce the heat and charge
the original controller (XBX original battery).
2. Equipped four low-noise cooling fans with 3 different levels allow users to switch.
3. Equipped with one touch button for fan speed control and one touch button for light mode
selection.
4. Equipped one headset stand to place the headset.
5. With two card slots to store the Storage Expansion Card.
6. Game Disc Storage, maximum for 6 game disc.
7. RGB colorful lighting effects with a total of 11 lighting modes.
8. Compatible with the original XBX protective case for added convenience and protection.
1. Follow the steps shown in the diagram to assemble and connect the multifunctional
charging dock to the console.
2. Power on the XBX console. The charging dock's controller charging indicator lights A and
B, as well as the fan speed indicator light, will turn green. At this point, the charging dock is in
standby mode, and the RGB colorful lighting will work in the mode it was in before the last
power-off.
3. Align the original XBX controller with the Type-C connector in charging slot A or charging
slot B on the charging dock. The corresponding charging indicator light will turn red, indicating
that the controller is charging. When the controller is fully charged, the corresponding
charging indicator light will turn green.
4. The cooling fan is set to default to the third-speed setting. Press the fanpower button once
to stop the fan, and the fan indicator light will turn off. Press the fan power button again to
switch to the first-speed setting, and the fan speed indicator light 1 will turn green. Press the
fan power button once more to switch to the second-speed setting, and the fan speed
indicator light 2 will turn green. Press the fan power button again to switch to the third-speed
setting, and the fan speed indicator light 3 will turn green. The fan power button allows you to
toggle between the "3rd speed → off → 1st speed → 2nd speed" modes sequentially.
Input: DC 5V/2A
Output: DC 5V/2A
Single controller charging current: ≤500mA
Charging Hours: ~3.5 hours
Product Overview：Product instructions:
Cooling fan
level indicator
Fans speed
control button
Caution
Multi-function Stand x 1 Headset Stand x 1
Charging cable x 1
Manual x 1
Product List:
Note:
2. When is powered on, there is voltage inside the Type-C connector used for controller charging.
Please avoid bending the Type-C connector and prevent water, metal debris, or other foreign
objects from coming into contact with the Type-C connector.
3. When the controller is fully charged or close to full charge and placed on this product for
charging, the charging indicator light will not change and will continue to show a green light.
5. Light Switch Button: Pressing the light effect switch button allows you to cycle through
the 11 lighting effects:
1. Rainbow Breath Flow
2. Rainbow Color Jogging
3. Rainbow Breath Gradient
4. Single Color Breath Gradient
5. Multi-color Overall Jumping
6. Blue
7. Aqua Blue
8. Green
9. Yellow
10. Red
11. Purple
6. Long-press the light mode switch button for 3 seconds to save the current
light mode and turn off the lights. Press the light mode switch button again to enter the
saved light mode. The current light mode is automatically saved when the device is
powered off, and the device will enter the last saved light mode upon the next power-on.
7. Equipped with two USB ports, one with 2.0 data functionality, and the other supports
low-current charging only.
