Side 1/1
80g书写纸 单色双面印刷 315*142MM
1.当风扇在运转中，请勿企图将风扇锁死特别长的时间，此举会因连续停止不转，产生高热而烧毁
风扇。
2.安装风扇时，请特别注意，如果安装不到位会振动产生噪音。
3.本产品在长期不使用时，应将风扇从XBX主机上拔掉。
4.本产品在使用或存放时，应尽量避开灰尘、重压，以免影响使用寿命。
5.本产品不能在潮湿的环境里使用、存放。
6.本产品因使用不当而造成浸水、撞坏或摔坏，出现电气性能问题，请停止使用。
散热风扇 X1 说明书 X1
产品说明书（PG-X B X 0 1 2 )
X B X 散 热 风 扇
工作电压：4.75V-5.25V 工作电流：<150mA
1.本产品适用于XBX原装游戏主机散热。
2.带散热风扇开关与散热风扇工作状态指示灯。
3.带USB2.0转接母座，不独占主机USB接口。
4.散热风扇能给主机散热和降温。
风扇开关
USB接口
风扇
1.将PG-XBX012散热风扇的USB公头
插入XBX主机背部USB接口，注意散热
风扇底端的圆柱型插销需要嵌入主机壳。
3.再次按一下PG-XBX012散热风扇的开关
时，开关弹起，风扇指示灯熄灭，同时散热
风扇停止工作。
4.在PG-XBX012散热风扇USB公头插在XBX主机USB接口上时（不论散热风扇是否工作），散热风扇上
的USB母座具备完整的XBX主机USB2.0接口功能。
2.当需要给XBX主机散热时，按一下
PG-XBX012散热风扇上部的方形开关，
风扇指示灯亮起，同时散热风扇进入工作
状态，向主机内部方向吹风。
设备使用说明：
适用说明:
注意事项：
ZL202130111367.1
Manual(PG-XBX012)
Manual X1
XBX Cooling Fan
Radiator Fan X1
1. Insert the USB male of PG-XBX012
cooling fan into the USB interface on
the back of XBX console, and pay
attention to that the cylindrical pin at
the bottom of the cooling fan needs to
be embedded into the console shell.
2. When it is necessary to dissipate heat
the XBX console, press the square N.S
on the top of product, the indicator light
will be on, Then start to wokr, blowing air
to the interior of the console.
3. Press the switch again, the switch will
pop up, the indicator will off, and the cooling
fan stop working
1. This product is suitable for heat dissipation of XBX original game console.
2. With cooling fan switch and Indicator of cooling fan working status
3. With USB 2.0 female adapter,Does not occupy the USB interfaceof console.
4. Can dissipate heat and cool the XBX console
1. When the fan is under operation, please do not attempt to lock the fan for long time. This will
cause the fan to be continuously stopped and generate high heat and burn the fan.
2. When installing the fan, please pay special attention, if the installation is not in place, it will
vibrate and generate noise.
3. When this product is not in use, the power USB plug should be unplugged from the XBX console.
4. When this product is used or stored, dust and heavy pressure should be avoided as much
as possible, so as not to affect the lifetime.
5. This product cannot be used or stored in a humid environment.
6. This product is immersed in water, crashed or broken due to improper use, and electrical
performance problems occur, so please stop using it.
7. If there is any damage, please send it to the maintenance department for disposal, and do not
disassemble it by yourself.
Applicable instructions:
Product features:
Working voltage: Working current: 4.75V-5.25V < 150mA
4. When the PG-XBX012 Cooling Fan USB male is inserted into the USB interface of XBX
console (no matter whether the cooling fan is working or not), the USB female seat on the
cooling fan has a complete USB 2.0 interface function
Electrical parameters:
Illustration:
Product note:
Product note:
ZL202130111367.1
Patent NO. :
1
1
Power button
Extra USB Port
Cooling Fan
2 3
2 3
