TWEETER TYPE: Pure-titanium dome with EOS™ waveguide

D E S I G N G O A L : Bring the thrill of live performance and movie sound to

the home environment by calling on JBL’s professional engineering leadership.

C R O S S O V E R N E T W O R K : Straight-Line Signal Path™ (SSP)

P O R T D E S I G N : FreeFlow™ ared

P R O F E S S I O N A L R E F E R E N C E : Studio Monitor

O W N E R ’S G U I D E

W O O F E R T Y P E :

Cast-aluminum basket with HeatScape™ motor structure

P R O D U C T L I N E :

S T U D I O S E R I E S

M O D E L

S-C ENT ER

N U M B E R :

T H A N K Y O U F O R C H O O S I N G J B L

For more than 50 years, JBL

has been involved in every

aspect of music and lm

recording and reproduction,

from live performances to the

recordings you play in your

home, car or oce.

We’re confident that the JBL

loudspeaker you have chosen

will provide every note of

enjoyment that you expected –

and that when you think

about purchasing additional

audio equipment for your

home, car or office, you will

once again choose JBL.

Please take a moment to

complete the enclosed

profile card. It enables us

to keep you posted on our

latest advancements, and

helps us to better understand

our customers and build

products that meet their

needs and expectations.

JBL Consumer Products

0-2 ft.

S P E A K E R P L A C E M E N T

Proper placement of the

speakers is an important step

in obtaining the most realistic

soundstage possible. These

recommendations are for the

optimum placement of the

loudspeakers. Use these

placement recommendations

as a guide. Slight variations

will not diminish your

listening pleasure.

The Studio Series S-CENTER

loudspeaker is video-

shielded and can safely be

placed near a television.

The S-CENTER is designed

to complement all of the

Studio Series loudspeakers.

It is the ideal way to

re-create the cinematic

experience in your home.

If there is no sound from

any of the speakers:

• Check that receiver/

amplier is on and that

a source is playing.

• Review proper operation

of your receiver/amplier.

If the system plays at low

volumes but shuts o as

volume is increased:

• Check all wires and

connections between

receiver/amplier

and speakers.

• Make sure all wires are

connected. Make sure none

of the speaker wires are

frayed, cut or punctured.

• If more than one pair of

main speakers is being

used, check the minimum

impedance requirements of

your receiver/amplier.

If there is no sound from

the center speaker:

• Make sure that your

receiver’s “Center-Channel”

mode is in the ”Normal“ or

”Wide“ position. If it is in the

”Phantom“ position, the

center speaker will not play.

• Check all connections

between processor/amplier

and the center speaker.

CONNECTION TIPS

S P E A K E R C O N N E C T I O N S

– +

Speaker Outputs

CENTER

– +

Speakers and electronics

terminals have corre-

sponding (+) and (–)

terminals. It is important to

connect both speakers

identically: (+) on the

speaker to (+) on the

amplier and (–) on the

speaker to (–) on the

amplier. Wiring “out of

phase” results in thin sound,

weak bass and a poor

stereo image.

T R O U B L E S H O O T I N G
