JT-DPM8600

Programmable lab power supplies

2. GENERAL INFORMATION

Dear customer,

thank you for choosing our product. In the following, we will show you how

to use your product.

Should you encounter any unexpected problems during use, please do not

hesitate to contact us.

1. SAFETY INSTRUCTIONS

Our product is suitable for up to 75 Volt DC. Working with voltage

over 60 V DC is re-served for trained electricians, because of the

hazard of an electric shock which may cause serious injuries or

death. Non-electricians have to use a voltage source below 60

Volt DC. !

Model

3. TECHNICAL PARAMETERS

The DPM8600 series are programmable power supplies which have a large

output power, are compact and are well structured. At the same time, it is

equipped with TTL serial communication interface or RS485 communication

interface, which provides a serial communication protocol.

I -RTUt can also be applied to modbus communication protocol and supports

further development from users. Moreover, it can provide multi-purpose

solution according to your design and testing requirements.

Also, a DPM8600 series can be equipped with wireless remote control. The

wireless controller adopts 2.4-inch LCD screen. It has many display values,

a a simple operation, built-in lithium battery which can be recharged and it

can control the power supply from up to 10 meters wirelessly. The wireless

controller can control multiple power supplies simultaneously.

This modular power supply can be applied in several aspects. It can be used

for example as an ammeter, a smartmeter, a LED driver, a voltage regulator

for solar panels or in an industrial control.

If the device is damaged or the scope of delivery incomplete, do not use it

and contact our support. Otherwise, if the device is damaged, it could cause

shorts and the device could iname.

NOTE: The following description uses the DPM8624 as an example.

The DPM8605 works similar to the DPM8624.

DPM-8605 DPM8624-485

Input voltage 10 - 75 V 10 - 75 V

Output voltage 0 - 60 V 0 - 60 V

Output current 0 - 5 A 0 - 24 A

Output power 0 - 300 W 0 - 1440 W

Communication

interface

DPM-8605 TTl serial communication interface

DPM8624-485 RS-485 communictaion interface

Voltage resolution 10 mV

Current resolution 1 mA 10 mA

Output ripple < 50 mVpp

Eiciency 92 %

Display accuracy 10 mV, 1 mA 10 mV, 1 mA

Output tolerance voltage: ± 2 % / current: ± 5 %0 0

Response time < 50 ms

Dimension 120 · 131 · 55 mm 150 · 120 · 59 mm

Applied ambient

temperature -25 - 60 °C
