Ultra-thin HDMI2.0 Extender
1
Statement
Read this user manual carefully before using this product. Pictures shown in this manual is for reference
only, different model and specifications are subject to real product. This manual is only for operation
instruction only, not for any maintenance usage. The functions described in this version are updated till
May 3, 2017. In the constant effort to improve our product, we reserve the right to make functions or
parameters changes without notice or obligation. Please refer to the dealers for the latest details.
Safety Precaution
To insure the best from the product, please read all instructions carefully before using the device. Save
this manual for further reference.
Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
Do not dismantle the housing or modify the module to avoid electrical shock or burn.
Using supplies or parts not meeting the products’ specifications may cause damage, deterioration or
malfunction.
Do not expose the unit to rain, moisture or install this product near water.
Install the device in a place with fine ventilation.
Do not twist or pull by force ends of the optical cable. It can cause malfunction.
Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before
cleaning.
Unplug the power cord when left unused for a long period of time.
Refer all servicing to qualified service personnel.
After-sales Service
We provide limited warranty for the product within three years counting from the first day you buy this
product (The purchase invoice shall prevail).
For any questions or problems, please try to get help from your local distributor, AV dealer or call us
directly at 888-975-1368 or email us at: support@kanexpro.com.
Introduction
This product is an ultra-thin HDMI2.0 Extender consist of transmitter and receiver. It extends 1080p/4K
HDMI signal over CAT5e/CAT6a cable up to 70m /40m (PoC), and enables IR and RS232 pass-through
to control source or display device remotely. It also adopt a visually lossless video compression
technology (VLC) to ensure the HD lossless transmission of HDR and 4K@60Hz/4:4:4 over
CAT5e/CAT6a cable.
