Side 1/4
Certicate Number
SGS ATEX003922
Issued 15 December 2022
Page 1 of 4
B -CERT-AS 070 SGS Baseefa Limited is an associate of SGS Fimko OY Issue 2
1
2
Equipment or Protective System Intended for use in Potentially Explosive Atmospheres
Directive 2014/34/EU
3
EU - Type Examination
Certicate Number:
SGS22ATEX0039
4
Product:
EXC6R, EXC7R, EXH6R
5
Manufacturer:
Ledlenser GmbH & Co. KG
6
Address:
Kronenstraße 5-7, D-42699, Solingen, Germany
7
This product and any acceptable variation thereto is specified in the schedule to this certicate and the documents
therein referred to.
8
SGS Fimko Oy, Notied Body number 0598, in accordance with Article 17 of Directive 2014/34/EU of the
European Parliament and of the Council, dated 26 February 2014, certies that this product has been found to
comply with the Essential Health and Safety Requirements relating to the design and construction of products
intended for use in potentially explosive atmospheres given in Annex II to the Directive.
The examination and test results are recorded in condential Report No. GB/BAS/ExTR19.0071/00
9
Compliance with the Essential Health and Safety Requirements has been assured by compliance with:
EN IEC 60079-0:2018 60079-11:2012 EN
except in respect of those requirements listed at item 18 of the Schedule.
10
If the sign “X” is placed after the certificate number, it indicates that the product is subject to the Specic
Conditions of Use specied in the schedule to this certicate.
11
This EU - TYPE EXAMINATION CERTIFICATE relates only to the design and construction of the specied
product. Further requirements of the Directive apply to the manufacturing process and supply of this product.
These are not covered by this certificate.
12
The marking of the product shall include the following:




S Schedule ee
SGS Fimko Oy Customer Reference No. 7674
Project File No. 19/0262
This document is issued by the Company subject to their General Conditions for Certication Services accessible at
http://www.sgs.com/en/Terms-and-Conditions.aspx . Attention is drawn to the limitation of liability, indemnication and jurisdiction
issues dened therein. Any holder of this document is advised that information contained herein reflects the Company’s findings at the
time of their intervention only and within the limits of Client’s instructions, if any. It does not necessarily indicate that the equipment
may be used in particular industries or circumstances. The Company’s sole responsibility is to its Client and this document does not
exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document
cannot be reproduced except in full, schedule included, without prior written approval of the Company. Any unauthorized alteration,
forgery or falsication of the content or appearance of this document is unlawful and oenders may be prosecuted to the ful lest extent
of the law.
SGS Fimko Oy
Takomotie 8
FI-00380 Helsinki, Finland
Telephone +358 (0)9 696 361
e-mail sgs.mko@sgs.com
web site www.sgs.
Business ID 0978538-5 Member of the SGS Group (SGA SA)
Mikko Välimäki
Authorised Signatory for SGS Fimko Oy
Certicate Number
SGS ATEX003922
Issued 15 December 2022
Page 2 of 4
B -CERT-AS 070 SGS Baseefa Limited is an associate of SGS Fimko OY Issue 2
13
Schedule
14
Certicate Number SGS22ATEX0039
15 Description of Product
The EXC6R and EXC7R are portable right-angle ashlights. The EXH6R is a portable headlamp. All are powered by a
custom lithium ion based battery pack. They are suitable for use in Group IIC and IIIC areas and have Equipment Protection
Levels of Ga and Db.
The EXH6R is also suitable for use in Group I areas and has Equipment Protection Level Ma.
The lamps have a charging socket rated Um = 6.75V for use only in safe areas.
The EXC6R and EX R models are marked: C7



II 1G Ex ia IIC T4 Ga



II 2D Ex ib IIIC T135°C Db
The EXH6R is marked:



I M1 Ex ia I Ma



II 1G Ex ia IIC T4 Ga



II 2D Ex ib IIIC T135°C Db
The equipment is considered out of scope of EN 60079-28:2015.
16 Report Number
GB/BAS/ExTR19.0071/00
17 Specic Conditions of Use
None.
18 Essential Health and Safety Requirements
In addition to the Essential Health and Safety Requirements (EHSRs) covered by the standards listed at item 9, the following
are considered relevant to this product, and conformity is demonstrated in the report:
Clause
Subject
1.4.1
External eects
1.4.2
Aggressive substances, etc.
19 Drawings and Documents
Number
Sheet
Issue
Date
Description
SC-EXC6R-A
1 & 2
V1
02/12/2021
Main exploded drawing
SC-EXC6R-B
1
V1
02/12/2021
EXC6R control PCBA subassembly
SC-EXC6R-C
1 & 2
V1
02/12/2021
EXC6R base subassembly
SC-EXC6R-D
1 & 2
V1
02/12/2021
EXC6R lamp head subassembly
SC-EXC6R-LA-01
1
V1
2022-12- 06
EXC6R IECEx laser drawing
SC-EXC6R-38
1 to 4
V1
09/05/2022
EXC6R Electronics
EX4200Y0-21
1
V1
12/12/2017
Φ6.5XΦ2.5防水透气膜 白色蒲微( )
SC-EXC6R-03
1
V0
18/09/2020
EXC6R top shell
