VRTEX® 360
WELDING PROCEDURE SPECIFICATIONS
S28157-272 Revision A.08
1 SMAW 1/8" (3.2 mm) E6010 Fleetweld 5P+ NA NA Flat 1/4" (6.4 mm) 90 (±5) NA DC+
2,3,4 SMAW 1/8" (3.2 mm) E6010 Fleetweld 5P+ NA NA 2F, 3F up, 4F 3/8" (9.6 mm) 90 (±5) NA DC+
5,6,7,8 SMAW 1/8" (3.2 mm) E6010 Fleetweld 5P+ NA NA 1G, 2G, 3G up, 4G 3/8" (9.6 mm) 90 (±5) NA DC+
9 SMAW 1/8" (3.2 mm) E7018 Excalibur 7018 NA NA Flat 1/4" (6.4 mm) 125 (±5) NA DC+
10,11,12 SMAW 1/8" (3.2 mm) E7018 Excalibur 7018 NA NA 2F, 3F up, 4F 3/8" (9.6 mm) 125 (±5) NA DC+
13,14,15,16 SMAW 1/8" (3.2 mm) E7018 Excalibur 7018 NA NA 1G, 2G, 3G up, 4G 3/8" (9.6 mm) 125 (±5) NA DC+
17 SMAW 1/8" (3.2 mm) E6013 Fleetweld 37 NA NA Flat 1/4" (6.4 mm)
100 (± 5)
NA AC
18 SMAW 1/8" (3.2 mm) E6013 Fleetweld 37 NA NA 2F 10 GA. (3.2 mm)
100 (± 5)
NA AC
19 SMAW 1/8" (3.2 mm) E6013 Fleetweld 37 NA NA 3F down 10 GA. (3.2 mm) 125 (±5) NA AC
20 SMAW 1/8" (3.2 mm) E6013 Fleetweld 37 NA NA 4F 10 GA. (3.2 mm)
100 (± 5)
NA AC
21,22 SMAW 1/8" (3.2 mm) E6013 Fleetweld 37 NA NA 1G, 2G 3/8" (9.6 mm) 110 (±5) NA AC
23,24 SMAW 1/8" (3.2 mm) E6013 Fleetweld 37 NA NA 3G, 4G 3/8" (9.6 mm) 90 (±5) NA AC
Root: 80 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
Root: 80 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
Root: 80 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
1/8" (3.2 mm) E6010 Fleetweld 5P+ Root: 90 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
1/8" (3.2 mm) E6010 Fleetweld 5P+ Root: 90 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
1/8" (3.2 mm) E6010 Fleetweld 5P+ Root: 90 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
1/8" (3.2 mm) E6010 Fleetweld 5P+ Root: 90 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
1/8" (3.2 mm) E6010 Fleetweld 5P+ Root: 90 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
1/8" (3.2 mm) E6010 Fleetweld 5P+ Root: 90 (±5)
Hot: 100 (± 5)
Fill/Cap: 80 (±5)
GTAW Root: NA
Fill/Cap: 80 (±5)
GTAW Root: NA
Fill/Cap: 80 (±5)
GTAW Root: NA
Fill/Cap: 80 (±5)
37 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) Flat 1/4" (6.4 mm) 250 (+ 5) (6.3 m/min) 18 DC+
38 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 2F 10 GA. (3.2 mm) 250 (+ 5) (6.3 m/min) 18 DC+
39 GMAW-S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 2F 1/4" (6.4 mm) 375 (+ 5) (9.5 m/min) 20 DC+
40 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 3F up 1/4" (6.4 mm) 275 (+ 5) (7.0 m/min) 18 DC+
41 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 3F down 10 GA. (3.2 mm) 250 (+ 5) (6.3 m/min) 18 DC+
42 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 4F 1/4" (6.4 mm) 325 (+ 5) (8.2 m/min) 19 DC+
43 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 1G 3/8" (9.6 mm) 350 (+ 5) (8.9 m/min) 20 DC+
44 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 2G 3/8" (9.6 mm) 320 (+ 5) (8.0 m/min) 19.5 DC+
45 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 3G up 3/8" (9.6 mm) 250 (+ 5) (6.3 m/min) 17.9 DC+
46 GMAW - S .035" (.89 mm) ER70S-6 SuperArc L-56 75/25 25-35 (12-16.5 l/min) 4G 3/8" (9.6 mm) 270 (+ 5) (6.8 m/min) 18 DC+
47 GMAW - Spray .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) Flat 1/4" (6.4 mm) 400 (+ 5) (10.0 m/min) 27 DC+
48 GMAW - Spray .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 2F 3/8" (9.6 mm) 375 (+ 5) (9.5 m/min) 26.5 DC+
49 GMAW - Spray .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 1G 3/8" (9.6 mm) 370 (+ 5) (9.4 m/min) 26.5 DC+
50 GMAW - Pulse .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 2G 3/8" (9.6 mm) 130 (+ 5) (3.3 m/min) .95(trim) DC+
51 GMAW - Pulse .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 3G up 3/8" (9.6 mm) 130 (+ 5) (3.3 m/min) .95(trim) DC+
GMAW - STT .045" (1.1 mm) ER70S-6 SuperArc L-56 100% Co2 25-35 (12-16.5 l/min) 2G Pipe
130 - 140 (3.3-3.8 m/min)
NA
GMAW - Pulse .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 2G Pipe 125-130 (3.2-3.3 m/min) .95(trim)
GMAW - STT .045" (1.1 mm) ER70S-6 SuperArc L-56 100% Co2 25-35 (12-16.5 l/min) 5G Pipe down
130 - 140 (3.3-3.8 m/min)
NA
GMAW - Pulse .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 5G Pipe up 125-130 (3.2-3.3 m/min) .95(trim)
GMAW - STT .045" (1.1 mm) ER70S-6 SuperArc L-56 100% Co2 25-35 (12-16.5 l/min) 6G Pipe down
130 - 140 (3.3-3.8 m/min)
NA
GMAW - Pulse .045" (1.1 mm) ER70S-6 SuperArc L-56 90/10 25-40 (12-18 l/min) 6G Pipe up 125-130 (3.2-3.3 m/min) .95(trim)
GMAW - STT .045" (1.1 mm) ER70S-6 SuperArc L-56 100% Co2 25-35 (12-16.5 l/min)
130 - 140 (3.3-3.8 m/min)
NA
FCAW - G .045" (1.2 mm) E71T-1 UC 71A85 75/25 40-50 (19-23.5 l/min) 275 (+ 5) (7.0 m/min) 25
GMAW - STT .045" (1.1 mm) ER70S-6 SuperArc L-56 100% Co2 25-35 (12-16.5 l/min) 5G Pipe down
130 - 140 (3.3-3.8 m/min)
NA
FCAW - G .045" (1.2 mm) E71T-1 UC 71A85 75/25 40-50 (19-23.5 l/min) 5G Pipe up 275 (+ 5) (7.0 m/min) 25
GMAW - STT .045" (1.1 mm) ER70S-6 SuperArc L-56 100% Co2 25-35 (12-16.5 l/min) 6G Pipe down
130 - 140 (3.3-3.8 m/min)
NA
FCAW - G .045" (1.1 mm) E71T-1 UC 71A85 75/25 40-50 (19-23.5 l/min) 6G Pipe up 275 (+ 5) (7.0 m/min) 25
58 FCAW - G .045" (1.1 mm) E71T-1 UC 71A85 75/25 40-50 (19-23.5 l/min) Flat 1/4" (6.4 mm) 275 (+ 5) (7.0 m/min) 25 DC+
59,60,61 FCAW - G .045" (1.1 mm) E71T-1 UC 71A85 75/25 40-50 (19-23.5 l/min) 2F, 3F up, 4F 3/8" (9.6 mm) 275 (+ 5) (7.0 m/min) 25 DC+
62,63,64,65 FCAW - G .045" (1.1 mm) E71T-1 UC 71A85 75/25 40-50 (19-23.5 l/min) 1G, 2G, 3G up, 4G 3/8" (9.6 mm) 275 (+ 5) (7.0 m/min) 25 DC+
66 FCAW - S 5/64" (2.0 mm) E71T-8 NR- 232/233 NA NA Flat 1/4" (6.4 mm) 140 (+ 5) (3.5 m/min) 20 DC-
67,68 FCAW - S 5/64" (2.0 mm) E71T-8 NR- 232/233 NA NA 2F, 3F up 3/8" (9.6 mm) 155 (+ 5) (4.0 m/min) 21 DC-
69 FCAW - S 5/64" (2.0 mm) E71T-8 NR- 232/233 NA NA 4F 3/8" (9.6 mm) 145 (+ 5) (3.7 m/min) 20 DC-
70,71 FCAW - S 5/64" (2.0 mm) E71T-8 NR- 232/233 NA NA 1G, 2G 3/8" (9.6 mm) 130 (+ 5) (3.3 m/min) 21 DC-
72 FCAW - S 5/64" (2.0 mm) E71T-8 NR- 232/233 NA NA 3G up 3/8" (9.6 mm) 125 (+ 5) (3.2 m/min) 19.5 DC-
56
6" (150 mm)
DC+
57
6" (150 mm)
DC+
54
6" (150 mm)
DC+
55
2G Pipe
6" (150 mm)
DC+
52
6" (150 mm)
DC+
53
6" (150 mm)
DC+
NA
6G Pipe up
2" (50 mm)
NA
DC+
5G Pipe up
2" (50 mm)
NA
DC+
NA
36
SMAW
3/32" (2.4 mm) E7018
Excalibur 7018
NA
35
SMAW
3/32" (2.4 mm) E7018
Excalibur 7018
NA
NA
2G Pipe
2" (50 mm)
NA
DC+
NA
DC+
NA
6G Pipe up
2" (50 mm)
3/32" (2.4 mm) E7018
Excalibur 7018
34
SMAW
3/32" (2.4 mm) E7018
Excalibur 7018
NA
33
SMAW
NA
2" (50 mm)
NA
DC+
3/32" (2.4 mm) E7018
Excalibur 7018
NA
DC+
3/32" (2.4 mm) E7018
Excalibur 7018
2" (50 mm)
32
SMAW
NA
NA
5G Pipe up
31
SMAW
NA
NA
2G Pipe
DC+
30
SMAW
NA
NA
6G Pipe up
29
SMAW
NA
NA
5G Pipe up
6" (150 mm)
NA
DC+
3/32" (2.4 mm) E7018
Excalibur 7018
NA
DC+
3/32" (2.4 mm) E7018
Excalibur 7018
6" (150 mm)
28
SMAW
NA
NA
2G Pipe
6" (150 mm)
NA
DC+
27
SMAW
1/8" (3.2 mm) E6010
Fleetweld 5P+
NA
NA
6" (150 mm)
NA
DC+
3/32" (2.4 mm) E7018
Excalibur 7018
6G Pipe up
6" (150 mm)
NA
DC+
26
SMAW
1/8" (3.2 mm) E6010
Fleetweld 5P+
NA
NA
5G Pipe up
25
SMAW
1/8" (3.2 mm) E6010
Fleetweld 5P+
NA
NA
2G Pipe
6" (150 mm)
NA
VRTEX® 360 - Default Weld Process Settings (Standard Production Software Set 1)
WPS #
VR Welding
Process
Consumable Type
Lincoln Brand
Gas Mixture
Gas Flow (CFH)
Position
Mat'l (in)
WFS (ipm) or amps
Voltage
Polarity
