Side 1/19

(June 2024)

DST-Pro USB4, USB-C Laptop

Docking Station

User Manual English

Benutzerhandbuch Deutsch

Manuel Utilisateur Français

Manuale Italiano

Manual del Usuario Español

No. 43372

lindy.com

User Manual English

Introduction

Thank you for purchasing the Lindy USB-C Laptop Docking Station. This product has been designed to

provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free lifetime

technical support. To ensure correct use, please read this manual carefully and retain it for future

reference.

This Laptop Docking Station of the latest USB4 generation is a high performance, multifunctional solution

for connecting laptops, tablets or mobile phones to a range of interfaces including an 8K 30Hz DisplayPort

or HDMI® display or two displays simultaneously at 4K 60Hz*. Through a single USB-C cable, connect to

multiple SuperSpeed 10Gbps USB Type A or Type C ports, a 3.5mm combined headphone jack, Gigabit

Ethernet, (Micro-) SD card slots, DisplayPort and HDMI®.

The USB4 Docking Station also supports Power Delivery 3.0 up to 100W for charging the connected laptop

or peripheral devices (power supply not included). The dock can be used with the power supply supplied

with the laptop or a power supply can be purchased separately.

Package Contents

• USB-C Laptop Docking Station

• USB4 Type C cable (appr. 0.8m)

• This Manual

Specification

• Host Interface: USB4 (40Gbps)

• Connects an HDMI® and/or DP display to your laptop

• Max. resolutions (single display): 7680x4320 30Hz, 3840x2160 120Hz

• Max. resolution for dual displays* (MST - macOS does not support MST): 3480x2160 60Hz

• 4 Port USB 3.2 / 3.1 Gen 2 10Gbps Hub: 3x USB Type A and 1x USB Type C

• 3 Port USB 2.0 480Mbps Hub (for mouse, keyboard etc.) : 3x USB Type A

• 1x USB Type C Power Delivery port (PD 3.0 up to 20V / 5A)

• Supports Gigabit Ethernet 10/100/1000Mbps

• 1x SD and 1x Micro SD slot (SD 3.0 up to 1Gbps), compatible with SDXC, SDHC, SD, MMC, RS-

MMC, Micro SDXC, microSD, micro SDHC, UHS-I

• 1x 4 segments combo Audio port (1x in, 1x out)

• Compatible with computers with USB4 / 3.2 / Thunderbolt 3/4 Type C interface and DisplayPort

Alternate mode

• Special Features: 3x USB Gen 2 Type A Battery Charging 1.2 ports (total current limit is 2.3A),

Supports MST for Windows, supports simultaneous card reading (microSD), PXE (Preboot

Execution Environment) and Wake on LAN (WOL) support

Physical Properties

•

Dimensions WxDxH: 129x69.5x48mm (5.08x2.74x1.89in)

•

Housing Material: Aluminium Alloy

•

Net Weight: 0.3kg (0.66lb)

•

Operating Temperature: 0°C - 40°C (32°F -104°F)

•

Storage Temperature: -10°C - 70°C (14°F - 158°F)

•

Humidity: 10 - 90% RH (non-condensing)

Produkt Specifikationer

Mærke:	Lindy
Kategori:	Andet computertilbehør
Model:	43372
Bredde:	129 mm
Dybde:	69.5 mm
Højde:	48 mm
Vægt:	300 g
Brugervejledning:	Ja
Produktfarve:	Anthracit
Pakkevægt:	400 g
Pakkedybde:	151 mm
Pakkebredde:	174 mm
Pakkehøjde:	56 mm
Kompatible hukommelseskort:	MicroSD (TransFlash), SD
Opbevaringstemperatur (T-T):	-10 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Antal HDMI-porte:	1
HDCP:	Ja
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	3
Udgange til hovedtelefoner:	1
Ethernet LAN:	Ja
Driftstemperatur (T-T):	0 - 40 °C
Ethernet LAN-datahastigheder:	1000 Mbit/s
Husmateriale:	Aluminium
Kabler inkluderet:	USB Type-C til USB Type-C
Forbindelsesteknologi:	Docking
Strømforbrug (maks.):	20 W
Strømkilde type:	USB
Indbygget kortlæser:	Ja
Bæredygtighedscertifikater:	CE, Federal Communications Commission (FCC), REACH, RoHS
Mikrofonindgang:	Ja
Værtsgrænseflade:	USB4
Tilslutning af hovedtelefoner:	3,5 mm
Maksimal opdateringshastighed:	120 Hz
HDMI-version:	2.1
DisplayPort-version:	1.4
Antal DisplayPorts:	1
Overholdelse af bæredygtighed:	Ja
Kombineret hovedtelefon/mikrofon-port:	Ja
Maksimal digital opløsning:	7680 x 4320 pixel
Dataoverførselshastighed:	1 Gbit/sek.
HDCP-version:	2.2
USB strømforsyning revision:	3.0
USB strømforsyning:	Ja
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte:	1
Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte:	3
USB type-C DisplayPort alternativ tilstand:	Ja
Antal understøttede skærme:	2
USB strømforsyning op til:	100 W
PowerShare:	Ja
Antal USB-porte med understøttelse af PowerShare:	3
Antal USB4-porte:	1
