Side 1/4
ON/OFF
SCAN
RESET
RECEIVER
VOLUME /
POWER DIAL
POWER LED
ON/OFF
SCAN
RESET
BATTERY
COMPARTMENT
ON/OFF
SCAN
RESET
WHAT’S INCLUDED
1 x Transmitter
1 x Receiver (headphones)
1 x 3.5mm to RCA adaptor cable
2 x 3.5mm audio cable
4 x AAA Batteries
WIRELESS
HEADPHONES
TRANSMITTER
CABLES
MICROPHONE
POWER LED
MIC AUDIO OFF CHAT
WLMNT
BATTERY
COMPARTMENT
TRANSMITTER
FUNCTIONS
MIC AUDIO OFF CHAT
WLMNT
MICROPHONE
OUTPUT
AUDIO
INPUT
FUNCTION
SWITCH
ADAPTOR CABLE
AUDIO CABLE X2
RED
WHITE
INSTALLATION
INSTALLING THE RECEIVER (HEADPHONES)
1. Insert 2 x AAA batteries into the battery compartment according to the correct polarity.
INSTALLING THE TRANSMITTER
1. Insert 2 x AAA batteries into the battery compartment according to the correct polarity.
2. Insert one end of the audio cable into the socket on the back of the transmitter.AUDIO
3. Insert other end of the audio cable into the socket of your chosen audio source. AUDIO-OUT
In cases where the socket of the audio source is not the headphone 3.5mm socket, AUDIO-OUT
use the supplied RCA adaptor cable for connection (see installation diagram to the right).
4. To achieve the best reception, spread out the transmitter audio cable which can also be used as an antenna.
USING YOUR HEADPHONES WITH A TV
1. Insert the transmitter audio cable into the socket of the source. AUDIO-OUT
If a TV is used as the source, the TV can be muted to only output sound through the headphones.
2. Move the FUNCTION SWITCH to the position to turn on the Power LED of the transmitter. WL
3. Turn the VOLUME / POWER DIAL on the headphones to turn on the Power LED of the headphones.
4. Press the button then press the button until the channel of your source is found by the headphones. RESET SCAN
5. If channel is not found repeat step 4.
USING YOUR HEADPHONES FOR WIRELESS INTERNET CHAT / GAMING
1. Connect one audio cable to the socket of the transmitter and insert the other end of the cable into the AUDIO AUDIO-OUT socket
of the computer.
2. With the other audio cable, insert one end into the socket of the transmitter and insert the other end into the MIC
of the computer.MICROPHONE INPUT
3. Aim the microphone socket of the transmitter towards you then move the (MIC) FUNCTION SWITCH CHAT to the position.
The Power LED of transmitter will turn on.
4. Turn on the VOLUME / POWER DIAL of the headphones and the Power LED of the receiver will turn on.
5. Press the button, then the RESET SCAN button until the audio channel of your computer is heard.
6. If channel is not found repeat step 5.
USING YOUR HEADPHONES WITH A CABLE (NOT WIRELESS)
1. Turn the VOLUME / POWER DIAL OFF to on the headphones.
2. Insert one end of the audio cable into the audio socket at the bottom of the headphones.
3. Insert the other end of the cable into the headphone socket of your audio source.
4. Your headphones are ready for use.
USING YOUR UNIT AS A SOUND MONITORING DEVICE
1. Place the transmitter near the area you want monitored and aim the microphone towards it. MIC
2. Move the FUNCTION SWITCH of the transmitter to the position and the Power LED will come on. MNT
3. Turn on the VOLUME / POWER DIAL and the Power LED of the receiver will come on.
4. Press the button, then theRESET SCAN button until the channel of your source is heard.
LISTENING TO THE RADIO
1. Press the button on the headphones to automatically search for FM radio channels.SCAN
2. The headphones will automatically lock onto any received FM radio channels.
3. If your chosen station is not found, press the button and repeat this step.RESET
SAVING BATTERY POWER – SWITCHING OFF YOUR UNIT
Save battery power by turning off your unit when not in use:
1. Move the FUNCTION SWITCH on the transmitter to the position.OFF
2. Turn the VOLUME / POWER DIAL OFF on the headphones to the position.
3. The Power LEDs on the transmitter and headphones will turn off.
Remove batteries when not in use for long periods.
A B C

Produkt Specifikationer

Mærke: Liquid Ears
Kategori: Hovedtelefoner
Model: HW8900BK
