Side 1/20

Before operating this vehicle, please read all printed materials thoroughly.

Horizon Hobby is not responsible for inadvertent errors in this manual.

INSTRUCTION MANUAL

BEDIENUNGSANLEITUNG

MANUEL D’UTILISATION

MANUALE DI ISTRUZIONI

1/14-SCALE ELECTRIC 4WD BUGGY

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING: Read the ENTIRE instruction manual to become familiar with

the features of the product before operating. Failure to operate the product correctly

can result in damage to the product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common

sense and requires some basic mechanical ability. Failure to operate this Product in a

safe and responsible manner could result in injury or damage to the product or other

property. This product is not intended for use by children without direct adult supervi-

sion. Do not use with incompatible components or alter this product in any way outside

of the instructions provided by Horizon Hobby, LLC. This manual contains instructions for

safety, operation and maintenance. It is essential to read and follow all the instructions

and warnings in the manual, prior to assembly, setup or use, in order to operate correctly

and avoid damage or serious injury.

WARNING AGAINST COUNTERFEIT PRODUCTS

Always purchase from a Horizon Hobby authorized dealer to ensure authentic

high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty

with regards, but not limited to, compatibility and performance of counterfeit products

or products claiming compatibility with DSM or Spektrum technology.

NOTICE

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC.

For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product.

MEANING OF SPECIAL LANGUAGE

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superﬁcial injury.

SAFETY PRECAUTIONS AND WARNINGS

• Always keep a safe distance in all directions around your model to avoid collisions

or injury. This model is controlled by a radio signal subject to interference from

many sources outside your control. Interference can cause momentary loss of control.

• Always operate your model in open spaces away from full-size vehicles, trafﬁc and people.

• Always carefully follow the directions and warnings for this and any optional support

equipment (chargers, rechargeable battery packs, etc.).

• Always keep all chemicals, small parts and anything electrical out of the reach of children.

• Always avoid water exposure to all equipment not speciﬁcally designed and protected

for this purpose. Moisture causes damage to electronics.

• Never place any portion of the model in your mouth as it could cause serious injury

or even death.

• Never operate your model with low transmitter batteries.

updates and more. Click on the Support tab at www.LOSI.com and follow the product

registration link to stay connected.

COMPONENTS

• 1/14-Scale Mini 8IGHT™ Desert Buggy RTR vehicle

• Spektrum™ STX2™ 2-CH Radio (SPMSTX200)

• Spektrum™ SRX200 2-CH receiver (SPMSRX200)

• Dynamite

Mini Brushless Waterproof ESC, 25A (DYNS1425)

• Dynamite

Fuze™ Mini Brushless Motor, 3800Kv (DYNS1409)

• Mini Servo (SPMS500)

• Dynamite

7.2V 1200mAh Ni-MH Battery Long with EC3™ Connector (DYN1473)

• Dynamite

100 mA AC NiMH Wall Charger with EC3™ Connector

• 4 AA batteries (for transmitter)

RECOMMENDED ACCESSORIES

• Soft bristle brush for cleaning

• #0 or #1 Phillips screwdriver

• 1.5mm and 2.0mm Hex driver

• Thread Lock

TOOLS INCLUDED

• Turnbuckle Wrench

• 4-Way Wrench

• 1.5mm and 2.0mm Hex ˝L˝ Wrench

Use only Dynamite

tools or other high-quality tools. Other tools can cause damage to the

small screws and parts used on this model.

TABLE OF CONTENTS

Components ................................................................................................................2

Recommended Accessories ..................................................................................... 2

Tools Included ........................................................................................................2

Contents ...................................................................................................................... 3

Water-Resistant Vehicle with Waterproof Electronics ......................................................3

Quick Start ................................................................................................................... 3

Charging Warnings .......................................................................................................4

Charging the Battery ....................................................................................................4

Installing the Battery and Powering ON the Vehicle .......................................................4

Specktrum STX2 Radio System ......................................................................................5

Installing the Transmitter Batteries .......................................................................... 5

Binding ........................................................................................................................ 5

Changing the Throttle Limit ..........................................................................................5

Control Test ..................................................................................................................6

Before Running Your Vehicle ......................................................................................... 6

Driving Precautions ......................................................................................................6

Run Time ......................................................................................................................6

Getting Started ............................................................................................................6

Operation .....................................................................................................................6

Mini Brushless Waterproof ESC .....................................................................................7

Fuze Mini Brushless Motor, 3800Kv ..............................................................................7

Tuning, Adjusting & Maintaining your Vehicle ................................................................ 8

Service/Repair ..............................................................................................................8

Troubleshooting Guide .................................................................................................8

Limited Warranty ..........................................................................................................9

FCC Information .........................................................................................................10

IC Information ............................................................................................................10

EU Compliance Statement ..........................................................................................10

Parts Listings ........................................................................................................ 35–36

Optional Parts ............................................................................................................36

Exploded View .....................................................................................................37–41

Setup Sheet ..........................................................................................................42–43

LOSI MINI 8IGHT-DB RTR • INSTRUCTION MANUAL

Produkt Specifikationer

Mærke:	Losi
Kategori:	Radiostyret legetøj
Model:	Mini 8ight DB
Bredde:	208 mm
Højde:	118 mm
Vægt:	1:14
Brugervejledning:	Ja
Batterispænding:	7.2 V
Batterikapacitet:	1200 mAh
Motortype:	Elektrisk motor
Produkttype:	Buggy
Batteriteknologi:	Nikkel-Metalhydrid (NiMH)
Husmateriale:	Aluminium
Batterier inkluderet:	Ja
Længde:	335 mm
Antal kanaler:	2 kanaler
Konstruktionstype:	Klar til at løbe (RTR)
Husets farve:	Hvid
Batterier påkrævet:	Ja
Lejeteknologi:	Kugleleje
Drevtype:	4-hjuls træk (4WD)
Elektronisk hastighedskontrol (ESC):	Ja
Sender:	Ja
Akselafstand:	223 mm
Elektronisk hastighedskontrol (pr. ESC) type:	Børstefri
Indbygget servo:	Ja
Senderfrekvens:	2.4 GHz
Afstand:	28 mm
