Side 1/48
SS13
LIMLINE WIRELES
SWITCH
USER MANUAL 3
GEBRAUCHSANLEITUNG 10
GUIDE UTILISATEUR 16
MODO DE EMPLEO 23
MANUALE D’ISTRUZIONI 30
GEBRUIKSAANWIJZING 37
20146/20061012 • SS13 TM SLIMLINE WIRELESS SWITCH
ALL RIGHTS RESERVED MARMITEK © 2007
TM
SS13
SLIMLINE WIRELESS
SWITCH
2 © MARMITEK
USER MANUAL SS13™
WIRELESS SWITCH
SAFETY WARNINGS
• To prevent short circuits, this product should only be used inside and
only in dry spaces. Do not expose the components to rain or moisture.
Do not use the product close to a bath, swimming pool etc.
• Do not expose the components of your systems to extremely high
temperatures or bright light sources.
• Do not open the product: the device contains live parts. The product
should only be repaired or serviced by a qualified repairman.
• In case of improper usage or if you have opened, altered and repaired
the product yourself, all guarantees expire. Marmitek does not accept
responsibility in the case of improper usage of the product or when the
product is used for purposes other than specified. Marmitek does not
accept responsibility for additional damage other than covered by the
legal product responsibility.
• This product is not a toy. Keep out of reach of children.
• Batteries: keep batteries out of the reach of children. Dispose of
batteries as chemical waste. Never use old and new batteries or
different types of batteries together. Remove the batteries when you
are not using the system for a longer period of time. Check the polarity
(+/-) of the batteries when inserting them in the product. Wrong
positioning can cause an explosion.
• Automatic switching devices provide comfort, but can also be
dangerous. They can surprise people or can ignite clothing hanging
over an electric heat source. Please be careful and take appropriate
measures to avoid accidents.
How does Marmitek X-10 work?
Marmitek X-10 components use the existing mains wiring to communicate
(using Marmitek X-10 signals). You can build a complete system using the
three different kind of components of the Marmitek X-10 System:
3SS13TM
ENGLISH
1. Modules: These components will receive Marmitek X-10 signals and
will switch or dim the attached lamp or appliance.
2. Controllers: These components will transmit Marmitek X-10 signals and
thus will control the Modules.
3. Transmitters: Wireless components like remotes. The signals of these
components will be received by a controller with transceiver
functionality (IRRF 7243, TM13 or console of a Marmitek
Security System).
The Transceiver will translate the signals into Marmitek X-10
signals on the power line.
Addresses
Up to a maximum of 256 different addresses can be preset. These are
subdivided into a so-called HouseCode (A to P incl.) and a UnitCode (1 to 16
incl.). The HouseCode can also be set on the controllers, so that the
controllers and modules become part of the same system. The address can be
set either using code dials or by pressing buttons, depending on the type of
module.
The Marmitek X-10 System uses standard commands, which control all units
with the same HouseCode at the same time (e.g. all lights on, all off, etc.).
Signal Range
Range of Marmitek X-10 signals over the Power Line and how to
increase the range.
The Marmitek X-10 System is based on power line communication. The
range of the Marmitek X-10 signals very much depends on the local
circumstances. On average the range is a cable length of 80 meters.
If you have difficulties with the range of your Marmitek X-10
signals, please pay attention to the following facts:
1. When more than one phase is used for your electrical system, it is
necessary to couple these phases for the Marmitek X-10 signals.
For coupling you can use FD10 Phase Couplers/Filters. You only need to
install a Phase Coupler/Filter when your wall outlets and light switches are
divided over more than one phase (more than one group is no problem).
For bigger buildings or longer distances we advice you to use an active
repeater instead of passive FD10’s.
2. It is possible that Marmitek X-10 signals are attenuated by devices and
lights which are connected to the power line. In a normal home situation
this effect is negligible (the Marmitek X-10 system is using active gain
control to eliminate the effects). However, it is possible that a particular
4 © MARMITEK
device in your house is attenuating the signals so much that the range of
Marmitek X-10 signals is decreased significantly. When you have range
problems, it is wise to try to locate the device which is attenuating the
signals simply by unplugging devices from the power line, and testing the
differences in range for your Marmitek system. When e.g. your conclusion
is that e.g. your computer monitor is attenuating the signal, you can use a
FM10 Plug-in Filter between the power line and the monitor to eliminate
the effects.
Known devices which can cause attenuation are:
PC Monitors
PCs with heavy internal power supplies
Old Televisions
Copiers
Fluorescent Lights
Gas Discharge Lamps (Energy Saving Lamps)
3. Some (old) devices are able to disturb the signal by transmitting noise on
the power line. Because the Marmitek X-10 signals are transmitted on 120
kHz, only noise on or near this frequency will have influence on the range.
When you use a FM10 Filter to connect this device to the power line, the
noise will be filtered.
4. The Marmitek X-10 protocol has several mechanism to avoid modules to
be switched on or off by other sources than your Marmitek X-10 Controllers.
However, it is possible that the Marmitek X-10 signals are disturbed by e.g.
baby phones which are in TALK mode (continuous transmission). When
these kind of signals are present on the power line it is possible that the
Marmitek X-10 signals will not come through.
5. The mains do not stop at the front door of your home. Everything that is
attached to mains nearby your home can have influence on Marmitek X-10
signals (e.g. heavy machinery). If you think that your system is influenced by
devices out of your house, it is advisable to install FD10 Phase Coupler/Filter
on each phase entering the house. These filters will block signals coming
into or going out of your house, but will also match the impedance for the
mains. The FD10’s will not only filter but will also couple the phases (please
see 1).
5SS13TM
ENGLISH
INSTRUCTIONS FOR USE SS13™
WIRELESS SWITCH
INTRODUCTION
Congratulations buying the Marmitek X-10 SS13 wireless switch. This is a
super thin, elegant wireless switch. It is the ideal solution for situations
where an extra switch is needed without installing wires. It is to install on
walls, glass, doors tables etc. and transmits high frequent signals through
walls and ceilings. The SS13 wireless switch transmits radio graphical signals
to an X-10 Transceiver TM13, IRRF7243 or Marmitek X-10 Alarm station.
Then the Transceiver or Station transmits these signals via the in your house
already installed electric wiring. Through this you can switch on and off
your lighting (or apparatus) connected to X-10 receivers (lighting can be
dimmed also). The SS13 is completely wireless and battery powered.
PROPERTIES
The switches are delivered standard at HouseCode A. The top button serves
UnitCode 1, the next one 2, and the 3rd button UnitCode 3. The bottom
button is the dim button. The dim button works for the last activated
UnitCode.
Change of the HouseCode
1. Press the top button ON and keep it pressed. The red LED flashes shortly.
After 3 seconds the present set-up is shown: 1 flash is HouseCode A, 2
flashes is HouseCode B etc.
2. Release the top button ON.
3. Now press shortly for the desired HouseCode on the same top ON
button (1x = A, 2x = B etc). The LED flashes every time you press the
button.
4. At the last time keep the button pressed. After 3 seconds the LED shows
the set-up HouseCode. Now release the button.
Change of the UnitCode
When setting up the UnitCode the top button is set up in the desired
UnitCode. The next buttons are always automatically one UnitCode higher
than the button directly above it ( for instance, when you set up the first
button to UnitCode 6 then the next button is automatically UnitCode 7
6 © MARMITEK
and the next on 8).
1. Press the top OFF button and keep it pressed. The red LED flashes
shortly. After 3 seconds the present set up is shown: 1 flash is UnitCode
1, 2 flashes is UnitCode 2 etc.
2. Release the top OFF button.
3. Now press shortly for the desired UnitCode on the same top OFF button
(1x = 1; 2x = 2 etc.) The Led flashes every time you press the button.
4. At the last time keep the button pressed. After 3 seconds the LED shows
the set-up UnitCode. Now release the button.
Change of the battery
Open the sliding drawer at the back of the switch and replace the battery.
Use an identical 3V lithium battery (type CR2032). Mind the polarity when
replacing.
APPLICATIONS
With the Marmitek X-10 SS13 wireless switch in combination with the
TM13 you can activate pre-programmed macros in the CM11 computer
interface.
You can also use the SS13 as a central operation panel for your Marmitek
installation (max. 3 unique UnitCodes.).
FREQENTLY ASKED QUESTIONS
What is the reason for modules to switch on/off spontaneously?
It is possible that a Marmitek X-10 System is installed at one of your
neighbours using the same HouseCode. To solve this problem try to change
the HouseCode of your system, or have FD10 Phase Coupler/Filter installed
at your incoming mains.
My modules will not respond to my controller.
Make sure that the HouseCode on all Modules and Controllers are set to
the same HouseCode (A .. P).
My modules will not react to my remote / sensor.
When you use a remote or sensor, you should have at least one TM13
Transceiver or Marmitek Security Console installed in your house. These
components will translate the radio signals to the Marmitek X-10 signal on
7SS13TM
ENGLISH
the power line. Only one Transceiver should be installed for all remotes and
sensors set to the same House Code.
Am I able to increase the range of my remotes by using more
Transceivers?
Yes, you can use more than one TM13 Transceiver in your home when the
range of your remotes is not sufficient. The TM13 is using so called collision
detection to prevent signals to be disturbed when more than one TM13 is
transmitting. TM13’s will wait for a quite power line before transmitting
their data. To prevent your Marmitek X-10 System to become slow or to
prevent dimming from becoming less smooth, make sure that the TM13
units are placed as far away from each other as possible.
The other modules do not respond to signals of the SS13. What can
be the problem?
• Check if the SS13 has been set-up correctly. The easiest way to do this
is to give again the correct HouseCode to the top button.
• Has the battery been placed correctly?
• The SS13 uses a Transceiver module (TM13, IRRF7243 or one of the
Marmitek X-10 alarm stations). Check if it works properly, for instance
to use another remote control.
• Maybe the range of the SS13 is not sufficient for your purpose; if so,
when using a TM13, place an extra TM13 in the neighbourhood of
your SS13.
Do you still have questions? Please check out www.marmitek.com
for more information.
8 © MARMITEK
TECHNICAL DATA
Supply: 1x CR2032 3V lithium battery (supplied)
RF range: Up to 30m free field, up to 20m through walls and
ceilings
RF frequency: 433,92 MHz
RF power: 1mW
X-10 Key codes: On, off, dim, bright
Ambient temperature: - 10° C to + 50° C (operation)
- 20° C to + 70° C (storage)
Dimensions: 115x70x7mm
9SS13TM
ENGLISH
Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this symbol on
the product and/or its packaging must not be disposed of with unsorted municipal
waste. The symbol indicates that this product should be disposed of separately from
regular household waste streams. It is your responsibility to dispose of this and
other electric and electronic equipment via designated collection facilities appointed
by the government or local authorities. Correct disposal and recycling will help prevent potential
negative consequences to the environment and human health. For more detailed information
about the disposal of your old equipment, please contact your local authorities, waste
disposal service, or the shop where you purchased the product.
GEBRAUCHSANLEITUNG
SS13™DRAHTLOSER SCHALTER
SICHERHEITSHINWEISE
• Um Kurzschluss vorzubeugen, dieses Produkt bitte ausschließlich innerhalb des
Hauses und nur in trockenen Räumen nutzen. Setzen Sie die Komponenten
nicht Regen oder Feuchtigkeit aus. Nicht neben oder nahe eines Bades,
Schwimmbades usw. verwenden.
• Setzen Sie die Komponente Ihres Systems nicht extrem hohen Temperaturen
oder starken Lichtquellen aus.
• Das Produkt niemals öffnen: Das Gerät enthält Bestandteile mit
lebensgefährlicher Stromspannung. Überlassen Sie Reparaturen oder Wartung
nur Fachleuten.
• Bei einer zweckwidrigen Verwendung, selbst angebrachten Veränderungen
oder selbst ausgeführten Reparaturen verfallen alle Garantiebestimmungen.
Marmitek übernimmt bei einer falschen Verwendung des Produkts oder bei
einer anderen Verwendung des Produktes als für den vorgesehenen Zweck
keinerlei Produkthaftung. Marmitek übernimmt für Folgeschäden keine andere
Haftung als die gesetzliche Produkthaftung.
• Dieses Produkt ist kein Spielzeug. Außer Reichweite von Kindern halten.
• Batterien: Halten Sie die Batterien außerhalb der Reichweite von Kindern.
Liefern Sie die Batterien als chemischen Kleinabfall ein. Verwenden Sie niemals
alte und neue oder unterschiedliche Typen von Batterien durcheinander. Wenn
Sie das System längere Zeit nicht benutzen, entfernen Sie die Batterien.
Achten Sie beim Einlegen der Batterien auf die Polarität (+ / -): Ein falsches
Einlegen kann zu Explosionsgefahr führen.
• Automatisches Schalten ist nicht nur bequem, sondern kann auch Gefahr
bedeuten. So können Personen überrascht werden, oder kann Kleidung, die
über eine elektrische Wärmequelle hängt in Brand geraten. Passen Sie immer
auf und treffen Sie Maßnahmen um dies zu verhindern.
WIE FUNKTIONIERT MARMITEK X-10?
Die Komponenten aus dem Marmitek X-10 Sortiment kommunizieren mit
einander über das bestehende Lichtnetz (mittels Marmitek X-10 Signalen).
10 © MARMITEK
Produkt Specifikationer
| Mærke: | Marmitek |
| Kategori: | Ikke kategoriseret |
| Model: | SS13e |
Har du brug for hjælp?
Hvis du har brug for hjælp til Marmitek SS13e stil et spørgsmål nedenfor, og andre brugere vil svare dig
Ikke kategoriseret Marmitek Manualer
7 Oktober 2024
17 September 2024
21 August 2024
16 August 2024
15 August 2024
14 August 2024
12 August 2024
12 August 2024
11 August 2024
11 August 2024
Ikke kategoriseret Manualer
- Alpine
- TC Electronic
- Heitronic
- Theragun
- Eversolo
- Draper
- NUVO
- Jahnke
- AudioControl
- WyreStorm
- Dali
- SBS
- Shimano
- Playmobil
- ADDAC System
Nyeste Ikke kategoriseret Manualer
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
