Side 1/14

3. Select AMCAP application from Start menu as

shown below.

Introduction

Thank you for buying this high quality video webcam.

Following information will help you to use your cam-

era to its full capabilities. For viewing pictures or video,

camera must be connected to your personal computer.

This camera supports Microsoft Video Class and

Plug&Play directly without driver. For using special

features like “face tracking” or “snapshot” please

follow software installation steps.

System requirements

¯ Pentium IV 1GHz or higher CPU

¯ 500MB free hard disk space

¯ CD-ROM drive

¯ 512MB RAM

¯ VGA card with DirectX 9.0 support

¯ Windows 2000/XP SP2/Vista/7

¯ Internet connection

¯ Free USB 2.0 port

Package content

¯ WebCam

¯ Software CD-ROM

¯ User manual

Hardware installation

Please plug camera into free USB 2.0 port

COMQ

Instructions Manual

PC Camera for Teleconferencing & Video Surveillance

MT4028

Software installation

Note: Please make sure the WebCam is plugged in

the USB port before proceeding.

1. Insert software disc into CD-ROM drive. If installa-

tion will not start automatically, open Setup.exe

from CD-ROM root folder.

2. When installation is completed, webcam icon will

appear in system tray.

Using AMCAP software

Video Preview

Click AMCAP to run application, if you cannot see the

picture click “Options” and choose “Preview” to enable

video preview.

Snapshot function

To capture a still image, right click on the webcam icon

form system tray and then select “Snapshot” and your

desired image size. A screen with a preview of the tak-

en photo will appear. To save the photo choose “File”

and then “Save as” and specify  lename.

Changing

video

resolution

Select “Options”

and then “Video

Capture Pin” to

open following

window.

Note: any higher then VGA resolution will decrease

transmisson speed (fps) due to USB bandwitch.

Recording a video

Open AMCAP, click the “Capture“ then “Start Capture“,

specify  lename and patch then click „OK“ to start cap-

turing. Select “Stop Capture“ to  nish recording.

Advanced settings

Open AMCAP, select “Options” and then “Video capture

 lter” – following window will appear.

„Settings“ tab

Here you can adjust basic image corrections. You can

also choose „low light“ when working in dark condi-

tions or choose frequency to match your power grid

freqency rate (50Hz or 60Hz).

“E ect” tab

Here you can select image e ect and image frame for

captured video.

„Zoom“ tab

Here you can enable „Face tracking“ function and con-

trol „Zoom“ function.

Note: „Face tracking“ works only in VGA mode.

Setting focus

To adjust focus rotate lens ring to left/right to achieve

desired focus range.

Precautions

¯ Do not touch camera lens with hand, sharp or coarse

stu , always use clean and soft cloth for cleaning.

¯ Do not use it in extremely hot, cold, dusty or humid

circumstances.

¯ Avoid mechanical shocks not to damage the glass

lens.

Note: Heat emission is a normal e ect when web-

cam is working.

Camera Speci cation

¯ High Resolution Digital Camera CMOS Sensor

¯ Video mode: RGB24 or YUY2

¯ Interface: USB2.0

¯ Max transmission rate: 640x480@30fps

¯ Image focus: 3cm to in nity

¯ Non-Compression Image Processor

¯ AWB (Automatic White Balance)

¯ Manual Focus Function

¯ 5-layer glass lens

¯ Built-in Microphone

¯ Face tracking function (software enabled)

¯ Photo frame function (software enabled)

Advanced settings can be accessed by right click on

webcam icon from system tray.
