Introduction

Thank you for buying this high quality video webcam.

Following information will help you to use your cam-

era to its full capabilities. For viewing pictures or video,

camera must be connected to your personal computer.

This camera supports Microsoft Video Class. For

using special features like “face tracking” or “snap-

shot” please follow software installation steps.

System requirements

¯ Pentium IV 1GHz or higher CPU

¯ 500MB free hard disk space

¯ CD-ROM drive

¯ 512MB RAM

¯ VGA card with DirectX 9.0 support

¯ Windows 2000/XP/Vista/7

¯ Internet connection

¯ Free USB 2.0 port

Package content

¯ WebCam ¯ Software CD-ROM ¯ User manual

Hardware installation

Z-CAM

User Manual

Mini PC USB Camera

MT4029

Software installation

Note: Please don’t plug the WebCam into USB port

before CD installation.

1. Insert software disc into CD-ROM drive. If installa-

tion will not start automatically, open Setup.exe

from CD-ROM root folder.

Click on “Next” “Continue Anyway” “Finish”

2. Plug your camera into free USB port, the system will

detect the device and complete the installation au-

tomatically.

3. When installation is completed, webcam icon will

appear in system tray.

Using AMCAP software

Video Preview

Click AMCAP to run application, if you cannot see the

picture click “Options” and choose “Preview” to enable

video preview.

Snapshot function

To capture a still image, right click on the webcam

icon form system tray and then select “Snapshot” and

your desired image size. A screen with a preview of

the taken photo will

appear. To save the

photo choose “File”

and then “Save as”

and specify  lename.

Changing

video

resolution

Select “Options” and

then “Video Capture

Pin” to open follow-

ing window.

4. Select AMCAP application from Start menu as

shown below.

Setting focus

To adjust focus rotate lens ring to left/right to achieve

desired focus range.

Precautions

¯ Do not touch camera lens with hand, sharp or coarse

stu , always use clean and soft cloth for cleaning.

¯ Do not use it in extremely hot, cold, dusty or humid

circumstances.

¯ Avoid mechanical shocks not to damage the glass

lens.

Note: Heat emission is a normal e ect when web-

cam is working.

Camera Speci cation

¯ High Resolution CMOS Sensor

¯ Max transmission rate: up to 30fps@640x480

¯ Still image capture up to 8 Mega pixels

with software interpolation

¯ Image focus: 3cm to in nity

¯ Non-Compression Image Processor

¯ AWB (Automatic White Balance)

¯ Manual Focus Function

¯ Built-in Microphone

¯ Face tracking function (software enabled)

¯ Photo frame function (software enabled)

¯ Interface: USB2.0

„Face tracking” tab

Here you can enable „Face tracking“ function.

Note: „Face tracking“ works only in VGA mode.

Note: any higher then VGA resolution will decrease

transmisson speed (fps) due to USB bandwitch.

Recording a video

Open AMCAP, click the “Capture“ then “Start Capture“,

specify  lename and patch then click „OK“ to start cap-

turing. Select “Stop Capture“ to  nish recording.

Advanced settings

Open AMCAP, select “Options” and then “Video capture

 lter” – following window will appear.

„Settings“ tab

Here you can adjust basic image corrections. You can

also choose „low light“ when working in dark condi-

tions or choose frequency to match your power grid

freqency rate (50Hz or 60Hz).

“E ect” tab

Here you can select image e ect and image frame for

captured video.
