CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

I N S TA L L AT I O N I N S T R U C T I O N S

99-5846B

KIT FEATURES

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Touchscreen display for climate and personalization features

• Integrated hazard button and passenger airbag light

• Radio can be mounted up top or at bottom

• Painted Matte Black

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 10mm & 9/32” Socket wrench

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Preparation .......................................................3

Kit Assembly

–ISO DIN radio provision with pocket ..................4

–ISO DDIN radio provision .....................................4

Axxess Interface Installation ............................5-13

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Axxess interface built into touchscreen

Antenna Adapter: Included

Ford F-150 (with 4.2” screen) 2013-2014

KIT COMPONENTS

• A) Radio/Display trim panel with touchscreen display • B) Radio/Display sub-trim panel upper (a) • C) Radio/Display sub-trim panel lower (b)

• D) Radio brackets upper (a)

• E) Radio brackets lower (b) • F) Pocket • G) (4) Panel clips • H) (11) #6 x 3/8” Phillips pan-head screws

• I) (4) #8 x 3/8” Phillips truss-head screws • J) Touchscreen display assembly and wiring harness

• K) Antenna adapter (not shown)

A B C D

H I J

E F G

1.800.221.0932

MetraOnline.com

DASH DISASSEMBLY

1. Open and lower the glove box, then

remove (3) 10mm bolts from inside the

glove box facing up. (Figure A)

2. Remove (1) 7mm screw securing the

trim panel to the right of the radio, then

unclip and set to the side. (Figure B)

3. Remove (4) 9/32” screws securing

the radio/climate control panel to the

dash, then unclip, unplug, and remove.

(Figure C)

4. Remove (4) 9/32” screws securing the

radio chassis, then unplug and remove.

(Figure D)

5. Remove (4) 9/32” screws securing

the factory display, then unplug and

remove. (Figure D)

6. Unsnap, unplug, and remove the

traction control button and save for kit

assembly.

Continue to Kit Preparation

(Figure C)(Figure A)

(Figure B)

(Figure D)
