Side 1/10

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

AX-DSP

INSTALLATION INSTRUCTIONS

INTERFACE FEATURES

INTERFACE COMPONENTS

TOOLS REQUIRED

• Cutting tool • Crimping tool • Tape

• Connectors (example: butt-connectors, bell

caps, etc.)

TABLE OF CONTENTS

Installation Options ...............................................2

Installing the AX-DSP .............................................2

Wire Description

(20-pin Microﬁt)..................................................3

(16-pin Microﬁt) ..................................................4

DSP application .................................................4-10

Axxess Digital Signal Processor

• 31 Band graphic EQ

• 6 Inputs and 6 Outputs, including front, rear and subwoofer

• Selectable High and Low level inputs

•

Front, rear and subwoofer outputs have an independent two-way

crossover in-line with the EQ

• Front and rear outputs can be delayed independently up to 10ms

• Easy behind the radio installation

• Can be used with OE and aftermarket radios

• Chime control for vehicles with amp-generated chimes (When

retaining OEM radio)

• Retains Sonar sensors in vehicles where the tone is provided by the

ampliﬁer(when retaining OEM radio)

• Clipping detection and limiting circuits

• Retains OE voice prompts (SYNC and OnStar)

• Settings adjusted via Bluetooth application, compatible with both

Android and Apple devices

• Read, Write, and Store your conﬁguration for future recall

• DSP interface

• Universal harness

INSTALLATION OPTIONS INSTALLING THE AX-DSP

Attention!:

Axxess has created a line of vehicle speciﬁc T-harnesses for the AX-DSP. We highly recommend

that you purchase the T-Harness to cut down on installation time and mistakes.

Please visit www.axxessinterfaces.com for T-harness options.

OE Radio with Digital Ampliﬁer

Digital systems work differently from analog. They have a ﬁxed level output that is controlled through the

vehicle’s CAN Bus. Most of the time the programming content (audio) is provided through two channels, this can

be front or rear. The other channels are for content like Phone/Bluetooth, SMS reader, SYNC, or OnStar. The AX-DSP

retains these OE features.

Adding a Subwoofer to OE System

This feature offers the installer the ability to add a subwoofer to an OE system. Whether the OE ampliﬁer is digital

or analog, the AX-DSP will output a usable signal to feed the aftermarket ampliﬁer while maintaining the OE

features.

OE Radio with Analog Ampliﬁer

This option will allow the installer to tap directly to the output of the factory radio and feed signal into the DSP.

Aftermarket Radio System

The AX-DSP can be used in the aftermarket environment to improve the overall listening experience for car audio

enthusiasts. Installers will plug the RCA inputs of the AX-DSP into the output of the aftermarket radio and continue

with the normal installation process. When using an aftermarket radio and setting up the DSP in the Conﬁguration

tab, General must be chosen from the vehicle type button.

OE Radio without factory ampliﬁer

This option will allow the installer to wire directly into the output of the factory radio for signal and feed it through

the DSP to the aftermarket ampliﬁers. In many cases the CAN Bus wires need to be connected in order for the DSP

to communicate with the vehicle to turn on and give your installer a 12-volt 150mA remote turn-on output.

It is highly advisable to read the following steps beforehand, to ensure a clear

understanding of what is to be expected. The following steps must be done in the

order that they are numbered.

With the vehicle completely off:

AX-DSP is designed to be installed behind the OE radio:

1. Download AX-DSP app from Google Play Store or the Apple Store.

2. Remove the factory radio, we recommend you refer to

www.metraonline.com, use our vehicle ﬁt guide to get dash disassembly

instructions.

3. Unplug all connectors from radio.

4. Install vehicle speciﬁc T-harness.

5. Plug 20-Pin AX-DSP harness into the DSP.

6. Plug 16-Pin output harness into the DSP.

7. Plug all connectors back into factory radio.

8. Plug in all applicable RCA’s, leave ampliﬁer turn on wire disconnected until

DSP setup is complete.

9. Using the app, select the vehicle.

10. Connect the ampliﬁer turn-on wire.

11. Test and reassemble.
