MCP46XX PICtail™ Plus Daughter Board User’s Guide
DS51804A-page iv © 2009 Microchip Technology Inc.
NOTES:
MCP46XX PICTAIL™ PLUS
DAUGHTER BOARD USER’S GUIDE
© 2009 Microchip Technology Inc. DS51804A-page 1
Preface
INTRODUCTION
This chapter contains general information that will be useful to know before using the
MCP46XX PICtail™ Plus Daughter Board. Items discussed in this chapter include:
• Document Layout
• Conventions Used in this Guide
• Recommended Reading
• The Microchip Web Site
• Customer Support
• Document Revision History
DOCUMENT LAYOUT
This document describes how to use the MCP46XX PICtail™ Plus Daughter Board as
a development tool to emulate and debug firmware on a target board. The manual
layout is as follows:
•Chapter 1. “Product Overview” – Important information about the MCP46XX
PICtail™ Plus Daughter Board.
•Chapter 2. “Installation and Operation” – Includes instructions on how to get
started with this user’s guide and a description of the user’s guide.
•Appendix A. “Schematic and Layouts” – Shows the schematic and layout
diagrams for the MCP46XX PICtail™ Plus Daughter Board.
•Appendix B. “Bill Of Materials (BOM)” – Lists the parts used to build the
MCP46XX PICtail™ Plus Daughter Board.
•Appendix C. “Board Testing” – Describes the testing method for the MCP46XX
PICtail™ Plus Daughter Board and which aspects of the board are tested and
which are not.
NOTICE TO CUSTOMERS
All documentation becomes dated, and this manual is no exception. Microchip tools and
documentation are constantly evolving to meet customer needs, so some actual dialogs
and/or tool descriptions may differ from those in this document. Please refer to our web site
(www.microchip.com) to obtain the latest documentation available.
Documents are identified with a “DS” number. This number is located on the bottom of each
page, in front of the page number. The numbering convention for the DS number is
“DSXXXXXA”, where “XXXXX” is the document number and “A” is the revision level of the
document.
For the most up-to-date information on development tools, see the MPLAB® IDE on-line help.
Select the Help menu, and then Topics to open a list of available on-line help files.
MCP46XX PICtail™ Plus Daughter Board User’s Guide
DS51804A-page 2 © 2009 Microchip Technology Inc.
CONVENTIONS USED IN THIS GUIDE
This manual uses the following documentation conventions:
DOCUMENTATION CONVENTIONS
Description Represents Examples
Arial font:
Italic characters Referenced books MPLAB® IDE User’s Guide
Emphasized text ...is the only compiler...
Initial caps A window the Output window
A dialog the Settings dialog
A menu selection select Enable Programmer
Quotes A field name in a window or
dialog
“Save project before build”
Underlined, italic text with
right angle bracket
A menu path File>Save
Bold characters A dialog button Click OK
A tab Click the Power tab
N‘Rnnnn A number in verilog format,
where N is the total number of
digits, R is the radix and n is a
digit.
4‘b0010, 2‘hF1
Text in angle brackets < > A key on the keyboard Press <Enter>, <F1>
Courier New font:
Plain Courier New Sample source code #define START
Filenames autoexec.bat
File paths c:\mcc18\h
Keywords _asm, _endasm, static
Command-line options -Opa+, -Opa-
Bit values 0, 1
Constants 0xFF, ‘A’
Italic Courier New A variable argument file.o, where file can be
any valid filename
Square brackets [ ] Optional arguments mcc18 [options] file
[options]
Curly brackets and pipe
character: { | }
Choice of mutually exclusive
arguments; an OR selection
errorlevel {0|1}
Ellipses... Replaces repeated text var_name [,
var_name...]
Represents code supplied by
user
void main (void)
{ ...
}
MCP46XX PICtail™ Plus Daughter Board User’s Guide
DS51804A-page 4 © 2009 Microchip Technology Inc.
NOTES:
MCP46XX PICTAIL™ PLUS
DAUGHTER BOARD USER’S GUIDE
© 2009 Microchip Technology Inc. DS51804A-page 5
Chapter 1. Product Overview
1.1 INTRODUCTION
The MCP46XX PICtail™ Plus demonstrates the features and abilities Daughter Board
of Microchip’s MCP45XX and MCP46XX Digital Potentiometers. This board is
designed to exclusively use the MCP46XX devices.
The MCP45XX and MCP46XX are digital potentiometers with an I2C interface. These
devices have either 7 bits or 8 bits of resolution, single or dual offering, and are
available as either volatile or non-volatile memory options.
This board is designed to easily operate with any of the following:
• Explorer 16 Development Board (DM240001)
• PICkit™ Serial Analyzer (DV164122)
• Other PICDEM Demo Board that includes a PICtail Plus female connector
The use of the Explorer 16 Development Board (DM240001) will require a tool to
program the supplied firmware into the PIC24FJ128GA010 device. The use of any
other PICDEM Demo Board will require the user to modify the supplied “C” source
program appropriately.
The use of the PICkit Serial Analyzer will require the PC GUI interface program to
control the command and data sent to the MCP42XX devices serial port. The PICkit
Serial Analyzer GUI may be used.
This chapter covers the following topics:
• What is the MCP46XX PICtail™ Plus Daughter Board?
• What the MCP46XX PICtail™ Plus Daughter Board Kit includes.
