Motorola MTIDM042611 Manual

Motorola Overvågningskamera MTIDM042611

Læs gratis den danske manual til Motorola MTIDM042611 (2 sider) i kategorien Overvågningskamera. Denne vejledning er vurderet som hjælpsom af 11 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 6 anmeldelser. Har du et spørgsmål om Motorola MTIDM042611, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/2

Camera

CD Drill template

Quick guide

4 Screw plastic plugs

4 Tapping screws

PA 4X25

Security cap

1Mounting base

2Ethernet connection cable

3Power connection cable

IP DOME CAMERA

IP DOME VARIFOCAL CAMERA

Camera

CD Wrench Drill template

Quick guide

4 Screw plastic plugs

4 Tapping screws

PA 4X25

Please make sure that the wall or ceiling is strong

enough to withstand 3 times the weight of the camera.

Please install and use the camera in the dry environment.

1. Loosen the lock screw to disassemble the camera from

the mounting base.

2. Drill the screw holes and the cable hole on the

mounting surface using the available drill template.

3. Fix the mounting base to the mounting surface.

4. Route the cables through the cable hole and finally

connect the cables as needed.

1Mounting base

2Dome cover

3Locking screw

4Dome

5Ethernet connection cable

6Power connection cable

IP dome camera

Quick Guide

IP dome varifocal camera

•If the product does not work properly, please contact

your dealer or the nearest service center. Never

attempt to disassemble the camera yourself. Your

warranty will be voided if any problems are caused

by unauthorized repair or maintenance.

•

Handle with care and prevent dropping the camera.

When the product is mounted on a wall or ceiling,

ensure that the device is properly firmly fixed.

•Prevent touching the lens of the camera.

•

If cleaning is necessary, please use a clean cloth to

wipe it gently. If the device will not be used for a long

time, please cover the lens cap to protect the device

from dust.

Prevent aiming the camera directly to the sun or to

very bright environments.

•Do not place the camera in extrem hot or coldely

environments (operating temperature is -20˚C~50˚C),

dusty or damp locations.

• Para evitar exceso de calentamiento To avoid increase

in heat of product, good ventilation is required. •It is recommended to install the security cap for

outdoor installation.

•The 12 VDC power supply is not required if a PoE

network connection is used to power the camera, ..

Connecting the ethernet network cable

1. Loosen the cap nut from the main part.

2. Run the network cable (without RJ45 connector)

through the both parts. Then crimp the cable with

RJ45 connector.

3. Screw back and tighten cap to create a hermetic seal.

Quick Guide

•Please, read carefully these instructions before

operating your camera and save this as reference.

•All examples and images used in this guide are only

for reference.

•The content of this guide is subject to changes

without previous notice.

1. Precautions

2. Contents

3. Product overview

4. Installation

Produkt Specifikationer

Mærke:	Motorola
Kategori:	Overvågningskamera
Model:	MTIDM042611
Kode for international beskyttelse (IP):	IP66
Type:	IP-sikkerhedskamera
Højde:	102.5 mm
Vægt:	690 g
Produktfarve:	Black, White
Wi-Fi:	Ingen
Bluetooth:	Ingen
Formfaktor:	Kuppel
Understøttede videotilstande:	720p, 1080p
Relativ luftfugtighed ved drift (H-H):	0 - 95 %
Ethernet LAN-porte (RJ-45):	1
Ethernet LAN:	Ja
Webbrowser:	Ja
Understøttede videoformater:	H.264, H.265
Understøttede lydformater:	Ikke understøttet
Driftstemperatur (T-T):	-20 - 50 °C
Maksimal opløsning:	1920 x 1080 pixel
Husmateriale:	Metal
Understøttede grafikopløsninger:	480 x 240,1280 x 720 (HD 720),1920 x 1080 (HD 1080)
Forbindelsesteknologi:	Ledningsført
Strømforbrug (maks.):	6 W
Netværksstandarder:	IEEE 802.1x, IEEE 802.3af
DC-in-stik:	Ja
Understøttede netværksprotokoller:	TCP/IP UDP DHCP NTP RTSP PPPoE DDNS SMTP FTP, HTTPS, SNMP, 802.1X, QoS
Knap til nulstilling:	Ingen
IP-adresse filtrering:	Ja
Strømkilde type:	DC, PoE
Monteringstype:	Loft
Diameter:	120.4 mm
Indbygget kortlæser:	Ingen
Indbygget HDD:	Ingen
Video komprimeringsformater:	H.264, H.265
Understøttet placering:	Indendørs & udendørs
Antal brugere:	3 bruger(e)
Understøttede mobile operativsystemer:	Android, iOS
Indbygget mikrofon:	Ingen
Sensortype:	CMOS
Samlet antal megapixels:	2 MP
Støjreduktion:	Ja
Fokus:	Motoriseret
Firmware kan opgraderes:	Ja
Hældningsvinkelområde:	0 - 90 °
Progressiv scanning:	Ja
Bredt dynamikområde (WDR):	Ja
Dag/nat funktion:	Ja
Vandafvisende:	Ja
Minimumsbelysning:	0 Lux
Panoreringsområde:	0 - 360 °
Rotationsvinkel:	360 °
Antal sensorer:	1
Optisk sensorstørrelse:	1/2.7 "
Antal effektive pixels (HxV):	1920 x 1080 pixel
Maksimale blænderåbning tal:	1.4
Nattesyn:	Ja
Billedhastighed:	30 fps
Justering af billedkvalitet:	Brightness, Contrast, DNR, Saturation, Sharpness
Fortrolighedspolitik maskering:	Ja
Ethernet-grænsefladetype:	Hurtigt ethernet
Bevægelsessensor (video):	Ja
DC udgangsspænding:	12
Antal kameraer:	1
Brændviddeområde:	2.8 - 12 mm
Kameraets lukkerhastighed:	1/25 - 1/100000 sek./side
Kamera lukker type:	Elektronisk
Videostreaming:	Ja
Beskyttelse af adgangskode:	Ja
Nattesyn, afstand:	40 m
Intelligent Video Surveillance (IVS) systemfunktioner:	Crossing line, Intrusion
Bit-rate:	256 Kbps - 5 Mbps
Spejl:	Ja
Termisk rammehastighed (PAL):	50 Hz
Region of Interest (ROI) kodning:	Ja
Flip & spejl:	Ja
Termisk rammehastighed (NTSC):	60 Hz
Video intelligent analysering:	Ja
Kompensation for baggrundslys:	Ja
Highlight Compensation (HLC):	Ja
Digital Wide Dynamic Range (DWDR):	Ja
Hjerteslag:	Ja
Smart IR:	Ja
Støjreduktionsteknologi:	3D støjreduktion
Adfærdsanalyse:	Intrusion detection, Line crossing detection, Object removal detection
Digitalt vandmærke:	Ja
Bitrate kontrol:	Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Automatisk flip:	Ja
Administrationssoftware:	MVMS AI, MVMS ENTERPRISE
