M-56 IP

User Manual

MICRO SYSTEM WITH DOCKING FOR iPod/iPhone

Please read the instruction carefully before operating the unit.

English GB - 1

LOCATION OF CONTROLS

1. LED display

2. Standby indicator

3. Remote sensor

4. Standby button

5. PLAY/PAUSE button

6. STOP button

7. buttonSOURCE

8. , buttons: Skip / search / Tuning

9. controlVOLUME+/-

10. jackLINE IN

GB - 2

R1. Standby button

R2. button MUTE

R3. number buttons0-9,10+

R4. MENU/PROG button : To access iPod menu;

To program playback sequences.

R5. buttons : Folder down /upALB-/+

R6. ▲ button: To move up in iPod menu

R7. ▼ button: To move down iPod menu

R8. / / button: M- (MEMORY -)

Skip / search / Preset down

R9. / / button: M+ (MEMORY +)

Skip / search / Preset up

R10. buttonENTER

R11. buttons: TuningTUN-/+

R12. buttonsVOL+/-

R13. PLAY/PAUSE button

R14. buttonSOURCE

R15. buttonINTRO

R16. button REPEAT

R17. buttonRANDOM

R18. buttonAUTO/STOP

R19. button SLEEP

R20. buttonEQ

R21. buttonMEMORY/ VIDEO SELECT

R22. buttonST/MONO

Before throwing any batteries away, consult your distributor who may be able

to take them back for specic recycling.

REMOTE CONTROL

Installing Battery

Insert 2 “AAA/ UM4” batteries to the remote control prior to use. Make sure to match

their polarities (+/-) to the markings inside the compartment.

NOTES:

- Never recharge the batteries, apply heat to them or take them apart.

- If the remote control is not going to be used for a long time, remove the battery to

avoid damage caused by battery leakage corrosion.

- Attention should be drawn to the environmental aspects of battery disposal.

- Do not throw batteries in re!

- Battery shall not be exposed to excessive heat such as sunshine, re or the like.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the

same or equivalent type.

GB - 3

1.Press button to turn on the unit. STANDBY

2.The function is selected by pressing button repeatedly: CD, USB, FM SOURCE

RADIO, LINE IN (AUX IN) and iPod.

VOLUME

Turn VOLUME-/+ control to adjust the sound to comfortable level. The volume level will

be displayed for a few seconds.

MUTE

To cut off the sound from the speakers temporarily, press button on remote MUTE

control. The “MUTE” icon is shown on the display. Press button again to cancel MUTE

Mute mode and restore the sound from the speakers.

Press button on remote control to toggle among the different sound effects (FLAT EQ

/CLASSIC /ROCK /POP / JAZZ). The selection will show on display for few seconds.

DISC OPERATION

POWER SUPPLY

This set operates on AC 100-240V~ 50/60Hz.

Connect the power cord to a convenient AC wall outlet.

AUDIO CONTROLS

-By number buttons , 10+ 0-9

Use the number buttons to input the track number, and it will start playback from the

selected track automatically.

If you want to input the track number bigger than 9, use the , buttons. 10+ 0-9

Example 1, to select the 10th track, rstly press 10+ button once. “_ _” appears on

display, then press number button & . 1 0

Example 2, to select the 25th track, rstly press 10+ button once. “_ _” appears on

display, then press number button & . )2 5

GB - 4

USB OPERATION

1. Press button to turn on the unit.STANDBY

2. Connect an USB device to the USB port on unit.

3. Press button to select USB mode. Playback starts automatically.SOURCE

Notes:

- Do not put anything other than a USB device to the port of this unit. Other objects

may damage the USB mechanism.

- The USB socket must not be connected to the computer directly, for that may damage

the unit.

- There are many USB devices in the market. We cannot guarantee to support all

different models. Please try another USB device if your device is not supported.

Fast search backward/forward

Press and hold / to search quickly within a track.

Select a folder (mp3 only)

•Press ALB+ on remote control to select the rst track of next folder of your current

disc or USB.

•Press ALB- on remote control to select the rst track of previous folder of your current

disc or USB.

RADIO

Presetting radio stations

The unit can store up to 20 FM stations in its memory.

Manual preset

1. Tune to a desired station.

2. Press MEMORY button on remote control. “01” ashes on display.

3. Press on remote control to select a desired preset location. Press M-/+ MEMORY

again to save the radio station as the selected preset station.

4. Repeat above steps to preset a maximum of 20 stations.

Auto preset

In FM mode, press on remote control to start automatic preset programming. AUTO

Radio frequencies will be browsed and radio stations stored automatically. When all

the available radio stations are stored or all memory locations are full, the auto preset

programming function will stop.

Retrieving the preset stations

In radio mode, press on remote control to access a preset station.M-/+

GB - 5

PLAY MODES(CD/MP3 ONLY)

Intro playback

During playback, press button on remote control and “INTRO” appears on INTRO

display. It will start to play the rst 10 seconds of each track. Press INTRO button again

to cancel this function and “INTRO” disappears on display.

Repeat playback

Press button on remote control repeatedly to select a play mode:REPEAT

- Repeat One : display shows “REP”.

- Repeat folder :display shows “REP ALB”. (MP3 only)

- Repeat All : display shows “REP ALL”.

To cancel repeat playback, press button repeatedly until repeat indicator REPEAT

disappears.

Random playback

Press button on remote control and “RDN” appears on display. It will play all RANDOM

tracks in random order. Press button again to cancel this function and “RDN” RANDOM

disappears.

Program playback

1.In stop mode, press button on remote control. The display will show “P01” PROG

and ashing “00” (“000” for MP3 ).

2.Use number buttons to input the track number and press button to conform. PROG

3.Repeat above steps to program up to 32 tracks.

4.Press to start program playback.

5.Press button to stop the program playback and cancel this function.

11.USB port

12. Disc door open button

13.Disc compartment

14.iPod/iPhone dock

15.VIDEO OUT jack

16.FM antenna

17.AC cord

18.Speaker terminal

19.Speaker box

20.Speaker wire

SPEAKER CONNECTION

Connect the speaker wire of the speaker box to the speaker terminal on back of unit.

1. Press button to turn on the unit.STANDBY

2. Open the CD door by pushing the CD door Open button .

3. Place the CD with label side up inside the CD compartment and close the CD door.

4. Press the button to select CD function. The “CD” icon is displayed. SOURCE

Playback starts automatically.

BASIC OPERATION

Play/pause

Press to pause playback. Press again to resume.

Select a track

-By /

Press / to select a track.

Listening to the radio

1. Press button to turn on the unit.STANDBY

2. Press button to select Radio (FM) mode. “FM” appears on display.SOURCE

3. Tune to a desired station with / on unit or on remote control.TUN-/+

Note:

- For a better reception in FM, extend the antenna.

-If a stereo broadcast is received, “ST” is displayed. Press ST/MONO button on remote

control to switch between Mono and Stereo mode.

iPod/iPhone not included

R11

R12

R15

R19

R20

R10

R14

R18

R17

R22

R21

R13

R16

1919

20 20

HX-3188 IB MUSE 001 REV0 -GB.ind1 1 2011-12-27 17:25:01

Produkt Specifikationer

Mærke:	Muse
Kategori:	Hi-Fi system
Model:	M-56 IP
Type:	Home audio micro system
Bredde:	248 mm
Dybde:	140 mm
Højde:	141 mm
Vægt:	2000 g
Brugervejledning:	Ja
Produktfarve:	Sort
Skærmtype:	LED
Wi-Fi:	Ingen
USB-port:	Ja
Antal højttalere:	2
Udgangseffekt (RMS):	10 W
Equalizer:	Ja
Slumretimer:	Ja
Understøttede lydformater:	MP3
Integreret ur:	Ja
Fjernbetjening inkluderet:	Ja
Strømkilde:	Vekselstrøm
Understøttede disktyper:	CD, CD-R, CD-RW
Indbygget kortlæser:	Ingen
Baggrundsfarve:	Ravfarvet
Baggrundsbelysning:	Ja
AUX-indgang:	Ja
Understøttede radiobånd:	FM
RDS Tuner inkluderet:	Ja
MP3-afspilning:	Ja
Indgangsspænding:	100-240 V
Afspilningstilstande:	Program, Repeat
Lyd (L, R) udgang:	2
Indgangsfrekvens:	50 - 60 Hz
Kampatibilitet med Apple-docking:	iPhone, iPod
Antal forudindstillede stationer:	20
Snooze funktion:	Ja
CD-afspiller:	Ja
Kassettebåndoptager:	Ingen
Optisk diskafspiller:	Ja
Antal optiske diske:	1 diske
Equalizer, funktioner:	Classic, Jazz, Pop, Rock
Apple docking:	Ja
RDS funktioner:	PLL
