Side 1/10
RECEIVING AND INSPECTION
Immediately upon receipt of a shipment, carefully inspect for
damage and shortage. Turn impeller by hand to see that it turns
freely and does not bind. If any damage and/or shortage is detected
or suspected, the carrier must be asked to conduct an inspection.
The consignees representative should not accept shipment without
a notation on the delivery receipt indicating items not delivered or
apparent extent of damage.
When a shipment is opened and damage is found which was not
evident externally (concealed damage), it is mandatory that the
consignee request an immediate inspection by the carrier. Report
damage to the carrier within 15 days. Failure to report damage within
the above time limit will cause rejection of a claim.
HANDLING
When handling fans and their accessories, always use equipment
and methods that will not cause damage. Fans should be lifted using
slings and padding or spreaders to avoid damage.
CAUTION! Always make sure that all lifting and handling equipment
and techniques conform to current safety standards.
Avoid lifting fans in a way that will bend or distort fan parts. Never
pass slings or timbers through the orices of fan.
CAUTION! Do not lift by the fan hood. Fans with special coatings or
paints must be protected in handling to prevent damage.
STORAGE
Fans are protected against damage during shipment. If they
cannot be installed and put into operation immediately upon receipt
certain precautions are necessary to prevent deterioration during
storage. Responsibility for integrity of fans and accessories during
storage must be assumed by the user. The manufacturer will not
be responsible for damage during storage. These suggestions are
provided solely as a convenience to the user, who shall make his
own decision as to whether to use any or all of them.
INDOOR: The ideal storage environment for fans and accessories is
indoors, above grade, in a low humidity atmosphere which is sealed
to prevent the entry of blowing dust, rain, or snow. Temperatures
should be evenly maintained at between 70°F and 105°F (wide
temperature swings may cause condensation and “sweating” of
metal parts). Windows should be covered to prevent temperature
variations caused by sunlight. Provide thermometers and humidity
indicators at several points and maintain the atmosphere at 40%
relative humidity, or lower.
It maybe necessary to use trays of renewable desiccant or portable
dehumidier to remove moisture from the air in the storage enclosure.
Thermostatically controlled portable heaters (vented to outdoors)
may be required to maintain even temperatures inside the enclosure.
CAUTION! Provide re extinguishers, or re alarms, or emergency
response communication to protect building and equipment against
re damage. Be sure that building and storage practices meet all
local, state and federal re and safety codes.
The following fans or accessories must be stored indoors, in a clean
dry atmosphere:
a. Any fan that is protected by a cardboard carton.
b. Spare wheels or propellers.
c. Boxes, bags or cartons of hardware.
d. Curbs
e. Dampers
Remove any accumulations of dirt, water, ice or snow and wipe
dry before moving indoor storage. Allow cold parts to reach room
temperature to avoid “sweating” of metal parts. Open boxes or
cartons. Remove any accumulated moisture; if necessary use
portable electric heaters to dry parts and packages. Leave coverings
loose to permit air circulation and to permit periodic inspection.
Rotate wheels or propellers by hand to distribute bearing grease
over the entire bearing surfaces.
Store at least 3 ½” o󰀨 the oor on wooden blocks covered with
moisture proof paper or polyethylene sheathing. Provide aisles
between parts and along all walls, to permit air circulation and space
for inspection.
OUTDOOR: Fans designed for outdoor use may be stored outdoors,
if absolutely necessary. The storage area should be reasonably level
and drained or ditched to prevent accumulation of water. Fencing
and lighting for security are desirable. Roads or aisles for portable
cranes and hauling equipment are needed. Consider the use of drift
fencing to minimize accumulation of blowing snow or dirt.
The following fans may be stored outdoors, if dry indoor storage
space is not available:
a. Fans intended for outdoor use that are crated in wood.
b. Wall fans installed in wall housings.
All fans must be supported on wooden blocks or timbers above water
or normal snow levels. Provide enough blocking to prevent settling
into soft ground. Fans should be set in place using the directional
arrow markings on the crate as a guide.
Locate pieces far enough apart to permit air circulation, sunlight,
and space for periodic inspection. Place all parts on their supports
so that rain water will run o󰀨, or to minimize water accumulation. Do
not cover parts with plastic lm or tarps-these cause condensation
of moisture from the air passing through heating and cooling cycles.
Fan wheels and propellers should be blocked to prevent spinning
caused by strong winds.
INSPECTION AND MAINTENANCE DURING STORAGE
Inspect fans and accessories at least once per month, while in
storage. Log results of inspection and maintenance performed. A
typical log entry should include the following:
a. Date
b. Inspector’s Name
c. Name of Fan
d. Location
e. Condition of Paint or Coating
f. Is moisture present?
g. Is dirt accumulated?
h. Corrective steps taken?
Read and Save These Instructions
NAKS Form 613157
INSTALLATION & MAINTENANCE INSTRUCTIONS
Direct Drive Restaurant Grease Rated Fans
______________________________________________________________________________________________________________________________
2020 © North American Kitchen Solutions
172 Reaser Court
Elyria, OH 44035
www.naksinc.com
Page 1 of 10
