Read and Save These Instructions
NAKS Form 613158
RECEIVING AND INSPECTION
Immediately upon receipt of a shipment, carefully inspect
for damage and shortage. Turn the impeller by hand to see
that it turns freely and does not bind. If any damage and/or
shortage is detected or suspected, the carrier must be asked
to conduct an inspection. The consignee's representative
should not accept shipment without a notation on the delivery
damage.
When a shipment is opened and damage is found which was
not evident externally (concealed damage), it is mandatory
that the consignee request an immediate inspection by the
carrier. Report damage to the carrier within 15 days. Failure to
report damage within the above time limit will cause rejection
of a claim.
HANDLING
When handling fans and their accessories, always use
equipment and methods that will not cause damage. Fans
should be lifted using slings and padding or spreaders to
avoid damage.
equipment and techniques conform to current safety
standards.
Avoid lifting fans in a way that will bend or distort fan parts.
Never pass slings or timbers through the orices of fan.
CAUTION! lift by the fan hood. Fans with special Do not
coatings or paints must be protected in handling to prevent
damage.
STORAGE
Fans are protected against damage during shipment. If
they cannot be installed and put into operation immediately
upon receipt certain precautions are necessary to prevent
deterioration during storage. Responsibility for integrity of
fans and accessories during storage must be assumed by the
user. The manufacturer will not be responsible for damage
during storage. These suggestions are provided solely as a
convenience to the user, who shall make his own decision as
to whether to use any or all of them.
INDOOR: The ideal storage environment for fans and
accessories is indoors, above grade, in a low humidity
atmosphere which is sealed to prevent the entry of blowing
dust, rain, or snow. Temperatures should be evenly maintained
at between 70°F and 105°F (wide temperature swings may
cause condensation and "sweating" of metal parts). Windows
should be covered to prevent temperature variations caused
by sunlight. Provide thermometers and humidity indicators at
several points and maintain the atmosphere at 40% relative
humidity, or lower.
It may be necessary to use trays of renewable desiccant or
portable dehumidier to remove moisture from the air in the
storage enclosure.
Thermostatically controlled portable heaters (vented to
outdoors) may be required to maintain even temperatures
inside the enclosure.
CAUTION! Provide re extinguishers, or re alarms, or
telephone to protect building and equipment against re
damage. Be sure that building and storage practices meet all
local, state and federal re and safety codes.
The following fans or accessories must be stored indoors, in
a clean dry atmosphere:
a. Propeller Wall Fans not in Wall Housings.
b. Any fan which is protected by a cardboard carton.
c Motors dismounted from fans.
d. Spare wheels or propellers.
e. The belts, sheaves, bushings and other parts when
not mounted on fan.
f. Boxes, bags or cartons of hardware.
g. Curbs
h. Dampers
Remove any accumulations of dirt, water, ice or snow and
wipe dry before moving indoor storage. Allow cold parts to
reach room temperature to avoid “sweating” of metal parts.
Open boxes or cartons. Remove any accumulated moisture;
if necessary use portable electric heaters to dry parts and
packages. Leave coverings loose to permit air circulation and
to permit periodic inspection.
Rotate wheels or propellers by hand to distribute bearing
grease over the entire bearing surfaces.
Store at least 3 ½” off the oor on wooden blocks covered
with moisture proof paper or polyethylene sheathing. Provide
aisles between parts and along all walls, to permit air
circulation and space for inspection.
INSTALLATION & MAINTENANCE INSTRUCTIONS
Belt Drive Exhaust Fans
_________________________________________________________________________________________________________________
2017 © North American Kitchen Solutions
172 Reaser Court
Elyria, OH 44035
www.naksinc.com
Page 1 of 7
OUTDOOR: Fans designed for outdoor use may be stored
outdoors, if absolutely necessary. The storage area should
be reasonably level and drained or ditched to prevent
accumulation of water. Fencing and lighting for security are
desirable. Roads or aisles for portable cranes and hauling
equipment are needed. Consider the use of drift fencing to
minimize accumulation of blowing snow or dirt.
The following fans may be stored outdoors, if dry indoor
storage space is not available:
a. Fans intended for outdoor use that are crated in
wood.
b. Wall fans where installed in wall housings.
All fans must be supported on wooden blocks or timbers
above water or normal snow levels. Provide enough blocking
to prevent settling into soft ground. Fans should be set in
place using the directional arrow markings on the crate as a
guide.
Locate pieces far enough apart to permit air circulation,
sunlight, and space for periodic inspection. Place all parts
on their supports so that rain water will run off, or to minimize
water accumulation. Do not cover parts with plastic lm or
tarps - these cause condensation of moisture from the air
passing through heating and cooling cycles.
Fan wheels and propellers should be blocked to prevent
spinning caused by strong winds.
INSPECTION AND MAINTENANCE
DURING STORAGE
Inspect fans and accessories at least once per month, while
in storage. Log results of inspection and maintenance
performed. A typical log entry should include the following:
a. Date
b. Inspector’s Name
c. Name of Fan
d. Location
e. Condition of Paint or Coating
f. Is moisture present?
g. Is dirt accumulated?
h. Corrective steps taken?
If moisture or dirt accumulations are found on parts, the
rotated at each inspection by hand ten to fteen revolutions to
redistribute the motor and bearing lubricant.
require special techniques for touch-up or repair.
Machined parts coated with rust preventive should be restored
to good condition promptly if signs of rust occur. The most
critical items are pulleys, shafts and bearing locking collars.
At the rst sign of rusting on any of the above parts, remove
the original rust preventive coating with petroleum solvent and
clean lint-free cloths. Polish any remaining rust from surfaces
with crocus cloth or ne emery paper and oil. Do not destroy
the continuity of the surfaces. Wipe clean with lint-free cloths
(Ashland Oil Company) or equal. For hard to reach internal
surfaces or for occasional use, consider using Tectly 511M
Rust Preventive or WD40 or equal.
REMOVING FROM STORAGE
As fans are removed from storage to be installed in their nal
location, they should be protected and maintained in similar
fashion, until the fan equipment goes into operation.
INSTALLATION
1. CAUTION! This unit has rotating parts and safety
precautions should be exercised during installation,
operation and maintenance.
2. WARNING! use in hazardous environments Do not
where the fan's electrical system could provide ignition
to combustible or ammable materials, unless the unit is
specically built for hazardous environments.
3. WARNING! If gases, other than clean air, are to be
exhausted using the fan, then the user bears the
responsibility of determining that the fan is appropriate
and safe for the application.
4. COMMERCIAL KITCHEN EXHAUST APPLICATIONS:
Ventilators should be installed in accordance with the
requirements of the National Fire Protection Association
Bulletin NFPA96 “Vapor Removal From Cooking
Equipment” taking specic note of the following:
(a) Ducts terminating into the base of an up-discharge
exhaust fan shall be constructed of carbon steel not
less than 16 MSG (1.6 mm) and extend a minimum
of 18" (457 mm) above the roof surface.
(b) Air velocity through the duct shall not be less than
1500 FPM (7.620 m/s).
(c) A minimum of 40" (1016 mm) clearance shall be
maintained between the exhaust discharge and
the roof surface. (To comply sizes 80 through 300
require 18" [457 mm] roof curb.)
(d) Fan Discharge shall be a minimum of 10 feet from
the fresh air intake.
5. GREASE TROUGH ACCESSORY: A container to collect
residue grease should be located under the grease drain
on the ventilator to prevent accumulation of grease on the
roof surface. An accessory grease trough that attaches
to the curb is available from the manufacturer at extra
cost. Containers should be serviced at regular intervals
to prevent overow. Curb hinges are also available as an
optional accessory. Installation instructions are shipped
with the accessories.
_________________________________________________________________________________________________________________
2017 © North American Kitchen Solutions
172 Reaser Court
Elyria, OH 44035
www.naksinc.com
