Side 1/6

JR, BM

10/20/13

NTV-DOC091

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

1 | P a g e

3950 NW 120th Ave, Coral Springs, FL 33 TEL 561-955-9770 FAX 561-955-9760 065

www.nav-tv.com info@nav-tv.com

Volvo CAM/Volvo CAM12

NTV-KIT294/368

Overview

The Volvo Cam kit adds an aermarket back up camera to the factory 6.5” screen in select

Volvo vehicles. Addionally, this module will enable video in moon (VIM) and navigaon

control in moon (CIM) if equipped. This installaon requires no cung of any factory wires

and is fully Plug & Play behind the media screen.

Kit Contents

Volvo Cam module

NTV-ASY160

NAV-TV CAM 6

NTV-CAM046

SMB to RCA adapter

NTV-CAB007

USB Cable (updates)

NTV-CAB009

Plug Play T-Harness &

KIT294: NTV-HAR207

KIT368: NTV-HAR204 & NTV-HAR207

CAM 6 Extension Power/Signal

NTV-CAM046

JR, BM

10/20/13

NTV-DOC091

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

2 | P a g e

Volvo Cam Module Pin Outs

Pin #

Descripon

Color

12v Constant (+)

Yellow

-not used-

Gray

-not used-

Blue

CAN HI (Radio Side)

Green

CAN HI (Vehicle Side)

White

Ground (-)

Black

Output 1 (12v w/ CAN)

White/Red

Output 2 (12v w/ REV)

White/Blue

Output 3

White/Purple

-not used-

Gray/White

-not used-

Pink/Black

-not used-

Pink

CAN LO (Radio Side)

White/Green

CAN LO (Vehicle Side)

Brown

Module Programming

1. The Volvo Cam module will come preprogrammed with the most popular working le,

but you may need to adjust it for your parcular Volvo type/year.

2. Refer to and click on the hps://navtv.com/products/NTV-KIT368/volvo-cam-12.html

‘ ’Files buon at the boom.

3. Aer downloading, unzip the compressed folder into another folder.

4. If you’ve never TV module before, you’ll need to install one updated a NAV- of the USB

drivers from the same unzipped folder (win 7+ or XP driver, respecvely).

5. Open the Volvo USB Updater (blue icon) found in the extracted folder from step 3.

6. Connect the Volvo Cam module to the computer using the provided USB to mini-USB

cable.

7. The ‘USB Device’ eld should populate aer 5-10 seconds.

8. Click the 3 dots at the top right of the updater window. Navigate to the same extracted

folder from step 3. Select the ‘VolvoVIMCam.enc’ le and press ‘Open’.

9. Double click ‘ON’ for VIM or address in moon to adjust ON or OFF.

10. Double click ‘ON’ for Rear view camera to adjust ON or OFF.

11. Double click ‘o’ for Front view camera to adjust ON or OFF.

Wire Side
