RGB-VW

NTV-KIT389

Overview

The RGB-VW allows the user to add an aermarket backup camera to the factory navigaon

screen in select Volkswagen vehicles. Reverse acvaon is automac, no reverse lamp

connecon is required.



NOTE: The VW must be programmed for rear camera (VAG-Comm: Ross Tech) before

installing this product.

Kit Contents

Plug & Play Video IN Harness

NTV-HAR209

RGB Power Harness

NTV-CAB034

RGB Converter

NTV-INT005

BHM

01/05/14

NTV-DOC101

2 | P a g e

Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

Interface Connectors

Installaon

*This car must be programmed for rear camera before installing this kit. This update can be

performed at a VW dealership, or if you have a VAG-COMM programmer you can perform the

update yourself.

1. Remove the factory radio, disconnect all harnesses and set the radio aside.

2. Connect the from the provided to black wire RGB Power Harness

ground.

3. Connect the from the provided to red wire RGB Power Harness

an accessory 12v (+) source.

4. Connect the provided to the RGB-Plug & Play Video IN Harness

VW.

5. Connect the other end of the to the port Plug & Play Video IN Harness

of the back of the VW radio (it will only t in one locaon).

6. Connect the power plug you previously wired up (step 2 & 3) to the RGB-VW.

7. Connect your camera’s signal to port on the RGB-VW labeled ‘VIDEO 1’.

Power port

RGBS vs Sync Over Green

switch (leave on RGBS)

NOT USED

Camera IN

Plug & Play RGB connector
