EASY CHEESER™

N55300A 3/4” Slicing Arm

N55300A-1 3/8” Slicing Arm

N55300A-2 3/4” & 3/8” Slicing Arms

OPERATING AND MAINTENANCE INSTRUCTIONS

IMPORTANT

1. To get the best operation and life from your machine, please read and comply with these instructions.

2. Clean machine thoroughly before and after each use using cleaning instructions below.

3. Minimize the use of alkaline cleaners as they may cause pitting and dulling of the finish.

OPERATION

1. Set unit on a flat, sturdy surface when cutting cheese.

2. Prepare the block of cheese to be cut. Since cheese is produced in different sized loaves, the size of the prepared block must be

convenient to the preparer. The EASY CHEESER™ will easily handle 1/3 of many 5 pound loaves.

3. Select the CUTTING BOW ASSEMBLY to be used – 3/4inch cut or 3/8 inch cut.

4. Raise the CUTTING BOW ASSEMBLY to the full upward position and place the prepared cheese block against the guide at the right of

the SUPPORT BLOCK ASSEMBLY. NOTE: We recommend that the longest dimension of the prepared block be pointed toward the

CUTTING BOW WIRES for the first and second cuts when it can be done to produce the desired size and shapes of cheese.

5. Gently and steadily, press the CUTTING BOW through the prepared cheese block. This has now produced slices of cheese.

6. To cut sticks of cheese, set the sliced block of cheese aside and again raise the CUTTING BOW ASSEMBLY. (Change the CUTTING

BOW ASSEMBLY if it is desired to cut rectangular sticks rather than square sticks.) Turn the sliced block ¼ turn (90 degrees) and

again place the block on the SUPPORT BLOCK ASSEMBLY in the same position as in line number (3) above. Gently and steadily press

the CUTTING BOW through the sliced block. This has now produced sticks of cheese.

7. To cut cubes and rectangles – set the “sticked” block of cheese aside and again raise the CUTTING BOW. (Select the appropriate BOW

for the desired cut.) Place the “sticked block on the SUPPORT BLOCK ASSEMBLY so that the sticks lie across the slots in the frame.

Be sure the “sticked” block is against the guide at the right end of the FRAME to get uniform cuts. Gently and steadily, press the

CUTTING BOW through the “sticked” block. This has produced cubes or rectangles, depending upon the CUTTING BOW selection.

8. If unit fails to operate properly when first used call NEMCO customer service at 1-800-782-6761.

IMPORTANT:

Store in a place to protect the EASY CHEESER from being bumped. Accidental notches in the wires may cause premature failure.

CLEANING

NOTE: Proper maintenance plays an important part in the life span and functioning of the unit.

1. For easiest cleaning, wash the unit soon after each use to prevent cheese from hardening prior to washing.

2. Wash with a pressure spray or conventional sink cleaning methods. It is dishwasher safe but strong alkaline cleansers will dull the

surface and eventually pit the metal. MINIMIZE THE USE ALKALINE CLEANSERS.

3. Remove the PIVOT PIN ASSEMBLY and release the CUTTING BOW.

4. Wash the PIVOT PIN ASSEMBLY and the FRAME and SUPPORT ASSEMBLY by conventional methods. Notice that the SUPPORT

BLOCK ASSEMBLY may be removed from the FRAME for cleaning by removing screws and then can be disassembled. When

reassembling the unit, be sure parts are aligned.

5. Wash the CUTTING BOW by either of the following methods, as deemed necessary.

a) With the cutting wire installed wash thoroughly by conventional methods. Pay particular attention to where the wire wraps

around the posts and screws. A BRUSH is provided for cleaning in this area.

b) To wash with cutting wire removed, remove the CUTTING WIRE by loosening SCREWS to fully expose the posts and screws.

Wash thoroughly with the BRUSH provided. New wire must be installed to achieve necessary tension. Notice that the POSTS can

be removed for cleaning by removing the screws. Be sure the screws are tight when the CUTTING BOW is reassembled.

SERVICE INSTRUCTIONS

TO CHANGE CUTTING BOWS

1. Release CUTTING BOW by pulling the knob on the PIVOT PIN ASSEMBLY.

2. Position the alternate CUTTING BOW on the FRAME and SUPPORT ASSEMBLY so that the PIVOT PIN holes are aligned and insert

the PIVOT PIN ASSEMBLY from either side of the FRAME.

TO REPLACE CUTTING WIRE

The REPLACEMENT WIRE KIT contains REPLACEMENT WIRE, a TENSIONER, spare SCREWS and complete instructions for easy re-

wiring of the CUTTING BOW.

If you prefer, the CUTTING BOW can be returned to NEMCO for wire replacement.

Number of pieces of cheese from a 3 3/4" x 3 3/4" x 4 1/2" block

Pieces Bow Cut 1 Cut 2 Cut 3

3/4" Stick x 3 ¾” LONG 30

3/4" Stick x 4 ½” LONG 25 3/4 x x

3/4" Cube 150 3/4 x x x

3/8" Stick x 3 ¾” LONG 120

3/8" Stick x 4 ½”LONG 100 3/8 x x

3/8" Cube 1200 3/8 x x x

3/8"x3/4" Stick x 3 ¾” 60 3/8 x

3/8"x3/4" Stick x 4 ½” 50 3/4 x

3/8 x

3/8"x3/4"x3/4" Pads 300 3/4 x x

3/8 x x

3/8"x3/8"x3/4" Pads 600 3/4 x

EXAMPLE: CUTTING STICKS ¾” x ¾” x 3 ¾” LONG

a. PLACE BLOCK OF CHEESE IN CUTTER WITH LONGEST DIMENSION PARRALLEL TO THE CUTTING BOW

b. CUT CHEESE - THIS WILL YEILD (6) SLICES ¾” x 3 ¾” x 3 ¾”

c. ROTATE THE BLOCK OF CHEESE ¼ TURN (90 DEGREES)

d. CUT CHEESE - THIS WILL YEILD (30) STICKS ¾” x ¾” x 3 ¾”

e. IF YOU FIRST PLACE BLOCK OF CHEESE IN CUTTER WITH LONGEST DIMENSION PERPENDICULAR TO THE

CUTTING BOW YOU WILL YIELD (5) SLICES ¾” x 3 ¾” x 4 1/2” AND (25) STICKS ¾” x ¾” x 4 ½”

NEMCO FOOD EQUIPMENT

301 Meuse Argonne, Hicksville, OH 43526

Phone: (419) 542-7751 Fax: (419) 542-6690 Toll free: 1-800-782-6761

7/22/2014 46018
