Side 1/3
Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com
INS-NSR-9744XL-21
Instruction Manual
NSR-9744XL
US PATENT 9,713,217
Please read these instructions before using your 9744XL. They include
important safety and operation information. Be sure to charge the 9744XL fully
before the  rst use. A battery is fully charged when the charger light is green.
Included in the box - Compris dans la boîte - Incluido en la caja
WARNINGS
y Lithium-ion batteries must be used and charged properly. Improper use can
result in serious injury,  re, or death.
y NOT FOR USE IN HAZARDOUS LOCATIONS. Do not use this product in
explosive atmospheres, near ammable liquids, or where explosion proof or
intrinsically safe lighting is required.
y DO NOT use this product in the proximity of vehicles or equipment when there
is a risk of  ammable liquids coming into contact with the  ashlight.
y Light can become hot while on. To prevent damage DO NOT cover or place
next to any potentially  ammable materials while in use.
y Do not leave the battery in direct sunlight or use or store the battery inside cars
in hot weather.
y Do not expose the battery to water or salt water, or allow the battery to get wet.
y Do not store the battery with metallic objects that may cause a short circuit.
y Immediately discontinue use of the battery if the battery emits an unusual
smell, feels hot, changes color, changes shape or appears abnormal in any way.
y Keep out of the reach of children.
STROBE WARNING
Exposure to strobing lights may cause dizziness, disorientation, and nausea.
A very small percentage of people suffer from photosensitive epilepsy and may
experience seizures or blackouts triggered by strobing lights. For more information
from the EPILEPSY FOUNDATION about photosensitivity and seizures, please
visit www.epilepsy.com. Anyone who has had symptoms linked to this condition
should consult a doctor before using this product.
INITIAL USE
Fully charge the 9744XL before the  rst use, or if the battery is new or has been
unused for several months. The maximum charge time required is approximately
6 hours.
CHARGER INPUT: 12 VDC Max
DAILY USE
y Use only the supplied Nightstick charger, battery and AC or DC adapter. For
best performance, charge the 9744XL when the  ashlight beam starts to dim.
y Connect the AC power adapter to the charger. The LED indicator will not be
illuminated at this point.
y With the ashlight facing forward, snap the 9744XL into the charger until the
contacts snap into place.
y The LED indicator changes to constant red indicating the 9744XL is properly
inserted into the charger and is in fact charging. The LED indicator remains red
until the battery is fully charged. At full charge, the LED indicator turns green.
y The total time to full charge the 9744XL varies depending on the remaining
charge in the battery pack.
y To con rm a full charge, keep the 9744XL in the charger and turn it on. The LED
indicator will change to red. Turn off the 9744XL. If the 9744XL is fully charged, the
LED indicator will turn green. If not, it remains red until the charge is completed and
the LED indicator turns green. The 9744XL will now be fully charged.
OPERATION
The 9744XL has seven light modes: momentary ashlight, full brightness
ashlight, medium brightness ashlight, low brightness ashlight, oodlight, dual-
light and strobe. The 9744XL has two body switches providing access to all modes.
MOMENTARY FLASHLIGHT MODE
Lightly press the top body switch for momentary operation. Release the switch
to turn the light off.
CONSTANT-ON
Press the top body switch until it clicks and then release for constant-on in
high-brightness mode. Press and release either switch to turn the light off.
SELECT BRIGHTNESS LEVEL
Press and hold down the top body switch. The light will cycle from high to
medium to low and then back up again at a rate of approximately one mode per
second. The light will continue to cycle up and down through the various modes
as long as the switch is held down. When the desired brightness level is reached,
simply release the switch, and the light will remain in that brightness mode. Press
and release the top body switch to turn the light off.
FLOODLIGHT
Press the bottom body switch until it clicks and then release for oodlight
mode. Press and release the bottom body switch again to turn the light off.
DUAL-LIGHT
Dual-Light allows the user to turn on both the Flashlight (at any brightness
level) and the Floodlight, at the same time. First select the appropriate brightness
level of the ashlight using the directions above. Next press and release the
bottom switch to activate the  oodlight. Both the Flashlight and the Floodlight are
now running. Press and release both the top and bottom body switches to turn
the light off.
STROBE FUNCTION
From off or any mode, rapidly double click the top body switch to activate the
strobe function running at full brightness. Press and release the top body switch
to turn the light off.
WARRANTY
LIMITED LIFETIME WARRANTY
Bayco Products, Inc. warrants this product to be free from defects in workmanship
and materials for the original purchaser’s lifetime. The Limited Lifetime Warranty
includes the LEDs, housing and lenses. Rechargeable batteries, chargers, switches,
electronics and included accessories are warranted for a period of two years with
proof of purchase. Normal wear and failures which are caused by accidents, misuse,
abuse, faulty installation and lightning damage are excluded.
We will repair or replace this product should we determine it to be defective.
This is the only warranty, expressed or implied, including any warranty of
merchantability or  tness for a particular purpose.
For a complete copy of the warranty, go to www.baycoproducts.com/bayco-
product-support/warranties. Retain your receipt for proof of purchase.
