Side 1/2

Cabled scanners

Barcode laser scanner

Related products

OPR3201

Cabled device•

Barcode laser scanner•

RS232, Keyboard Wedge, USB•

With stand•

OPV1001

Stationary device•

Omnidirectional laser scanner•

RS232, Keyboard Wedge, USB (HID/•

VCP)

ABS, with stand•

OPL7836

Cabled device•

Barcode laser scanner•

RS232, Keyboard Wedge, USB•

OPR2001

OPR2001_004

Basic Product Speciﬁcations

Operating indicators

Visual: 1 LED (red/green/orange)•

Non-visual: Buzzer•

Operating keys

Entry options: •

1 scan key

Communication

RS232: DB9 PTF connector with external power •

supply

Keyboard Wedge: MiniDIN6 F/M connector•

USB: Ver. 1.1, HID/VCP, USB-A connector•

Power

Voltage requirement: 5V • ± 10% (Keyboard Wedge

and USB), 6V (min. 4.5, max. 6.5V) (RS232)

Current consumption: Max. 150mA•

Barcode scanner Optics

Light source: 650 nm visible laser diode•

Scan method: Bi-directional scanning•

Scan rate: 100 scans/sec•

Trigger mode: Manual, auto-trigger, stand detection•

Reading pitch angle: -35 to 0°, 0 to +35°•

Reading skew angle: -50 to -8°, +8 to +50°•

Reading tilt angle: -20 to 0°, 0 to +20°•

Curvature: R>15 mm (EAN8), R>20 mm (EAN13)•

Min. resolution at PCS 0.9: 0.127 mm / 5 mil•

Min. PCS value: 0.45•

Depth of ﬁeld: At PCS 0.9, Code 39•

40 - 500 mm / 1.57 - 19.69 in (1.0 mm / 39 mil),

20 - 350 mm / 0.79 - 13.78 in (0.5 mm / 20 mil),

20 - 200 mm / 0.79 - 7.87 in (0.25 mm / 10 mil),

20 - 100 mm / 0.79 - 3.94 in (0.15 mm / 6 mil),

30 - 70 mm / 1.18 - 2.76 in (0.127 mm / 5 mil)

Supported Symbologies

Barcode (1D): JAN/UPC/EAN incl. add on, Codabar/•

NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128

(EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5,

Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/

Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey

Postal code: Chinese Post, Korean Postal Authority •

code

2D code: Composite codes, MicroPDF417, PDF417•

Durability

Temperature in operation: -5 to 50 °C / -23 to 122 °F•

Temperature in storage: -20 to 60 °C / -4 to 140 °F•

Humidity in operation: 20 - 85% (non-condensing)•

Humidity in storage: 10 - 90% (non-condensing)•

Ambient light immunity: Fluorescent 3,000 lx max, •

Direct sun 50,000 lx max, Incandescent 3,000 lx

max

Drop test: 1.5 m / 5 ft drop onto concrete surface•

Vibration test: 10 - 100 Hz with 2G for 1 hour•

Protection rate: IP 42•

Physical

Dimensions (w x h x d):•

56 x 151 x 31 mm / 2.20 x 5.94 x 1.22 in

Dimensions stand (w x h x d): •

100 x 175 x 127 mm / 3.94 x 6.89 x 5.00 in

(excl. scanner)

Weight body: Ca. 60 g / 2.1 oz (excl. cable) •

Weight stand: Ca. 115 g / 4.1 oz•

Case: ABS, Black, chrome stand•

Regulatory & Safety

Product compliance: CE, FCC, VCCI, RoHS, •

JIS-C-6802 Class 2, IEC 60825-1 Class 2, FDA CDRH

Class II

Enclosed items

Stand•

Sold separately

Power supply 100-240V/0.5A, 50/60 Hz, 6V/2A (for •

RS232)

Models

Interface versions: RS232, Keyboard Wedge, USB•

WWW . O P T I C ON. C O M

- The Netherlands: Hoofddorp

- France: Issy Les Moulineaux

- Germany: Dietzenbach

- Italy: Villanova di Castenaso (BO)

- Sweden: Järfälla

- United Kingdom: Luton, Bedfordshire

- U.S.A.: Renton, WA

- Brazil: São Paulo

- Japan: Warabi City

- Taiwan: Taipei

- P.R.China: Shanghai

- Australia: West Ryde

Opticon Sensors Europe B.V

European headquarters

Opaallaan 35

2132 XV Hoofddorp

The Netherlands

phone: +31 (0)23-5692700

fax: +31 (0)23-5638266

email: sales@opticon.com

internet: www.opticon.com

Produkt Specifikationer

Mærke:	Opticon
Kategori:	Stregkodelæser
Model:	OPR2001
Kode for international beskyttelse (IP):	IP42
Vægt:	60 g
Produktfarve:	Sort
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	20 - 85 %
Driftstemperatur (T-T):	-5 - 50 °C
Dimensioner (BxDxH):	56 x 31 x 151 mm
Certificering:	CE, FCC, VCCI, RoHS
Kabellængde:	1.5 m
Basisvægt:	115 g
Indgangsspænding:	6 V
Standard grænseflader:	USB
Bølgelængde:	650 nm
Strømforbrug:	150 mA
Hældningsvinkelområde:	-20 - 20 °
Maksimal driftstilstand:	1.5 m
Skanningshastighed:	100 sek./side
Pitch læsningsvinkel:	-35 - 35 °
