Cutting Metal
Your jigsaw can be used for cutting light gauge ferrous sheet and non-
ferrous metals such as copper, brass, aluminium, etc.
It is advisable when cutting sheet metal to clamp a backing sheet of soft
wood or plywood to the work as this will enable you to obtain a clean cut
without vibration and the possibility of tearing the metal. Both metal and
wood backing are sawn together. Do not force the cutting blade into the
metal as this will reduce the life of the blade and possibly damage the
motor.
Cutting thin metal will take longer than cutting even a relatively thick
piece of wood, so do not be tempted to speed up the operation by forcing
the saw. Spread a thin lm of oil along the proposed cutting line before
commencing to saw metal.
Always select the right blade for the job.
Jigsaw Frequently Cuts Out During Use
If the jigsaw switches off during use, the tool is overloaded. Please reduce
cutting pressure and/or increase pendulum action to reduce load on the
tool.
PXBJSS-018
INSTRUCTION MANUAL
ozito.com.au
0725
ELECTRICAL SAFETY
WARNING! When using electric tools basic safety precautions should always be
followed to reduce the risk of fire, electric shock and personal injury.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool. Save these instructions and other documents supplied with
this tool for future reference.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• This appliance is compatible and only to be used with all batteries & chargers from the
Ozito PXC range. Refer to the PXC battery and charger manuals for information regarding
charging, use and storage.
WARNING! Always remove the battery from the tool: when the batteries are to
be charged, when the tool is left unattended, when the tool is being checked, cleaned,
or having maintenance work done, when the tool is to be stored, or if the tool vibrates
abnormally.
• Do not combine different types of batteries or new and used batteries.
• Do not point LED at eyes of persons or animals.
• Do not use modified or damaged batteries.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the
warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power
tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can be caught
in moving parts.
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe
injury within a fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if
detachable, from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not allow for safe handling and control of the
tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk
of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature. Exposure to
fire or temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool
outside the temperature range specified in the instructions. Charging improperly or
at temperatures outside the specified range may damage the battery and increase the
risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be
performed by the manufacturer or authorized service providers.
JIGSAW SAFETY WARNINGS
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Hold the power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting
a “live” wire may make exposed metal parts of the power tool “live” and could give the
operator an electric shock.
• Use clamps or another practical way to secure and support the workpiece to a stable
platform. Holding the workpiece by hand or against your body leaves it unstable and may
lead to loss of control.
• Remove all nails and screws in the work piece before using the jigsaw. Cutting nails or
screws may damage your tool.
• Do not cut hollow pipe with the jigsaw
• Do not cut material thicker or of a wider diameter than the specified limits.
• Always allow enough clearance underneath the work piece to ensure the blade does not
touch the floor or work bench, etc.
• Hold the tool at a comfortable distance from your body. Do not over reach to access the
work piece.
• Do not touch moving parts with your fingers or hand.
• Do not cut through walls or cavities without first checking for hidden electrical wires.
• Ensure that you have tightened the blade prior to starting the machine.
• When you have finished the cut, wait until the saw blade has stopped moving prior to
removing it from the work piece.
• Do not touch the saw blade immediately after use. Allow time for the blade to cool, as it
may burn you due to the heat generated during sawing.
• Always check accessories to ensure that they are suitable for the operating speeds of this
tool. Incorrect accessories can break apart at high speed and cause serious damage or
injury.
• Avoid using power tools for long periods of time without breaks. Vibration from tools can be
transmitted into your hands and arms.
• Do not point LED at eyes of persons or animals.
Brushless Pendulum Jigsaw
Splinter Guard, Hex Key,
Timber Jigsaw Blade, Parallel
Guide, Line Guide, Dust
Extraction Adaptor, Angle
Adaptor, Base Plate Shoe
(Fitted)
When not in use, the tool should be stored in a dry, frost free location; keep
out of children’s reach.
If the housing of the tool requires cleaning, do not use solvents. Use of a
cloth only is recommended. Never immerse any part of the tool into liquid.
Note: Ozito Industries will not be responsible for any damage or
injuries caused by repair of the tool by an unauthorised person or by
mishandling.
MAINTENANCE
DESCRIPTION OF SYMBOLS
Diameter
Warning
Regulatory Compliance Mark
(RCM)
Wear eye, ear & breathing
protection
V
Volts
Direct Current
n
0
Ø
/min
No load speed
Revolutions or reciprocations
per minute
Read Instruction Manual
Power tools that are no longer usable should not be disposed
of with household waste but in an environmentally friendly
way. Please recycle where facilities exist. Check with your local
council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
SPARE PARTS
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here,
visit www.ozito.com.au or contact Ozito Customer
Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: enquiries@ozito.com.au
BRUSHLESS
PENDULUM
JIGSAW
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.
5. TROUBLESHOOTING
WARNING! BEFORE CLEANING OR CARRYING OUT
ANY MAINTENANCE PROCEDURE, ENSURE THAT
THE BATTERIES HAVE BEEN REMOVED.
4. MAKING CUTS
Pocket Cutting
A pocket cut is a hole cut into the middle of a workpiece.
1. Drill a hole into the workpiece (within the cut line) using a drill bit larger
than the intended jigsaw blade.
2. Place the blade of the jigsaw into the drilled hole and begin the cut.
WARNING! IF THE JIGSAW SWITCHES OFF DURING
USE, THE TOOL IS OVERLOADED. REDUCE THE
CUTTING PRESSURE AND/OR INCREASE THE
PENDULUM ACTION TO REDUCE LOAD ON THE
TOOL.
Straight Cuts
1. Place the base plate onto the workpiece but ensure that the blade is not
touching the edge of the material to be cut.
WARNING! ALWAYS HOLD THE TOOL BY ITS
INSULATED GRIPPING SURFACES. USE BOTH
HANDS TO SUPPORT THE TOOL WHEN CUTTING.
2. Select the speed from 1-7 and
then squeeze the on/off trigger to
start the tool.
3. Move the jigsaw forward into the
cut with light pressure. Allow the
tool to do the work.
4. To stop the jigsaw, release the on/off trigger.
WARNING! ALLOW THE BLADE TO COME TO A
COMPLETE STOP BEFORE LIFTING THE JIGSAW OUT
OF THE CUT.
WARNING! ONLY USE BLADES APPROPRIATE TO THE
MATERIAL BEING CUT. ONLY USE THE SUPPLIED
TIMBER BLADE TO CUT TIMBER.
WARNING! ENSURE ALL WORKPIECES ARE
SECURELY CLAMPED DOWN.
SPECIFICATIONS
Input: 18V
No Load Speed: 3,500/min
Stroke Height: 26mm
Cutting Depth: 135mm (Timber)
20mm (Plastic)
10mm (Metal)
Bevel Angle: 0-45° (Left & Right)
Blade Type: T-Shank
Adaptor Size: Ø35mm
Weight: 2.1kg
OZITO 25 Fox Drive, Dandenong South, Victoria, Australia 3175.
